- Page 1 USER MANUAL Network Dome Camera FD1001V1-EI/T V2017.1.001...
- Page 2 User Manual - Network Dome Camera – About this Manual This Manual is applicable to Network Camera. The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
- Page 3 User Manual - Network Dome Camera – Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 4 User Manual - Network Dome Camera – EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2004/108/EC, the RoHS Directive 2011/65/EU.
- Page 5 User Manual - Network Dome Camera – These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
- Page 6 User Manual - Network Dome Camera – Please make sure that the plug is firmly connected to the power socket. When the product is mounted on wall or ceiling, the device shall be firmly fixed. If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center.
- Page 7 User Manual - Network Dome Camera – camera model has an “H” in its suffix), dusty or damp locations, and do not expose it to high electromagnetic radiation. To avoid heat accumulation, good ventilation is required for operating environment. Keep the camera away from liquid while in use. While in delivery, the camera shall be packed in its original packing, or packing of the same texture.
-
Page 8: Table Of Contents
User Manual - Network Dome Camera – Table of Contents 1 Appearance Description ..............9 1.1 Type I Camera ..............9 1.2 Type II Camera .............. 12 2 Installation ..................14 Preparation ..............15 2.1.1 Disassembling............. 15 2.1.2 Memory Card Installation ........16 Mounting .............. -
Page 9: Appearance Description
User Manual - Network Dome Camera – 1 Appearance Description Cameras of this series belong to two appearance types. Type I has the lens that zoom and focus levels must be manually adjusted via zoom/focus lever. Type II has a motor-driven lens that zoom and focus adjustment can be completed via web browser or client software. - Page 10 User Manual - Network Dome Camera – Figure 1-1 Overview of Type I Camera Table 1-1 Description of Type I Camera Description Bubble Black Liner Lens Mounting Base Reset Auxiliary Video Output Serial Port...
- Page 11 User Manual - Network Dome Camera – Description Memory Card Slot Network Interface Power Supply Interface Audio/Alarm Interface Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, and port No., etc. Some of the models support audio and alarm functions.
-
Page 12: Type Ii Camera
User Manual - Network Dome Camera – Type II Camera The overview of the Type II network dome camera is shown below. Figure 1-3 Overview of Type II Camera... - Page 13 User Manual - Network Dome Camera – Table 1-2 Description of Type II Camera Description Bubble Black Liner Motor-Driven Lens Mounting Base Reset Auxiliary Video Output Serial Port Memory Card Slot Network Interface Power Interface Audio Input and Output Interface Video Output Interface Alarm Input and Output Interface Press RESET about 10s when the camera is powering on or rebooting...
-
Page 14: Installation
User Manual - Network Dome Camera – 2 Installation Before you start: Make sure the device in the package is in good condition and all the assembly parts are included. The standard power supply is 12V DC or PoE (802.3af), please make sure your power supply matches with your camera. -
Page 15: Preparation
User Manual - Network Dome Camera – Preparation Purpose: Before mounting, you have to disassemble the camera and install the memory card first. 2.1.1 Disassembling Steps: Loosen the three screws on the edge of the bubble with the screw driver. Lift and put aside the bubble. -
Page 16: Memory Card Installation
User Manual - Network Dome Camera – 2.1.2 Memory Card Installation Steps: 1. Rotate the camera body to completely expose the memory card slot. 2. Insert the memory card into the memory card slot, and push to get it mounted. Memory Card Memory Card Slot Figure 2-2... - Page 17 User Manual - Network Dome Camera – 2. Drill three screw holes in the ceiling. Side Cable Outlet Cable Outlet Screw Hole Screw Hole Drilling Template for Outdoor Day/Night Vandal-proof Dome Camera Screw Hole Figure 2-3 The Drill Template If you want to route the cables inside the ceiling, drill a cable hole in the ceiling according to the drill template.
- Page 18 User Manual - Network Dome Camera – Back Box Screws Figure 2-4 Secure the Camera 4. Adjust the surveillance angle, zoom and focus level. Refer to the Section 2.3 for detailed information. 5. Install the inner black liner back to the camera. 6.
- Page 19 User Manual - Network Dome Camera – Conduit Installation on the Side If you want to route the cables from side of the camera, you need to install a conduit for cable routing. Steps: 1. Rotate the water-proof plug counterclockwise to remove it from the camera.
-
Page 20: In-Ceiling Mounting
User Manual - Network Dome Camera – For wall mounting, position the side outlet directly downward for water-proof. Downward Figure 2-8 Side Outlet Direction 2.2.2 In-ceiling Mounting Before you start: In-ceiling mounting bracket is not included in package. If you choose this mounting type, you have to prepare a bracket first. - Page 21 User Manual - Network Dome Camera – Main Body Ceiling Hole Size In-ceiling Mounting Bracket Figure 2-9 Cut a Hole for In-ceiling Mounting 2. Align No.1 screw holes with the corresponding screw holes on the bracket, and secure the mounting base to the bracket with screws. In-ceiling Mounting Bracket Mounting...
- Page 22 User Manual - Network Dome Camera – 3. Align the screw holes for camera fixing, and secure the camera to the mounting base. In-ceiling Mounting Mounting Base Bracket Camera Screw Holes for Camera Fixing Figure 2-11 Install the Camera to the Mounting Base 4.
