Electrolux EOB9956XAX Installation Instruction

EN

Installation Instruction

Warning! Before proceeding with installation, read
the safety information in the User Manual.
The oven is designed to be connected to 230 - 240V
~ (50Hz) electricity supply.
The oven has an easily accessible terminal block which
is marked as follows:
Letter L - Live terminal
Letter N - Neutral terminal
- Earth terminal
CAUTION!
This oven must be earthed!
The cable used to connect the oven to the electrical
For UK use only

Connection

Min. size
via
Cooker 2,5 mm²
Control
Circuit
It is necessary that you install a double pole switch
between the oven and the electricity supply (mains),
with a minimum gap of 3 mm between the switch
contacts and of a type suitable for the required load in
compliance with the current regulations.
The switch must not break the yellow and green earth
cable at any point.
Fuse
type
PVC / PVC min: 15 A
twin and max: 20 A
earth
After installation and connecting, the cable must
be placed so that it cannot at any point reach
a temperature of more than 50°C above the
ambient temperature.
Before the oven is connected, check that the
main fuse and the domestic installation can
support the load; and that the power supply is
properly earthed.
The manufacturer declines any responsibility
should these safety measures not be carried out.
Attention: The new appliance may only be installed and
connected by a registered expert.
Please comply with this. If you do not, any
damage resulting is not covered by the warranty.

Safety information for the installer

• The electrical installation is to be set up so
that the appliance can be isolated from the
mains with a minimum 3 mm all-pole contact
separation.
• Suitable separation devices include e.g.
cut-outs, fuses (screw fuses are to be taken
out of the holder), RCD's and contactors.
• Anti-shock protection must be provided by the
installation.
• The built-in unit must meet the stability
requirements of DIN 68930.
• Built-in ovens and built-in cooking surfaces
safety reasons, they must only be combined
with appliances from the same manufacturer.
