  • Page 1 USER MANUAL Network Speed Dome PD1103Z2-E/T V2017.1.001...
  • Page 2 User Manual - Network Speed Dome - Quick Start Guide About this Manual This Manual is applicable to Network Speed Dome. The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.

  • Page 3: Regulatory Information

    User Manual - Network Speed Dome - Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Safety Instruction

    User Manual - Network Speed Dome - Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death. Cautions: Neglecting any of the cautions may cause injury or equipment damage.
  • Page 5 User Manual - Network Speed Dome - The dome cover for indoor use shall be kept from rain and moisture. Exposing the equipment to direct sun light, low ventilation or heat source such as heater or radiator is forbidden (ignorance can cause fire danger). Do not aim the speed dome at the sun or extra bright places.

  • Page 6: Table Of Contents

    User Manual - Network Speed Dome - Table of Contents 1 Overview ...................... 1 1.1 Overview of Type I Speed Dome ................1 1.2 Overview of Type II Speed Dome ................2 1.3 Overview of Type III Speed Dome ................3 1.4 Overview of Type IV Speed Dome ................

  • Page 7: Overview

    User Manual - Network Speed Dome - 1 Overview Please turn the power off before connect the cables. The overview of different speed domes can be categorized into four types, refer to the content below for the details. The cables are distinguished by different colors. The labels attached on the cables are for identification.

  • Page 8: Overview Of Type Ii Speed Dome

    User Manual - Network Speed Dome - Table 1-1 Descriptions of Cable Interface Description Network Cable Audio Cable Alarm Output Cables Alarm Input Cables RS-485 Cables Video Cable Power Cable Micro SD Card Slot 1.2 Overview of Type II Speed Dome 2 types of the 6.5-inch speed dome structure are provided;...

  • Page 9: Overview Of Type Iii Speed Dome

    User Manual - Network Speed Dome - Table 1-2 Descriptions of Cable Interface Description Network Cable Audio Cable Alarm Out Alarm In RS-485 Video Cable Power Cable SD Card Slot 1.3 Overview of Type III Speed Dome SD CA RD Figure 1-4 Cable Interface of the Type III Speed Dome Table 1-3 Descriptions of Cable Interface Description...

  • Page 10: Overview Of Type Iv Speed Dome

    User Manual - Network Speed Dome - Description Video Cable Power Cable SD Card Slot 1.4 Overview of Type IV Speed Dome Figure 1-5 Cable Interface of the Type IV Speed Dome Table 1-4 Descriptions of Cable Interface Description Network Cable Video Cable Alarm Out Audio Cable...

  • Page 11: Installation

    User Manual - Network Speed Dome - 2 Installation Before you start: Make sure the device in the package is in good condition and all the assembly parts are included. The standard power supply is 12V DC or 24V AC, please make sure your power supply matches with your speed dome.

  • Page 12: Type I Speed Dome

    User Manual - Network Speed Dome - For cement wall, you need to use the expansion screw to fix the bracket. The mounting hole of the expansion pipe on the wall should align with the mounting hole on the bracket. For wooden wall, you can just use the self-tapping screw to fix the bracket.
  • Page 13 User Manual - Network Speed Dome - Figure 2-3 Remove the sticker for separated 5-inch speed dome Figure 2-4 Remove the Sticker for Integrated 5-inch speed dome 3. If the speed dome supports the PoE (Power Over Ethernet) function, you can switch the PoE+ and Hi-PoE function of the dome camera.
  • Page 14 User Manual - Network Speed Dome - If you choose Hi-PoE, a Hi-PoE adapter must be connected. Power supply via Hi-PoE is supported. The Hi-PoE module connection is shown below. 1: Power Indicator 2: PORT Indicator 3:DATA&POWER OUT 4: DATA IN Network Speed Ethernet Dome...
  • Page 15 User Manual - Network Speed Dome - 1). Hang the safety rope to the speed dome and the hook on the bracket as shown in Figure 2-8. 2). Route the cables of the speed dome through the bracket. 3). Connect the corresponding cables. Safety Rope Figure 2-8 Hang the Safety Rope 4).

  • Page 16: Type Ii Speed Dome

    User Manual - Network Speed Dome - Pendant Adapter Lock Screw Figure 2-10 Pendent Adapter 2.1.2 Type II Speed Dome The long-arm bracket is taken as the example for the following mounting steps. Steps: 1. Loosen the 4 lock screws on the flange of the speed dome; refer to the Figure 2-11. Lock Screws Figure 2-11 Loosen the Lock Screws Please do not remove the lock screws from the dome.
  • Page 17 User Manual - Network Speed Dome - Back Box Lens Cover Sticker Lower Dome Protective Foam Figure 2-12 Remove the Protective Elements 3. Install the micro SD card of the speed dome. Debug Reset SD Card Slot SD Card Slot Open Cover Figure 2-13 Install the SD Card.
  • Page 18 User Manual - Network Speed Dome - 2). Connect the corresponding cables. Figure 2-14 Hang the Safety Rope 3). Loosen the two lock screws on the bracket. 4). Install the speed dome to the bracket. Rotate the speed dome clockwise tightly. 5).

