"EH" SHOWING ON MY COOLBOT DISPLAY

The Heater Mode Indicator light flashes rapidly.
EH means there is a problem with the HEATER cable (red tip cable).
● Unplug the HEATER from the CoolBot.
● Inspect the cable for possible damages in the cord or in the tip.
● Clean the plug end of the HEATER (jack connector) with a cotton cloth and re plug in the CoolBot a couple
times making sure it goes all the way in the port.
● If the error persists after 20 seconds, the HEATER cable is bad and needs replacement.
The CoolBot Pro does not have a workaround mode for a bad Heater Cable. DO NOT plug anything other than a
To order a replacement Heater under warranty (1 year) please contact our support team at support@storeitcold.com.
To purchase a new Heater please visit our parts page at:

REBOOTING THE COOLBOT PRO

From the CoolBot Pro Controller.
You can also reboot the CoolBot Pro Settings and Wi-Fi from the app (see page 19).
1. On the CoolBot Pro, press the left arrow button until the Program light is solidly lit. You will see the firmware
version on the display, currently "7.8".
2. Press the Checkmark button five times slowly, until you see "P1" on the display.
3. Press the Left Arrow a few times to get to the reset option you want:
•
P1: resets all settings (Same as Fr)
▪
Full factory reset of CoolBot and Jumper if the Jumper is connected.
▪
Factory Reset of the CoolBot only, if the Jumper is disconnected.
•
ES: escapes from this menu and returns to normal operation
•
CJ: clears the Jumper's (Wi-Fi radio) settings only. The Jumper HAS to be connected to the CoolBot Pro.
•
CE: Wi-Fi Mode disabled: Y=Not using Wi-Fi, N=Using Wi-Fi (See
•
CS: clears the CoolBot settings to defaults but keeps the Wi-Fi settings the same.
•
Fr: resets all settings (Same as P1)
4. Press Checkmark to select that reset option.
5. You will see a blinking "n" for "no". Press one of the arrow keys to change it to "y" for "yes."
6. Press Checkmark. The CoolBot will reset the selected settings.
7. If you chose P1, CJ, or Fr with the Jumper connected to the CoolBot, the CoolBot will switch to its Wi-Fi
Configuration mode. You should see the code "E0" on the display. This means the CoolBot pro and the Jumper
are ready to reconfigure the Wi-Fi connection.
8. The CoolBot set temp has been reset to factory setting of 42F, change it to your desired room temp.
IMPORTANT! If you are not using Wi-Fi and you have an EE showing on the display follow these steps:
1. Unplug the CoolBot Pro from the power supply
2. Disconnect the Jumper from the CoolBot – disconnect the Data Cable (if it was connected)
3. Plug your CoolBot Pro back in. You will see EE
4. Follow steps 1, 2, and 3 for rebooting the CoolBot Pro to get to the main program menu options
5. Scroll (with the arrows) to the CE option and select (checkmark) then choose (with the arrows): Y
6. Press Checkmark. Your CoolBot Pro should stop blinking and revert back to show the Room Temperature (It
is ready to use in the "No Wi-Fi Mode")
Rev: 2018 – 7A
ATTENTION!
replacement Heater Cable in the Heater port- it won't work!
©2018 Store It Cold, LLC
https://www.storeitcold.com/replacement-parts/
NOTE
NOTE
below)
23
