HIKVISION DS-7116HQHI-K1 User Manual

Ds-7100hqhi-k1 series; ds-7200hqhi-k1 series; ds-7200hqhi-k2 series; ds-7200hqhi-k/p series; ds-7200huhi-k1 series; ds-7200huhi-k2 series; ds-7200huhi-k/p series; ds-7300hqhi-k4 series; ds-8100hqhi-k8 series; ds-7300huhi-k4 series; ds-8100huhi-k8 series;
Hide thumbs Also See for DS-7116HQHI-K1:
Table of Contents

Advertisement

Quick Links

Network Video Recorder
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-7116HQHI-K1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HIKVISION DS-7116HQHI-K1

Summary of Contents for HIKVISION DS-7116HQHI-K1

  • Page 1 Network Video Recorder User Manual...
  • Page 2 INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

  • Page 3: Regulatory Information

    Network Video Recorder User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 4 Network Video Recorder User Manual Applicable Models This manual is applicable to the models listed in the following table. Series Model DS-7104HQHI-K1 DS-7100HQHI-K1 DS-7108HQHI-K1 DS-7116HQHI-K1 DS-7204HQHI-K1 DS-7200HQHI-K1 DS-7208HQHI-K1 DS-7216HQHI-K1 DS-7208HQHI-K2 DS-7216HQHI-K2 DS-7200HQHI-K2 DS-7224HQHI-K2 DS-7232HQHI-K2 DS-7204HQHI-K1/P DS-7200HQHI-K/P DS-7208HQHI-K2/P DS-7216HQHI-K2/P DS-7204HUHI-K1 DS-7200HUHI-K1...
  • Page 5 Network Video Recorder User Manual DS-7332HQHI-K4 DS-8124HQHI-K8 DS-8100HQHI-K8 DS-8132HQHI-K8 DS-7304HUHI-K4 DS-7308HUHI-K4 DS-7300HUHI-K4 DS-7316HUHI-K4 DS-7324HUHI-K4 DS-7332HUHI-K4 DS-8124HUHI-K8 DS-8100HUHI-K8 DS-8132HUHI-K8 DS-9008HUHI-K8 DS-9016HUHI-K8 DS-9000HUHI-K8 DS-9024HUHI-K8 DS-9032HUHI-K8 DS-7200HTHI-K1 DS-7204HTHI-K1 DS-7204HTHI-K2 DS-7200HTHI-K2 DS-7208HTHI-K2 iDS-7316HUHI-K4/16S DeepinMind Series DVR iDS-9016HUHI-K8/16S Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Provides additional information to emphasize or supplement...

  • Page 6: Safety Instructions

    Network Video Recorder User Manual Safety Instructions  Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user.  In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region.

  • Page 7: Product Key Features

    Network Video Recorder User Manual Product Key Features General  Connectable to Turbo HD and analog cameras;  Supports UTC (Coaxitron) protocol for connecting camera over coax;  Connectable to AHD cameras;  Connectable to HDCVI cameras;  Connectable to IP cameras; ...
  • Page 8 Network Video Recorder User Manual Local Monitoring  For DS-7300/8100/9000HUHI-K, DS-7324/7332/8124/8132HQHI-K, and DeepinMind series, there are two HDMI interfaces of which the HDMI 1 and VGA interfaces share simultaneous output. For HDMI1/VGA output, up to 1920 × 1080 resolution is supported. For HDMI 2 output, up to 4K (3840 ×...
  • Page 9  Several PTZ protocols (including Omnicast VMS of Genetec) supported; PTZ preset, patrol and pattern;  Zooming in/out by clicking the mouse and PTZ tracing by dragging mouse;  When Hikvision CVBS camera is connected, you can control PTZ via Coaxitron and call the OSD of the camera. HDD Management ...
  • Page 10 Network Video Recorder User Manual  Main stream and sub-stream configurable for simultaneous recording;  Pre-record and post-record for motion detection triggered recording, and pre-record time for schedule and manual recording;  Searching record files and captured pictures by events (alarm input/motion detection); ...
  • Page 11 Network Video Recorder User Manual  System will automatically reboot when a problem is detected in an attempt to restore normal functionality;  You can enable false alarm filer for the motion detection of the PIR cameras. Then only when the motion detection events and PIR events are both triggered, the motion detection alarm will be triggered.
  • Page 12 Network Video Recorder User Manual  Supports upgrading via remote FTP server;  RS-485 transparent channel transmission;  Alarm and exception information can be sent to the remote host;  Remotely start/stop recording;  Remotely start/stop alarm output;  Remote PTZ control; ...

  • Page 13: Table Of Contents

    Network Video Recorder User Manual TABLE OF CONTENTS Product Key Features ........................6 Chapter 1 Introduction ........................19 Front Panel ........................19 DS-7100HQHI-K1 ..................... 19 DS-7300HQHI-K4, DS-7300HUHI-K4, and iDS-7316HUHI-K4/16S ......19 DS-8100HQHI/HUHI-K8 ................... 23 DS-9000HUHI-K8 and iDS-9016HUHI-K8/16S ............24 Other Models ......................27 IR Remote Control Operations ..................
  • Page 14 Network Video Recorder User Manual Configure Unlock Pattern for Login .................. 44 Login to the Device ......................46 Log in via Unlock Pattern..................46 Log in via Password ....................46 Enter Wizard to Configure Quick Basic Settings ............... 47 Enter Main Menu ......................51 System Operation ......................
  • Page 15 Network Video Recorder User Manual Using an Auxiliary Monitor....................69 Chapter 6 PTZ Control ........................70 PTZ Control Wizard ......................70 Configure PTZ Parameters ....................70 Set PTZ Presets, Patrols & Patterns .................. 71 Set a Preset ......................71 Call a Preset ......................72 Set a Patrol ......................
  • Page 16 Network Video Recorder User Manual Configure Redundant Recording and Capture ............... 93 Configure 1080p Lite ...................... 94 Enable the 1080P Lite Mode ................. 94 Disable the 1080P Lite Mode ................95 Chapter 8 Disk Array ........................96 Create Disk Array ......................96 Enable RAID ......................
  • Page 17 Network Video Recorder User Manual Play Event Files ....................112 Play by Sub-periods ..................... 113 Play Log Files ....................... 114 Play External File ....................114 Playback Operations ..................... 115 Set Play Strategy in Smart/Custom Mode ............115 Edit Video Clips....................116 Switch between Main Stream and Sub-Stream ..........
  • Page 18 Network Video Recorder User Manual Chapter 13 VCA Event Alarm ..................... 138 Human Body Detection ....................138 Face Detection......................139 Vehicle Detection ......................140 Line Crossing Detection ....................141 Intrusion Detection ...................... 143 Region Entrance Detection ..................144 Region Exiting Detection ....................145 Unattended Baggage Detection ...................
  • Page 19 Network Video Recorder User Manual Configure Ports ......................170 Chapter 17 System Maintenance ....................172 Storage Device Maintenance ..................172 Configure Disk Clone ................... 172 S.M.A.R.T Detection .................... 173 Bad Sector Detection ..................174 HDD Health Detection ..................175 Search & Export Log Files ..................... 176 Search the Log Files .....................

