Huffy 214636E Owner's Manual

Portable system
Hide thumbs

Advertisement

Quick Links

Download this manual
© COPYRIGHT 2000 by HUFFY SPORTS
Portable System
Owners Manual
Customer Service Center
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
WARNING!
READ AND UNDERSTAND
OPERATOR'S MANUAL
BEFORE USING THIS UNIT.
FAILURE TO FOLLOW
OPERATING INSTRUCTIONS
COULD RESULT IN INJURY
OR DAMAGE TO PROPERTY.
Toll-Free Customer Service Number for U.S: 1-800-558-5234,
For Canada: 1-800-284-8339,
For Europe: 00 800 555 85234 (Sweden: 009 555 85234),
For Australia: 1-800-333 061
Internet Address: http://www.huffysports.com
• Two People
• Tape Measure
• Wood Board (Scrap)
• Wrenches: (Two) 7/16", 1/2", 9/16", 3/4" or Large and
Small Adjustable Wrenches
• Safety Goggles
• Sawhorse or Support Table
• Step Ladder 8 ft. (2.4 m)
• Garden Hose or Sand (225 lb.) (102 kg)
• Hammer
• Tape
• Phillips Head Screw Driver
1
REQUIRED TOOLS AND
MATERIALS:
03/04
P/N 214636E

Advertisement

loading
Need help?

Need help?

Do you have a question about the 214636E and is the answer not in the manual?

Questions and answers

Related Manuals for Huffy 214636E

Summary of Contents for Huffy 214636E

  • Page 1 • Step Ladder 8 ft. (2.4 m) • Garden Hose or Sand (225 lb.) (102 kg) • Hammer • Tape • Phillips Head Screw Driver For Canada: 1-800-284-8339, For Australia: 1-800-333 061 Internet Address: http://www.huffysports.com REQUIRED TOOLS AND MATERIALS: Small Adjustable Wrenches 03/04 P/N 214636E...

  • Page 2: Before You Start

    Verlängerungsvorrichtung und die verschiedenen Befestigungsteile fest miteinander verschraubt werden. Große Schrauben zur Probe in die großen Löcher der Verlängerungsrohre, Korbwandklammern und Dreiecksplatte stecken und diese vorsichtig in einer Kreisbewegung hin- und herbewegen, um eventuelle Farbrückstände aus den Bohrungen zu entfernen. P/N 214636E 03/04 any excess paint from holes if necessary.
  • Page 3 (Do not use salt.) • Use extreme caution if placing system on sloped surface. System may tip over more easily. In the U.S.:1-800-558-5234 and Canada: 1-800-284-8339 201241 2/99 03/04 P/N 214636E...

  • Page 4: Safety Instructions

    • If technical assistance is required, contact Huffy Sports. • Adult supervision is recommended when adjusting height. Most injuries are caused by misuse and/or not following instructions. P/N 214636E 03/04 PROPERTY DAMAGE AND WILL VOID WARRANTY. Use caution when using this system.
  • Page 5 WARRANTY CARD: Please remember to complete your product registration form either on-line at: www.huffysports.com or mail-in the enclosed postcard. For more information on assembly, placement, proper use, and maintenance, visit The American Basketball Council website at http://www.smarthoops.com. 03/04 P/N 214636E...
  • Page 6 Get to know the basic parts of your basketball system... FRONT BACKBOARD POLE FRONT PANEL BASE P/N 214636E 03/04...
  • Page 7 U.S. 1-800-558-5234; CANADA: 1-800-284-8339; http://www.huffysports.com PARTS LIST - (See Hardware Identifier) NOTE: Hardware kit is designed for more than one style of basketball system. Not all hardware will be used. * YOU MAY HAVE EXTRA PARTS WITH THIS MODEL. 03/04 P/N 214636E...
  • Page 8 HARDWARE IDENTIFIER (BOLTS & SCREWS) Item #29 (6) Item #7 (2) Item #23 (1) Item #48 (4) Item #16 (2) Item #12 (1) Item #40 (1) Item #50 (2) * You may have extra parts with this model. P/N 214636E 03/04...
  • Page 9 Item #31 (7) Item #8 (2) Item #18 (4) Item #47 (6) HARDWARE IDENTIFIER (PLASTIC SPACERS CAPS & CLIPS) Item #30 (4) Item #20 (2) Item #11(4) Item #42 (12)* Item #26 (4) Item #13 (2) Item #36 (2) 03/04 P/N 214636E...