- Page 23 User Manual - Network Dome Camera – Toggle Bolts: screw them clockwise Toggle Bolts: fix the bracket Figure 2-12 Fix the Bracket in Ceiling 5. Adjust the surveillance angle, refer to Section 2.3. 6. Install the black liner and the bubble back to the camera. Figure 2-13 Install the Black Liner and the Bubble...
-
Page 24: Mounting With Wall Mounting Bracket
User Manual - Network Dome Camera – 7. Install the rim to the bracket. Figure 2-14 Install the Rim 2.2.3 Mounting with Wall Mounting Bracket Before you start: Wall mounting bracket is not included in package. If you choose this mounting type, you have to prepare a bracket first. - Page 25 User Manual - Network Dome Camera – Figure 2-15 Size of the Mounting Base Steps: 1. Route the cables, install the wall mounting bracket, and secure the cap on the bracket. Wall Mounting Bracket Figure 2-16 Install Wall Mounting Bracket 2.
- Page 26 User Manual - Network Dome Camera – Mounting Base Figure 2-17 Install the Mounting Base 4. Align the camera with the mounting base, and secure the camera with screws. Figure 2-18 Secure the Camera 5. Connect the video output connector to the monitor. Connect the power connector to the power supply.
-
Page 27: Mounting With Pendant Mounting Bracket
User Manual - Network Dome Camera – 6. Adjust the image and focus. Please refer to the section 2.3 for more detailed information. 7. Install the inner black liner back to the camera. 8. Secure the bubble to the camera with screws. Figure 2-19 Secure Black Liner and Bubble 2.2.4 Mounting with Pendant Mounting Bracket... - Page 28 User Manual - Network Dome Camera – Figure 2-20 Size of the Mounting Base Steps: 1. Route the cables and Install the pendant mounting bracket. Secure the cap on the bracket. Pendant Mounting Bracket Figure 2-21 Install the Pendant Mounting Bracket 2.
- Page 29 User Manual - Network Dome Camera – 3. Secure the mounting base to the cap with screws. Mounting Base Figure 2-22 Install the Mounting Base 4. Align the camera with the mounting base, and secure the camera with screws.
-
Page 30: Mounting With Gang Box
User Manual - Network Dome Camera – Figure 2-23 Secure the Camera 5. Adjust the image and focus. Please refer to the section 2.3 for more detailed information. 6. Install the inner black liner back to the camera. 7. Secure the bubble to the camera with screws. Figure 2-24 Secure Black Liner and Bubble 2.2.5 Mounting with Gang Box... - Page 31 User Manual - Network Dome Camera – Gang Box Mounting Base Figure 2-25 Install the Mounting Base 3. Route the cables through the hole in the center of the mounting base. 4. Align the camera with the mounting base. And secure the camera with screws.
-
Page 32: Image And Focus Adjusting
User Manual - Network Dome Camera – 5. Adjust the image and focus. Please refer to the section 2.3 for more detailed information. 6. Install the inner black liner back to the camera. 7. Secure the bubble to the camera with screws. Figure 2-27 Secure the Black Liner and Bubble Image and Focus Adjusting Before you start:... -
Page 33: 3-Axis Adjustment
User Manual - Network Dome Camera – To a monitor Auxiliary Video Cable Auxiliary Video Output Figure 2-28 Connect Camera to a Monitor For certain camera models, the auxiliary video cable is not included in the package. Instead, you can connect the video out interface of the camera to a monitor for image and focus adjustment. -
Page 34: Zoom And Focus Adjustment
User Manual - Network Dome Camera – 3. Rotate the tilting axes to adjust the tilting position of the camera. 4. Rotate the lens table to adjust the azimuth angle of the image. Pan: 0° to 355° Tilt: 0° to 90° Rotate: 0°... - Page 35 User Manual - Network Dome Camera – Zoom/Focus Lever Figure 2-31 Zoom/Focus Lever 3. Tighten the zoom lever. 4. Loosen the focus lever and move the lever between F (Far) and N (Near) to obtain the optimum focus. 5. Tighten the focus lever. Type II: Type II camera is equipped with a motor-driven lens.
-
Page 36: Setting The Network Camera Over The Lan
User Manual - Network Dome Camera – 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. -
Page 37: Activating The Camera
User Manual - Network Dome Camera – Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via TKHSDM and Activation via Client Software are all supported. -
Page 38: Activation Via Tkhsdm Software
User Manual - Network Dome Camera – 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. - Page 39 User Manual - Network Dome Camera – Figure 3-4 TKHSDM Interface Note: The TKHSDM software supports activating the camera in batch. 3. Create a password and input the password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and...
-
Page 40: Modifying The Ip Address
User Manual - Network Dome Camera – You can check whether the activation is completed on the popup window. If activation failed, please make sure that the password meets the requirement and try again. Modifying the IP Address Purpose: To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your PC. - Page 41 User Manual - Network Dome Camera – Figure 3-5 Modify the IP Address 4. Input the password to activate your IP address modification. The batch IP address modification is supported by the TKHSDM.
-
Page 42: Accessing Via Web Browser
User Manual - Network Dome Camera – 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:... - Page 43 User Manual - Network Dome Camera – 4. Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.
- Page 44 User Manual - Network Dome Camera – Note: For detailed instructions of further configuration, please refer to the user manual of network camera.