  • Page 20: Chapter 1 Introduction

    Network Video Recorder User Manual Chapter 1 Introduction Front Panel DS-7100HQHI-K1 Front Panel of DS-7100HQHI-K1 Table 1-1 DS-7100HQHI-K1 Front Panel Description No. Icon Description Turns red when DVR is powered up. Turns red when data is being read from or written to HDD.
  • Page 21 Network Video Recorder User Manual Table 1-2 DS-7300HQHI-K4 Front Panel Description No. Name Function Description Turns green when DVR is powered up. POWER Turns green, indicating that the DVR is functioning READY properly. Turns green when device is controlled by an IR remote.
  • Page 22 Network Video Recorder User Manual No. Name Function Description Switches between main and spot video output in live view or playback mode. Enters numeral “3”; Enters letters “DEF”; 3/DEF/F2 Uses the F2 button is used to change the tab pages; Zooms in the image in PTZ control mode.
  • Page 23 Network Video Recorder User Manual No. Name Function Description Enters numeral “8”; 8/TUV/PTZ Enters letters “TUV”; Accesses PTZ control interface. Enters numeral “9”; 9/WXYZ/PREV Enters letters “WXYZ”; Multi-channel display in live view. Enters numeral “0”; Shifts the input methods in the editing text field. (Upper and lowercase, alphabet, symbols or numeric input).

  • Page 24: Ds-8100Hqhi/Huhi-K8

    Network Video Recorder User Manual No. Name Function Description Stops/starts auto switch in Auto-switch mode. POWER Power on/off switch. Moves the active selection up and down in a menu. Cycles through different channels in live view mode. Jumps 30s forward/backward in video files in the JOG SHUTTLE Control playback mode.

  • Page 25: Ds-9000Huhi-K8 And Ids-9016Huhi-K8/16S

    Network Video Recorder User Manual DS-9000HUHI-K8 and iDS-9016HUHI-K8/16S Front Panel of DS-9000HUHI-K8 and iDS-9016HUHI-K8/16S Table 1-3 DS-8100HQHI/HUHI-K8, DS-9000HUHI-K8, and iDS-9016HUHI-K8/16S Front Panel Description No. Name Function Description Turns red when a sensor alarm is detected. ALARM Turns blue, indicating that the DVR is functioning properly. READY Turns blue when device is controlled by an IR remote.
  • Page 26 Network Video Recorder User Manual Switches to the corresponding channel in live view or PTZ control mode. Inputs numbers and characters in edit mode. Alphanumeric Buttons Switches between different channels in playback mode. Turns blue when the corresponding channel is recording; turns red when the channel is in network transmission status;...
  • Page 27 Network Video Recorder User Manual Generates video clips for backup in playback mode. Enters/exits the folder of USB device and eSATA HDD. Switches between main and spot output. MAIN/SPOT/ZOOM- Zooms out the image in PTZ control mode. Selects all items on the list when used in a list field. F1/ LIGHT Turns on/off PTZ light (if applicable) in PTZ control mode.

  • Page 28: Other Models

    Network Video Recorder User Manual Cycles through channels in Live View mode. Controls the movement of the PTZ camera in PTZ control mode. Confirms selection in any of the menu modes. Checks the checkbox. Plays or pauses the playing of video files in Playback mode. ENTER Advances the video by a single frame in single-frame Playback mode.

  • Page 29: Ir Remote Control Operations

    Network Video Recorder User Manual Table 1-4 Front Panel of Other Models Description No. Icon Description Turns white when DVR is powered up. Turns red when data is being read from or written to HDD. Flashes white when the network is well-connected. Receiver for IR remote control.

  • Page 30: Unpair (Disable) An Ir Remote From A Device

    Network Video Recorder User Manual Remote Control Unpair (Disable) an IR Remote from a Device To unpair an IR Remote from a device so that the unit cannot control any device functions, proceed as follows: Press the DEV key on the IR Remote. Any existing Device ID# will be erased from the unit’s memory and it will no longer function with the device.
  • Page 31 Network Video Recorder User Manual No. Name Function Description •To Turn Power On: -If User Has Not Changed the Default device ID# (255): 1.Press Power On/Off button (1). -If User Has Changed the device ID#: 1.Press DEV button. 2.Press Number buttons to enter user-defined Device ID#. 3.Press Enter button.
  • Page 32 Network Video Recorder User Manual Enable IR Remote: Press DEV button, enter device ID# with number keys, press Enter to pair unit with the device Disable IR Remote: Press DEV button to clear Device ID#; unit will no longer be paired with the device Switch to the corresponding channel in Live View or PTZ Control mode Numerals...

  • Page 33: Troubleshooting

    Network Video Recorder User Manual Checks checkbox Play or pause video in Playback mode Advance video a single frame in single-frame Playback mode Stop/start auto switch in auto-switch mode Enter PTZ Control mode Go back to previous screen RESERVED Reserved Select all items on a list Switch between play and reverse play in Playback mode PTZ Control Adjust PTZ camera iris, focus, and zoom...