  • Page 10: Section A: Assemble The Base

    TOOLS REQUIRED FOR THIS SECTION Wrenches (2) 1/2” (2) 3/4” And/Or: (2) Socket Wrenches and Sockets 1/2” 9/16” Extension P/N 214636E 03/04 HARDWARE USED IN THIS SECTION Phillips- Head Screwdriver Item #20 Item #13 Item #19 (not actual size)
  • Page 11 203452, Washer P/N 203218, Nut P/N 203100, Carriage Bolts P/N 203223 . Carriage Bolts P/N 203223 Pole Bracket P/N 201581 Washer P/N 203218 Hex Flange Nut P/N 203100 Base P/N 206620 Front Cover P/N 203218 Washer P/N 203218 Eye bolts P/N 203452 P/N 203100 03/04 P/N 214636E...
  • Page 12 Indicator P/N 204872 L a b e l , H e i g h t Indicator P/N 204872 Nut P/N 203100 Nut P/N 203100 P/N 214636E 03/04 Height Adjustment Rod P/N 904833 Handle, Right P/N 204856 Handle, Left P/N 204855...
  • Page 13 Center alignment slot of middle pole section (5) in a lower hole of top pole section (4) as shown. NOTE: POLE SECTIONS SHOULD HAVE A 3-1/2" (9 CM) MINIMUM OVERLAP. Tape (Not Supplied) WOOD SCRAP (NOT SUPPLIED) 03/04 P/N 214636E...
  • Page 14 3-1/2" (9 CM) MINIMUM OVERLAP. Install bolt (12) through bracket and bottom pole section (6) and secure with nut (10) as shown. Nut should be tightened until flush (even) with locknuts outer edge. P/N 214636E 03/04 WOOD SCRAP (NOT SUPPLIED)
  • Page 15 Install rod (9) through bottom pole section (6) as shown. Install large eye bolts (7) onto rod (9) as shown. Secure cover to rod (9) using washers (47) nuts (8) and nut covers (13) as shown. 03/04 P/N 214636E...
  • Page 16 Install pole mount bracket (15) and reinforcement bracket (49) with carriage bolts (16) as shown. Tighten flange nuts (14) completely. Attach spacers (20, 21) to pole mount bracket (15) with bolts (19), washers (17), and nuts (18) as shown. IMPORTANT!: Tighten just until washers (17) stop moving. P/N 214636E 03/04...
  • Page 17 (15) with carriage bolt (23) and nut (14) as shown. FIG. A IMPORTANT!: Loop end of pin lanyard (25) over carriage bolt (23) as it passes through the pole mount bracket (15) during this assembly. 03/04 P/N 214636E...
  • Page 18 Insert handle assembly through pole mount assembly as shown. Lock pole assembly in place at the 10’ (3.05 m) mark with pin (24). P/N 214636E 03/04...

  • Page 19: Section B: Attach The Backboard

    HARDWARE USED IN THIS SECTION Item #48 Item #28 Phillips- Head Screwdriver Item #55 Item #19 (not actual size) Item #30 Item #31 Item #61 Item #18 Item #26 Item #36 Item #40 Item #50 Item #42 03/04 Item #29 P/N 214636E...
  • Page 20 Assemble backboard brackets (27) using spacers (28), bolts (19), and nuts (18) as shown. P/N 214636E 03/04...
  • Page 21 Rim mounting nuts and bolts (48) supplied with rim hardware. DO NOT use washers (47) here on spring return style rims. Refer To Instructions Included With Rim Hardware For Rim Assembly. Install cover (1) over spring return mechanism as shown. 03/04 P/N 214636E...
  • Page 22 Attach upper elevator tubes (35) to backboard support brackets (27) using spacers (26 & 11)), bolt (29), and nut (31) as shown. NOTE: Peel protective film from surface of acrylic backboard prior to use. P/N 214636E 03/04...
  • Page 23 Push second “arm” back and into ram as shown. Twist “body” of clip slightly again to spread “arms” of clip. Clip “arms” must be flat and touching edge to edge as shown, not overlapping. CLIP “ARM” CLIP “BODY” 03/04 P/N 214636E...
  • Page 24 NET INSTALLATION SIDE VIEW NETCLIP Insert net into bottom of clip as shown. SIDE VIEW Twist net until it snaps into position. Net must be centered through clip. NETCLIP P/N 214636E 03/04...
  • Page 25 Install upper elevator tubes (35) to triangle plates (37) as shown. Install handle assembly to lower elevator tubes (32) using bolt (29), spacers (36), and nut (31) as shown. NOTE: Before going on to next step, set adjustable system assembly to the 10’ (3.05 m) setting. 03/04 P/N 214636E...
  • Page 26 (41) in place. Secure assembly to ground using rope (44) and tie down stake (45). CAUTION! ADD TWO GALLONS (7.6 LITERS) OF NON-TOXIC ANTIFREEZE IN SUB- FREEZING CLIMATES. P/N 214636E 03/04 WARNING! DO NOT LEAVE ASSEMBLY UNATTENDED WHEN EMPTY; IT MAY TIP OVER.

  • Page 27: Section C: Apply Height And Moving Label & Height Adjustment

    TWO PEOPLE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. NOTE: Peel protective film from surface of acrylic backboard prior to use. WARNING! DO NOT ALLOW CHILDREN TO ADJUST HEIGHT. 03/04 P/N 214636E...
  • Page 28 Anrufer in Europa: 00 800 555 85234 (Schweden: 009 555 85234) Für Australien: 1-800-333.061 - Internet-Adresse: Número telefónico gratuito de servicio al cliente en EE. UU.: 1-800-558-5234, para Canadá: 1-800-284-8339, para Europa: 00 800 555 85234 (Suecia: 009 555 85234), para Australia: 1-800-333 061 - Dirección en Internet: http://www.huffysports.com P/N 214636E 03/04 Système portable Manuel d'utilisation Service clientèle...
  • Page 29 AVANT VORDERSEITE PARTE FRONTAL SECTION DE POTEAU SUPÉRIEURE SECCIÓN SUPERIOR DEL POSTE SECTION DE POTEAU CENTRALE MITTLERES STANGENTEIL SECCIÓN MEDIA DEL POSTE SOCLE BASE BASE CHARIOT RÄDERGRUPPE CONJUNTO DEL CARRO PORTAMUELA CERCEAU KORBRAND BORDE OBERES STANGENTEIL 03/04 P/N 214636E...
  • Page 30 P/N 214636E 03/04...
