Store It Cold CoolBot Pro Manual

Hide thumbs Also See for CoolBot Pro:
1
2
3
4

Advertisement

Table of Contents

Temperature
Sensors
Qty
Item
1
CoolBot Pro
1
CoolBot Jumper
2
Temperature Sensors
1
Heater
1
Data Cable
1
Power Supply

BEFORE STARTING

•
Should I read this guide?
We also encourage you to visit our support page
•
What if I don't have Internet OR Wi-Fi?
a Wi-Fi connection just like the previous generation CoolBots. Go straight to the "INSTALLING YOUR COOLBOT PRO TO YOUR
A/C" Section of this Guide (page 3). NOTE: Your CoolBot Pro will keep your cooler cold but you won't be able to access online
data or change settings from the CoolBot Pro App.
•
I have an Internet connection AND Wi-Fi.
with the "CONNECTING YOUR COOLBOT PRO TO YOUR WI-FI NETWORK" Section of this Guide (page 2), and then move to the
"INSTALLING YOUR COOLBOT PRO TO YOUR A/C" Section of this Guide (page 3).
•
I am replacing my existing CoolBot with the new CoolBot Pro.
well as always grab a pen and write down the settings from your old CoolBot:
✓ Room Set Point: _______
✓ Fins Setting: _______
✓ Heater delay: _______
CoolBot Pro Quick Start Set Up Guide Rev 2019 – 03A
CoolBot Pro
Heater
Patented Digital Temperature Controller
Wi-Fi Radio Signal Module
Sensor Cables (Blue Cable - Black Tip) with external 2.5mm jack connector
CoolBot Heater Cable (Black Cable - Red Tip) with external 2.5mm jack connector
Data Transfer Cable (Silver or Grey) with RJ11 connector on both ends
Mini-USB port connector cable. Input: 110V-240V / Output: 5V, 1Amp
Yes! We highly recommend reading this "Step by Step" guide entirely to ensure proper installation.
www.storeitcold.com/support
No problem! You can still use the CoolBot Pro without the CoolBot Jumper and without
Awesome! Then you will enjoy all of the benefits the CoolBot Pro and its app. Start
Push either arrow key on your CoolBot until the Room Mode light is lit. Press
the checkmark and the current setpoint will blink.
Push either arrow key on your CoolBot until the Fins Mode light is lit. Press
the checkmark and the current Fins Setting will blink.
Push either arrow key on your CoolBot until the Heater Mode light is lit. Press
the checkmark three times and the current Heater Delay Setting will blink.
CoolBot Jumper
Power Supply
Description
and read the detailed CoolBot Pro Manual.
No biggie! To ensure your cooler will continue performing just as
Data Cable
1 |
P a g e
©2019 Store It Cold, LLC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CoolBot Pro and is the answer not in the manual?

Questions and answers

Related Manuals for Store It Cold CoolBot Pro

Summary of Contents for Store It Cold CoolBot Pro

  • Page 1 Wi-Fi connection just like the previous generation CoolBots. Go straight to the “INSTALLING YOUR COOLBOT PRO TO YOUR A/C” Section of this Guide (page 3). NOTE: Your CoolBot Pro will keep your cooler cold but you won’t be able to access online data or change settings from the CoolBot Pro App.
  • Page 2 STEP 1 Unpack the CoolBot Pro in an area with good Wi-Fi reception (outside of your cooler and close to your Router is best). Plug in the Temperature Sensors and the Heater Cable into the corresponding ports (See diagram on page 4). Don’t connect the cables to your A/C and don’t plug in the power supply.
  • Page 3 STEP 1 Plug the cables into the corresponding labeled ports at the bottom of the CoolBot Pro except for the Data Cable. If you are replacing an existing CoolBot with “removable” cables, use all your new cables and save the old cables as spare parts. The CoolBot Pro works with both black and blue Temperature Sensor Cables.
  • Page 4 P a g e CoolBot Pro Quick Start Set Up Guide Rev 2019 – 03A ©2019 Store It Cold, LLC...