  • Page 34: Usb Mouse Operation

    Network Video Recorder User Manual  Batteries are fresh and not out of charge.  IR receiver is not obstructed.  No fluorescent lamp is used nearby If the remote still can’t function properly, please change a remote and try again, or contact the device provider.

  • Page 35: Rear Panel

    Network Video Recorder User Manual Rear Panel The rear panel varies according to different models. Please refer to the actual product. The following figures are for reference only. DS-7100HQHI-K1 Rear Panel of DS-7100HQHI-K1 DS-7200HUHI-K Rear Panel of DS-7200HUHI-K DS-7200HUHI-K/P Rear Panel of DS-7200HUHI-K/P...

  • Page 36: Ds-7200Hthi-K1

    Network Video Recorder User Manual DS-7200HTHI-K1 Rear Panel of DS-7200HTHI-K1 DS-7200HTHI-K2 Rear Panel of DS-7200HTHI-K2 DS-7200HQHI-K (with 16 Video Inputs) Rear Panel of DS-7200HQHI-K (with 16 Video Inputs) DS-7200HQHI-K (with 32 Video Inputs) Rear Panel of DS-7200HQHI-K (with 32 Video Inputs)

  • Page 37: Ds-7200Hqhi-K/P

    Network Video Recorder User Manual DS-7200HQHI-K/P Rear Panel of DS-7200HQHI-K/P Description of Rear Panel No. Item Description VIDEO IN BNC interface for Turbo HD and analog video input. AUDIO IN RCA connector AUDIO OUT RCA connector. DB15 connector for VGA output. Display local video output and menu.

  • Page 38: Ds-7300Hqhi-K (With 16 Video Inputs)

    Network Video Recorder User Manual DS-7300HQHI-K (with 16 Video Inputs) Rear Panel of DS-7300HQHI-K (with 16 Video Inputs) Description of DS-7300HQHI-K Rear Panel No. Item Description VIDEO IN BNC interface for Turbo HD and analog video input. VIDEO OUT BNC connector for video output. AUDIO IN RCA connector USB Port...

  • Page 39: Ds-7300Huhi-K4 (With 16 Video Inputs) And Ids-7316Huhi-K4/16S

    Network Video Recorder User Manual No. Item Description Power Switch Switch for turning on/off the device. Ground LINE IN BNC connector for audio input. eSATA Connects external SATA HDD, CD/DVD-RW. RS-232 Interface Connector for RS-232 devices. DS-7300HUHI-K4 (with 16 Video Inputs) and iDS- 7316HUHI-K4/16S Rear Panel of DS-7300HUHI-K4 (with 16 Video Inputs) DS-9000HUHI-K8 (with 8 Video Inputs)
  • Page 40 Network Video Recorder User Manual No. Item Description LOOP OUT (for DS- 9000HUHI-K8) USB Port Universal Serial Bus (USB) port for additional devices. Simultaneous HDMI1/VGA output. Display local video output and HDMI1/VGA menu. HDMI2 HDMI2 video output connector. AUDIO OUT RCA connector.

  • Page 41: Ds-7300Hqhi-K4 (With 32-Ch Video Inputs)

    Network Video Recorder User Manual DS-7300HQHI-K4 (with 32-ch Video Inputs) Rear Panel of DS-7300HQHI-K4 (with 32-ch Video Inputs) DS-7300HUHI-K4 (with 32-ch Video Inputs) Rear Panel of DS-7300HUHI-K4 (with 32-ch Video Inputs) DS-8100HQHI/HUHI-K8 (with 32-ch Video Inputs) Rear Panel of DS-8100HQHI/HUHI-K8 (with 32-ch Video Inputs) DS-9000HUHI-K8 (with 32-ch Video Inputs) Rear Panel of DS-9000HUHI-K8 (with 32-ch Video Inputs)

  • Page 42: Ids-9016Huhi-K8/16S

    Network Video Recorder User Manual iDS-9016HUHI-K8/16S Rear Panel of iDS-9016HUHI-K8/16S Description of DS-7300HQHI-K4, DS-7300HUHI-K4, DS-8100HQHI/HUHI-K8, DS-9000HUHI- K8, and iDS-9016HUHI-K8/16S Rear Panel No. Item Description VIDEO IN BNC interface for Turbo HD and analog video input. AUDIO IN RCA connector. LINE IN BNC connector for audio input.
  • Page 43 Network Video Recorder User Manual No. Item Description HDMI1 Interface HDMI1 video output connector. Display local video output and menu. HDMI2 Interface HDMI2 video output connector. Network Connector for network. Interface USB Interface Universal Serial Bus (USB) port for additional devices. Ground Power Supply 100 to 240 VAC power supply.

  • Page 44: Chapter 2 Getting Started

    Network Video Recorder User Manual Chapter 2 Getting Started Start up the Device Purpose: Proper startup and shutdown procedures are crucial to expanding the life of the device. Before you start: Check that the voltage of the extra power supply is the same with the device’s requirement, and the ground connection is working properly.

  • Page 45: Configure Unlock Pattern For Login

    Network Video Recorder User Manual Setting Admin Password We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the security of your product. And we recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product.
  • Page 46 Network Video Recorder User Manual After the device is activated, you can enter the following interface to configure the device unlock pattern. Use the mouse to draw a pattern among the 9 dots on the screen. Release the mouse when the pattern is done. Draw the Pattern ...

  • Page 47: Login To The Device

    Network Video Recorder User Manual Login to the Device Log in via Unlock Pattern  Only the admin user has the permission to unlock the device.  Please configure the pattern first before unlocking. Please refer to 2.2 Activate the Device. Right click the mouse on the screen and select the menu to enter the interface.