  • Page 19: Type Iii Speed Dome

    User Manual - Network Speed Dome - Pendant Adapter Lock Screw Figure 2-16 Pendent Adapter 2.1.3 Type III Speed Dome Steps: 1. Remove the protective sticker as shown in Figure 2-17. Protective Sticker Figure 2-17 Remove Protective Sticker 2. Remove the cover on the back of the speed dome as shown in Figure 2-18. Insert the SD card to the SD card slot and install the cover back.
  • Page 20 User Manual - Network Speed Dome - SD CARD SD Card Slot Figure 2-18 SD Card Slot 3. Refer to the steps 5-7 of the section 2.1.1 to install the bracket. 4. Hook the two ends of the safety rope to the back box of the speed dome and the bracket respectively.
  • Page 21 User Manual - Network Speed Dome - Figure 2-20 Install the Speed dome 7. Use L-wrench to tighten the lock screws to secure the speed dome and the bracket. Figure 2-21 Secure the Speed dome 8. Remove the protective film of the IR or laser light after you finish installing. The bracket in Figure 2-7 is the recommended bracket for this series of speed dome, and a pendent adapter is required if any other bracket is selected.

  • Page 22: Type Iv Speed Dome

    User Manual - Network Speed Dome - Pendant Adapter Lock Screw Figure 2-22 Pendent Adapter 2.1.4 Type IV Speed Dome Steps: 1. Remove the protective sticker as shown in Figure 2-23. Protective Sticker Figure 2-23 Remove Protective Sticker 2. Remove the cover on the back of the speed dome. Insert the SD card to the SD card slot and install the cover back.
  • Page 23 User Manual - Network Speed Dome - SD Card Slot Figure 2-24 SD Card Slot 3. Secure the bracket with 4 hex nuts and washers. Figure 2-25 Secure the Bracket 4. Apply thread tape to the thread of the head cover and rotate the head cover to the bracket.
  • Page 24 User Manual - Network Speed Dome - Figure 2-27 Buckle the Handle 6. Hook the two ends of the safety rope to the back box of the speed dome and the bracket respectively. 7. Hitch the speed dome onto the head cover with the hook on the back box. Hook Back Box Figure 2-28 Hang the Speed Dome...
  • Page 25 User Manual - Network Speed Dome - Figure 2-29 Route the Cables 9. Align the back box of the speed dome with the head cover. Use an Allen wrench to tighten the lock screws to secure the speed dome and the bracket. Lock Screw Figure 2-30 Secure the Speed dome 10.

  • Page 26: In-Ceiling Mounting

    User Manual - Network Speed Dome - Pendant Adapter Lock Screw Figure 2-31 Pendent Adapter 2.2 In-ceiling Mounting The in-ceiling mounting is only applicable for the 5-inch indoor speed domes. Before you start: The in-ceiling mounting is applicable to the indoor ceiling construction. The followings are the mandatory precondition for mounting: The height of the space above the ceiling must be more than 250mm.
  • Page 27 User Manual - Network Speed Dome - 4. Drill a hole on the ceiling according to the drill template (supplied). ±2mm of the diameter of the circle is tolerable. Figure 2-33 Draw and Cut a Hole on the Ceiling 5. Connect the cables. The video cable, control wire and network cable have been connected to the corresponding interfaces.

  • Page 28: Ceiling Mounting

    User Manual - Network Speed Dome - Ceiling Lock Figure 2-35 Install the back box 7. Install the flange. 1). Attach the flange to the lower dome and align the triangular notch of the trim ring with the arrow label on the in-ceiling bracket. 2).

  • Page 29: Removing The In-Ceiling Bracket

    User Manual - Network Speed Dome - 2.3.1 Removing the In-ceiling Bracket The ceiling mounting speed dome is installed with an in-ceiling bracket by default. Before you mount the speed dome on the ceiling, you need to remove the in-ceiling bracket first.

  • Page 30: Mounting

    User Manual - Network Speed Dome - Figure 2-39 Cabling for Ceiling Mounting 2.3.3 Mounting Before you start: If the speed dome is installed to the wooden wall, use the self-tapping screws to secure the mounting base. If the dome is installed to the cement wall, drill three 5 screw holes onto the wall according to the position of the holes, and then secure the mounting base to the wall with expansion screws.
  • Page 31 User Manual - Network Speed Dome - 3). Push the speed dome upwards and then forwards in the direction of arrow. When the speed dome is placed in position, the spring will automatically snap into the lock clip firmly. Refer to the 0. Push Forwards Line up Push Upwards...

  • Page 32: Setting The Dome Over The Lan

    User Manual - Network Speed Dome - 3 Setting the Dome over the LAN You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. If the product does not work properly, please contact with your dealer or the nearest service center.

  • Page 33: Activation Via Web Browser

    User Manual - Network Speed Dome - 3.2.1 Activation via Web Browser Steps: 1. Power on the speed dome, and connect the speed dome to the network. 2. Input the IP address into the address bar of the web browser, and click Enter to enter the activation interface.

  • Page 34: Modifying The Ip Address

    User Manual - Network Speed Dome - Figure 3-3 Interface 3. Create a password and input the password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 35 User Manual - Network Speed Dome - Please refer to section 3.2 to activate the speed dome if it is inactive. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Figure 3-4 Modify the IP Address 4.

  • Page 36: Accessing Via Web Browser

    User Manual - Network Speed Dome - 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 7.0 and above version, Apple Safari 5.02 and above...
  • Page 37 User Manual - Network Speed Dome - You may have to close the web browser to finish the installation of the plug-in. Figure 4-2 Download Plug-in Figure 4-3 Install Plug-in 6. Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login.
  • Page 38 Zuidelijk Halfrond 4 - P.O. Box 415 2801 DD Gouda - 2800 AK Gouda - The Netherlands www.tkhsecurity.com...