  • Page 48: Enter Wizard To Configure Quick Basic Settings

    Network Video Recorder User Manual Select the User Name in the dropdown list. Login Interface Input password. Click OK to log in.  When you forget the password of the admin, you can click Forgot Password to reset the password. ...
  • Page 49 Network Video Recorder User Manual Date and Time Settings After the time settings, click Next to enter the Network Setup Wizard window, as shown in the following figure. Network Settings Click Next after you configured the network parameters, which takes you to the HDD Management window.
  • Page 50 Network Video Recorder User Manual HDD Management To initialize the HDD, click the Init button. Initialization removes all the data saved in the HDD. Click Next. You enter the Camera Setup interface to add the IP cameras. 1) Click Search to search the online IP Camera. Before adding the camera, make sure the IP camera to be added is in active status.
  • Page 51 Network Video Recorder User Manual Hik-Connect Access Click Next to enter the Change Password interface to create the new admin password if required. Change Password You can enter click the to show the characters input. Check the checkbox of New Admin Password. Enter the original password in the text field of Admin Password Input the same password in the text field of New Password and Confirm.

  • Page 52: Enter Main Menu

    Network Video Recorder User Manual We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the security of your product. And we recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product.

  • Page 53: System Operation

    Network Video Recorder User Manual System Maintenance: System Operation Log out Purpose: After logging out, the monitor turns to the live view mode and if you want to perform any operations, you need to enter user name and password to log in again. Click on the menu bar.

  • Page 54: Chapter 3 Camera Management

    Network Video Recorder User Manual Chapter 3 Camera Management Add the IP Cameras Add the IP Camera Manually Purpose: Before you can get live video or record the video files, you should add the network cameras to the connection list of the device. Before you start: Ensure the network connection is valid and correct, and the IP camera to add has already been activated.

  • Page 55: Add The Automatically Searched Online Ip Cameras

    Network Video Recorder User Manual Click Add to finish the adding of the IP camera. (Optional) Click Continue to Add to continue to add other IP cameras. Add the Automatically Searched Online IP Cameras On the IP Camera interface, click the Number of Unadded Online Device to expand the panel.

  • Page 56: Configure Signal Input Channel

    AT camera is connected, it is powered on normally. Step 3 Check the connected AF or AT camera number and the connectable camera number.  Only Hikvision PoC camera is supported.  The maximum connectable AT/AF camera number varies with different models.

  • Page 57: Configuring 5 Mp Long Distance Transmission

    Network Video Recorder User Manual Signal Input Status (for Other DS-7300/9000HUHI Series) Check the checkbox to select different signal input types: HD/CVBS and IP. If you select HD/CVBS, four types of analog signal inputs including Turbo HD, AHD, HDCVI, and CVBS can be connected randomly for the selected channel.

  • Page 58: Enable The H.265 Stream Access

    Network Video Recorder User Manual 5 MP Long Distance Transmission Settings Select channel(s) to enable 5 MP Long Distance Transmission. Click OK. Click Apply to save the settings. Enable the H.265 Stream Access The device can automatically switch to the H.265 stream of IP camera (which supports H.265 video format) for the initial access.

  • Page 59: Configure The Customized Protocols

    Network Video Recorder User Manual Select the firmware upgrade file from the U-flash drive. Click Upgrade. Result: The IP camera will reboot automatically after the upgrading completes. Configure the Customized Protocols Purpose To connect the network cameras which are not configured with the standard protocols, you can configure the customized protocols for them.
  • Page 60 Network Video Recorder User Manual  Example: rtsp://192.168.1.55:554/ch1/main/av_stream. The protocol type and the transfer protocols must be supported by the connected IP camera. Click OK to save the settings. Result: After adding the customized protocols, you can see the protocol name is listed in the drop-down list.

  • Page 61: Chapter 4 Camera Settings

    Network Video Recorder User Manual Chapter 4 Camera Settings Configure OSD Settings Purpose: You can configure the OSD (On-screen Display) settings for the camera, including date/time, camera name, etc. Click on the main menu bar. Click Display. Select the camera from the drop-down list. Edit the name in the Camera Name text field.

  • Page 62: Configure Privacy Mask

    Network Video Recorder User Manual Click the Apply button to apply the settings. Configure Privacy Mask Purpose: The privacy mask can be used to protect personal privacy by concealing parts of the image from view or recording with a masked area. Click on the main menu bar.

  • Page 63: Configure The Video Parameters

    Network Video Recorder User Manual The configured privacy mask zones on the window can be cleared by clicking the corresponding Clear Zone1-4 icons on the right side of the window, or click Clear All to clear all zones. Click Apply to save the settings. Configure the Video Parameters Purpose: You can customize the image parameters including the brightness, contrast, saturation for the live...

  • Page 64: Configure Other Camera Parameters

    Network Video Recorder User Manual Configure Other Camera Parameters For the connected camera, you can configure the camera parameters including the exposure mode, backlight and image enhancement. Click on the main menu bar. Click Display. Select the camera from the drop-down list. Configure the camera parameters.

  • Page 65: Chapter 5 Live View

    Network Video Recorder User Manual Chapter 5 Live View Live view shows you the video image getting from each camera in real time. Start Live View Click on the main menu bar to enter the live view.  You can select a window and double click a camera from the list to play the video from the camera in the selected window.

  • Page 66: Target Detection

    Network Video Recorder User Manual Select the live view strategy to Real-time, Balanced or Fluency. Target Detection In live view mode, the target detection function can be used to detect the human motion/face/vehicle/human body during the last 5 seconds and the following 10 seconds. In the live view mode, click Target Detection tab to enter the target detection interface.

  • Page 67: Configure Live View Layout

    Network Video Recorder User Manual Go to System > Live View > General. Live View-General Configure the live view parameters.  Video Output Interface: Select the video output to configure.  Live View Mode: Select the display mode for live view, e.g., 2*2, 1*5, etc. ...
  • Page 68 Network Video Recorder User Manual Live View Select the video output interface, e.g., HDMI/ VGA or channel-zero. Select a window division mode from the toolbar. Select a division window, and double-click on the camera from the list to set the camera to the window.

  • Page 69: Configure Auto-Switch Of Cameras

    Network Video Recorder User Manual Configure Auto-Switch of Cameras You can set the auto-switch of cameras to play in different display modes. Go to System > Live View > General. Set the video output interface, live view mode and dwell time. ...

  • Page 70: Using An Auxiliary Monitor

    Network Video Recorder User Manual Result: You can view all of the channels in one screen using the CMS or web browser. Using an Auxiliary Monitor Certain features of the Live View are also available while in an Aux monitor. These features include: ...

  • Page 71: Chapter 6 Ptz Control

    Network Video Recorder User Manual Chapter 6 PTZ Control PTZ Control Wizard Before you start Please make sure the connected IP camera supports the PTZ function and is properly connected. Purpose Follow the PTZ control wizard to guide you through the basic PTZ operation. Click on the quick settings toolbar in the live view interface.

  • Page 72: Set Ptz Presets, Patrols & Patterns

    Network Video Recorder User Manual Click PTZ Parameters Settings to set the PTZ parameters. PTZ Parameters Settings Edit the parameters of the PTZ camera. All the parameters should be exactly the same as the PTZ camera parameters. Click OK to save the settings. Set PTZ Presets, Patrols &...

  • Page 73: Call A Preset

    Network Video Recorder User Manual Click in the lower right corner of live view to set the preset. Set Preset Select the preset No. (1~255) from the drop-down list. Enter the preset name in the text field. Click Apply to save the preset. Repeat steps 2-6 to save more presets.

  • Page 74: Set A Patrol

    Network Video Recorder User Manual Set a Patrol Purpose: Patrols can be set to move the PTZ to different key points and have it stay there for a set duration before moving on to the next key point. The key points are corresponding to the presets. Click on the quick settings toolbar in the live view interface..

  • Page 75: Call A Patrol

    Network Video Recorder User Manual Key Point Configuration 1) Configure key point parameters. Preset: It determines the order at which the PTZ will follow while cycling through the patrol. Speed: It defines the speed at which the PTZ will move from one key point to the next. Duration: It refers to the time span to stay at the corresponding key point.

  • Page 76: Set A Pattern

    Network Video Recorder User Manual Click on the quick settings toolbar in the live view interface.. The PTZ control panel displays on the right of the interface. Click Patrol on the PTZ control panel. Patrol Configuration Select a patrol in the text field. Click Call to call it.

  • Page 77: Call A Pattern

    Network Video Recorder User Manual Call a Pattern Purpose: Follow the procedure to move the PTZ camera according to the predefined patterns. Click on the quick settings toolbar in the live view interface. The PTZ control panel displays on the right of the interface. Click Pattern to configure pattern.

  • Page 78: Call Linear Scan

    180º. Call Linear Scan Before operating this function, make sure the connected camera supports the linear scan and is in HIKVISION protocol. Purpose: Follow the procedure to call the linear scan in the predefined scan range.

  • Page 79: Auxiliary Functions

    Network Video Recorder User Manual The park time can only be set via the speed dome configuration interface. The value is 5s by default. Click Stop Park (Quick Patrol), Stop Park (Patrol 1) or Stop Park (Preset 1) to inactivate it. Auxiliary Functions Before you start Please make sure the connected IP camera supports the PTZ function, and is properly connected.

  • Page 80: Chapter 7 Storage

    Network Video Recorder User Manual Chapter 7 Storage Storage Device Management Install the HDD Before startup of the device, install and connect the HDD to the device. Refer to the Quick Start Guide for the installation instructions. Add the Network Disk You can add the allocated NAS or disk of IP SAN to device, and use it as network HDD.
  • Page 81 Network Video Recorder User Manual Select the NAS disk from the list, or you can manually enter the directory in the text field of NetHDD Directory. Click OK to complete the adding of the NAS disk. Result: After having successfully added the NAS disk, return to the HDD Information menu. The added NetHDD will be displayed in the list.

  • Page 82: Configure Esata For Data Storage

    Network Video Recorder User Manual Add IP SAN Disk Result: After having successfully added the IP SAN disk, return to the HDD Information menu. The added NetHDD will be displayed in the list. If the installed HDD or NetHDD is uninitialized, please select it and click Init for initialization. Configure eSATA for Data Storage When there is an external eSATA device connected to device, you can configure eSATA for the data storage, and you can manage the eSATA in the device.

  • Page 83: Storage Mode

    Network Video Recorder User Manual When Usage type is selected to Record/Capture, enter the storage device interface. Edit the property of the selected eSATA, or initialize it is required. Storage Mode Configure HDD Group Purpose: Multiple HDDs can be managed in groups. Video from specified channels can be recorded onto a particular HDD group through HDD settings.
  • Page 84 Network Video Recorder User Manual Local HDD Settings Select the Group number for the current HDD. Click OK. Regroup the cameras for HDD if the HDD group number is changed. Go to Storage> Storage Mode. Select Mode to Group. Select the group No. from Record on HDD Group. Select the IP camera(s) to record/capture on the HDD group.

  • Page 85: Configure Hdd Quota

    Network Video Recorder User Manual Storage Mode-HDD Group Click Apply. Reboot the device to activate the new storage mode settings. Configure HDD Quota Purpose: Each camera can be configured with allocated quota for the storage of recorded files or captured pictures.

  • Page 86: Recording Parameters

    Network Video Recorder User Manual Storage Mode-HDD Quota (Optional) You can click Copy to if you want to copy the quota settings of the current camera to other cameras. Click Apply to apply the settings. Reboot the device to activate the new storage mode settings.

  • Page 87: Sub-Stream

    Network Video Recorder User Manual Frame Rate (FPS - Frames Per Second): refers to how many frames are captured each second. A higher frame rate is advantageous when there is movement in the video stream, as it maintains image quality throughout. Resolution: Image resolution is a measure of how much detail a digital image can hold: the greater the resolution, the greater the level of detail.

  • Page 88: Configure Recording Schedule

    Network Video Recorder User Manual Advanced Record Settings  Record Audio: Check the checkbox to enable or disable audio recording.  Pre-record: The time you set to record before the scheduled time or event. For example, when an alarm triggers the recording at 10:00, and if you set the pre-record time as 5 seconds, the camera records at 9:59:55.
  • Page 89 Network Video Recorder User Manual Go to Storage > Recording Schedule. Recording Schedule Select a camera. Check Enable Schedule. Select a record type. The record type can be Continuous, Motion Detection, Alarm, Motion | Alarm, Motion & Alarm, and Event. Different recording types are configurable.

  • Page 90: Configure Continuous Recording

    Network Video Recorder User Manual The all-day continuous recording is configured for the device by factory default. Click Apply to save the settings. To enable Motion, Alarm, M | A (motion or alarm), M & A (motion and alarm) and Event triggered recording and capture, you must configure the motion detection settings, alarm input settings and other events as well.

  • Page 91: Configure Alarm Triggered Recording

    Network Video Recorder User Manual Go to System > Event. Configure the event detection and select the channel (s) to trigger the recording when event occurs. Refer to Chapter 11 Event and Alarm Settings and Chapter 13 VCA Event Alarm for details.

  • Page 92: Configure Holiday Recording And Capture

    Network Video Recorder User Manual Go to Storage > Capture Schedule. Select the camera to configure the picture capture. Set Picture Capture Schedule Set the picture capture schedule. Refer to Chapter 7.4 Configure Recording Schedule for details. Configure Holiday Recording and Capture Purpose: Follow the steps to configure the record or capture schedule on holiday for that year.
  • Page 93 Network Video Recorder User Manual Edit Holiday Settings Edit the holiday name. Select the mode to by date, by week or by month. Set the start and end date of the holiday. Click OK. Set the schedule for the holiday recording. Refer to Chapter 7.4 Configure Recording Schedule for details.

  • Page 94: Configure Redundant Recording And Capture

    Network Video Recorder User Manual Configure Redundant Recording and Capture Purpose: Enabling redundant recording and capture, which means saving the record files and captured pictures not only in the R/W HDD but also in the redundant HDD, will effectively enhance the data safety and reliability.

  • Page 95: Configure 1080P Lite

    Network Video Recorder User Manual Record Parameters Check the checkbox of Redundant Record/Capture. Click OK to save settings. Configure 1080p Lite Purpose When the 1080P Lite Mode is enabled, the encoding resolution at 1080P Lite (real-time) is supported. If not, up to 1080P (non-real-time) is supported. This chapter is applicable to HQHI series DVR.

  • Page 96: Disable The 1080P Lite Mode

    Network Video Recorder User Manual Advanced Interface Step 2 Check the checkbox of 1080P Lite Mode and click Apply to pop up the attention box. After enabling 1080p lite mode, the 3 MP signal is not accessible to analog channel. Step 3 Click Yes in popup message box to reboot the device to have new settings taken effect.

  • Page 97: Chapter 8 Disk Array

    Network Video Recorder User Manual Chapter 8 Disk Array This chapter is applicable for DS-7300/8100/9000HUHI-K series DVR. Purpose: Disk array is a data storage virtualization technology that combines multiple physical disk drive components into a single logical unit. An array stores data over multiple HDDs to provide enough redundancy so that data can be recovered if one disk fails.

  • Page 98: One-Touch Creation

    Network Video Recorder User Manual Click Apply. Reboot device to take effect the settings. One-Touch Creation Purpose: One-touch configuration helps you to quickly create the disk array. By default, the array type created by one-touch configuration is RAID 5. Before you start: ...
  • Page 99 Network Video Recorder User Manual Create Array Enter the array name. Select RAID Level as RAID 0, RAID 1, RAID 5, RAID 6, or RAID 10 as required. Select the physical disks to constitute array. Required Number of HDD RAID Level Required Number of HDD RAID 0 At least 2 HDDs.

  • Page 100: Rebuild Array

    Network Video Recorder User Manual Rebuild Array Purpose: The status of array includes Functional, Degraded and Offline. To ensure the high security and reliability of the data stored in array, you should take immediate and proper maintenance at arrays according their status. ...

  • Page 101: Manually Rebuild Array

    Network Video Recorder User Manual Manually Rebuild Array Purpose: If no hot spare disks are configured, rebuild the degraded array manually. Before you start: At least one available physical disk should exist for rebuilding the array. Go to Storage > RAID Setup > Array. Array List Click of degraded array.

  • Page 102: Delete Array

    Network Video Recorder User Manual Delete Array Deleting array will delete all the data saved in it. Go to Storage > RAID Setup > Array. Array List Click of array to delete. Attention Click Yes on the popup message box.

  • Page 103: Check And Edit Firmware

    Network Video Recorder User Manual Check and Edit Firmware Purpose: You can view the information of the firmware and set the background task speed on the Firmware interface. Go to Storage > RAID Setup > Firmware. Firmware Optionally, set the Background Task Speed. Click Apply.

  • Page 104: Chapter 9 File Management

    Network Video Recorder User Manual Chapter 9 File Management Search and Export All Files Search Files Purpose Specify detailed conditions to search videos and pictures. Go to File Management > All Files. Specify detailed conditions, including time, camera, event type, etc. Search All Files Click Search to display results.

  • Page 105: Search And Export Human Files

    Network Video Recorder User Manual Click to select files and click Export. Select the file to export as Video and Log and click OK. Click OK to export files to backup device. Search and Export Human Files Search Human Files Purpose Specify detailed conditions to search human pictures and videos.

  • Page 106: Search And Export Vehicle Files

    Network Video Recorder User Manual Select the file to export as Video and Log and click OK. Click OK to export files to backup device. Search and Export Vehicle Files Search Vehicle Files Purpose Specify detailed conditions to search vehicle pictures and videos. Before you start Configure vehicle detection function for the cameras you want to search and export vehicle pictures and videos.

  • Page 107: Search History Operation

    Network Video Recorder User Manual Click OK to export files to backup device. Search History Operation Save Search Condition Purpose You can save the search conditions for future reference and quick search. Go to File Management > All Files/People Appearance File/Vehicle File. Set the search conditions.

  • Page 108: Chapter 10 Playback

    Network Video Recorder User Manual Chapter 10 Playback Play Video Files Instant Playback Instant Playback enables the device to play the recorded video files in last five minutes. If no video is found, it means there is no recording during the last five minutes. On the live view window of the selected camera, move the cursor to the window bottom to access the toolbar.

  • Page 109: Play Smart Searched Video

    Network Video Recorder User Manual Playback Interface Toolbar of Playback  Click the channel(s) to execute simultaneous playback of multiple channels. The playing speed of 256X is supported. Play Smart Searched Video In the smart playback mode, the device can analyze the video containing the motion, line or intrusion detection information, mark it in red color and play the smart searched video.

  • Page 110: Play Custom Searched Files

    Network Video Recorder User Manual Playback by Smart Search Set the rules and areas for smart search of line crossing detection, intrusion detection or motion detection event triggered recording. Line Crossing Detection  Click the icon. Click on the image to specify the start point and end point of the line. Intrusion Detection ...

  • Page 111: Play Tag Files

    Network Video Recorder User Manual Custom Search Click Search. Custom Searched Video Files On the search results interface, select a file and click to start playing the video. Play Tag Files Purpose: Video tag allows you to record related information like people and location of a certain time point during playback.
  • Page 112 Network Video Recorder User Manual Click to add the tag. Edit the tag information. Click OK. Max. 64 tags can be added to a single video file. Edit Tag Files Go to Playback. Click Tag. The available tags are white marked and displayed in the time bar. Point the white marked tag in the time bar to access the tag information.

  • Page 113: Play Event Files

    Network Video Recorder User Manual Tag Search Click Search. Searched Tag Files On the search results interface, select a tag file and click to start playing the video. Play Event Files Purpose Play back video files on one or several channels searched by event type (e.g., alarm input, motion detection, line crossing detection, face detection, vehicle detection, etc.).

  • Page 114: Play By Sub-Periods

    Network Video Recorder User Manual Click Search. On the search results interface, select an event video file/picture file and double click to start playing the video. Event Files You can click button to play 30s backward or forward.  Refer to Chapter 11 Event and Alarm Settings and Chapter 13 VCA Event Alarm for details for event and alarm settings.

  • Page 115: Play Log Files

    Network Video Recorder User Manual Set the start time and end time for searching video. Select the different multi-period at the right bottom corner, e.g., 4-Period. According to the defined number of split-screens, the video files on the selected date can be divided into average segments for playback.

  • Page 116: Playback Operations

    Network Video Recorder User Manual You can play files from the external storage devices. Before You Start: Connect the storage device with the video files to your device. Go to Playback. Click the icon at the left bottom corner. Select and click the button or double click to play the file.

  • Page 117: Edit Video Clips

    Network Video Recorder User Manual Edit Video Clips You can take video clips during the playback and export the clips. In the video playback mode, click to start video clipping operation.  : Set the start time and end time of the video clipping. ...

  • Page 118: Fast View

    Network Video Recorder User Manual Click the to enter the fisheye expansion mode.  180° Panorama ( ): Switch the live view image to the 180° panorama view.  360° Panorama ( ): Switch the live view image to the 360° panorama view. ...

  • Page 119: Chapter 11 Event And Alarm Settings

    Network Video Recorder User Manual Chapter 11 Event and Alarm Settings Configure Arming Schedule Select the Arming Schedule tab. Choose one day of a week and set the time segment. Up to eight time periods can be set within each day. Time periods shall not be repeated or overlapped.

  • Page 120: Configure Audio Warning

    Network Video Recorder User Manual Go to System > View > General. Set the event output and dwell time.  Event Output: Select the output to show event video.  Full Screen Monitoring Dwell Time: Set the time in seconds to show alarm event screen. If alarms are triggered simultaneously in several channels, their full-screen images will be switched at an interval of 10 seconds (default dwell time).

  • Page 121: Trigger Alarm Output

    Network Video Recorder User Manual Go to System>Network>Advanced. Configure the Email settings. Go to the Linkage Action interface of the alarm detection (e.g., motion detection, video tampering, face detection, etc.). Select the Send Email alarm linkage action. Trigger Alarm Output The alarm output can be triggered by the alarm input, motion detection, video tampering detection, face detection, line crossing detection, and all other events.

  • Page 122: Configure Motion Detection Alarm

    Network Video Recorder User Manual PTZ Linkage You can set one PTZ type only for the linkage action each time. Configure Motion Detection Alarm The motion detection enables the device to detect the moving objects in the monitoring area and trigger the alarm.
  • Page 123 Network Video Recorder User Manual Set Motion Detection Select the camera to configure the motion detection. Check Enable. Set the motion detection area.  Full screen: click to set the full-screen motion detection for the image.  Customized area: use the mouse to click and drag on the preview screen to draw the customized motion detection area (s).

  • Page 124: Configure Video Loss Alarm

    Network Video Recorder User Manual Configure Video Loss Alarm Purpose: The video loss detection enables to detect video loss of a channel and take alarm response action(s). Go to System > Event > Normal Event > Video Loss Set Video Loss Detection Select the camera to configure the video loss detection.

  • Page 125: Configure Video Tampering Alarm

    Network Video Recorder User Manual Configure Video Tampering Alarm Purpose: The video tampering detection enables to trigger alarm when the camera lens is covered and take alarm response action(s). Go to System> Event>Normal Event>Video Tampering. Select the camera to configure the video tampering detection. Set Video Tampering Setting Check Enable.

  • Page 126: Configure Sensor Alarms

    Network Video Recorder User Manual Configure Sensor Alarms Purpose: Set the handling action of an external sensor alarm. Configure Alarm Input Go to System> Event>Normal Event>Alarm Input Select an alarm input item from the list and click Alarm Input Select the alarm input type to N.C or N.O. Edit Alarm Name.

  • Page 127: Configure One-Key Disarming

    Network Video Recorder User Manual Configure One-Key Disarming The one-key disarming enables the device to disarm the alarm input 1 by one-key operation. Go to System> Event>Normal Event>Alarm Input Select the alarm input1 item from the list and click Select the alarm input type to N.C or N.O. Edit the alarm name.
  • Page 128 Network Video Recorder User Manual Go to System> Event>Normal Event>Alarm Output. Select an alarm output item from the list and click Edit Alarm Name. Select Dwell Time (the alarm duration) from 5s to 600s, or Manually Clear. Manually Clear: You should manually clear the alarm when the alarm occurs. Refer to Chapter 11.8 Trigger or Clear Alarm Output Manually for detailed instructions.

  • Page 129: Configure Exceptions Alarm

    Network Video Recorder User Manual Configure Exceptions Alarm The exception events can be configured to take the event hint in the live view window, trigger alarm output and linkage actions. Go to System > Event > Normal Event > Exception. (Optional) Enable the event hint if you want to display the event hint in the live view window.

  • Page 130: Trigger Or Clear Alarm Output Manually

    Network Video Recorder User Manual Exceptions Handling Set the normal linkage and alarm output triggering. Refer to 11.2 Configure Alarm Linkage Actions. Trigger or Clear Alarm Output Manually Purpose: Sensor alarm can be triggered or cleared manually. When Manually Clear is selected for the dwell time of an alarm output, the alarm can be cleared only by clicking Clear.
  • Page 131 Network Video Recorder User Manual Alarm Output...

  • Page 132: Chapter 12 Pos Configuration

    Network Video Recorder User Manual Chapter 12 POS Configuration The device can be connected with the POS machine/server, and receive the transaction message for overlay on the image during the live view or playback, as well as trigger the POS event alarm. This chapter is only applicable to DS-7300/8100HQHI-K, DS-7300/8100/9000HUHI-K, and DeepinMind series DVR.
  • Page 133 Network Video Recorder User Manual Universal Protocol Settings  EPSON The fixed start and end line tag are used for EPSON protocol.  AVE The fixed start and end line tag are used for AVE protocol. And the serial port and virtual serial port connection types are supported.
  • Page 134 Network Video Recorder User Manual  NUCLEUS 1) Click the Custom to configure the NUCLEUS settings. 2) Enter the employee No. shift No. and the terminal No. in the field. The matching message sent from the POS device will be used as the valid POS data. The NUCLEUS protocol must be used in the RS-232 connection communication.
  • Page 135 Network Video Recorder User Manual USB-to-RS-232 Settings  RS-232 Connection Connect the device and the POS machine via RS-232. The RS-232 settings can be configured in Menu>Configuration>RS-232. The Usage must be set to Transparent Channel.  Multicast Connection When connecting the device and the POS machine via Multicast protocol, set the multicast address and port.

  • Page 136: Configure Pos Text Overlay

    Network Video Recorder User Manual Sniff Settings Configure POS Text Overlay Go to System > POS Settings. Click Channel Linkage and Display tab. Select the linked channel to overlay the POS characters. Set the characters overlay for the enabled POS. ...

  • Page 137: Configure Pos Alarm

    Network Video Recorder User Manual Overlay Character Settings You can adjust the size and position of textbox on the preview screen of POS settings interface by dragging the frame. Click Apply to activate the settings. Configure POS Alarm Purpose: The POS event can trigger channels to start recording, or trigger full screen monitoring, audio warning, notifying the surveillance center, sending email and so on.
  • Page 138 Network Video Recorder User Manual Set Trigger Cameras of POS Click Apply to save the settings.

  • Page 139: Chapter 13 Vca Event Alarm

    Network Video Recorder User Manual Chapter 13 VCA Event Alarm The device supports receiving the VCA detections sent by connected IP cameras. Enable and configure the VCA detection on the IP camera settings interface first.  VCA detections must be supported by the connected IP camera. ...

  • Page 140: Face Detection

    Network Video Recorder User Manual Human Body Detection 4) Click Draw Area to draw a quadrilateral in the preview window and then click Stop Drawing. Related Operation: You can click Clear to clear the existing virtual line and re-draw it. Set the arming schedule.

  • Page 141: Vehicle Detection

    Network Video Recorder User Manual Face Detection Select a camera to configure. Check Enable Face Detection. Optionally, check Save VCA Picture to save the captured pictures of face detection. Drag the Sensitivity slider to set the detection sensitivity. Sensitivity range: [1-5]. The higher the value is, the more easily the face can be detected.

  • Page 142: Line Crossing Detection

    Network Video Recorder User Manual Vehicle Detection Select a camera to configure. Check Enable Vehicle Detection. Optionally, check Save VCA Picture to save the captured pictures of vehicle detection. Set the arming schedule. Refer to Chapter 11.1 Configure Arming Schedule. Set the linkage actions.
  • Page 143 Network Video Recorder User Manual Go to System > Event > Smart Event. Click Line Crossing. Line Crossing Detection Select a camera to configure. Check Enable Line Crossing Detection checkbox. Optionally, check Save VCA Picture to save the captured pictures of line crossing detection.

  • Page 144: Intrusion Detection

    Network Video Recorder User Manual Set the linkage actions. Refer to Chapter 11.2 Configure Alarm Linkage Actions. Click Apply. Intrusion Detection Purpose: Intrusion detection function detects people, vehicle or other objects which enter and loiter in a pre-defined virtual region, and some certain actions can be taken when the alarm is triggered. Go to System >...

  • Page 145: Region Entrance Detection

    Network Video Recorder User Manual longer than the threshold, device will trigger an alarm. Its range is [1s- 10s]. − Sensitivity: The size of the object that can trigger the alarm. The higher the value is, the more easily the detection alarm can be triggered. Its range is [1-100].

  • Page 146: Region Exiting Detection

    Network Video Recorder User Manual Region Entrance Detection Select a camera to configure. Check Enable Region Entrance Detection checkbox. Optionally, check Save VCA Picture checkbox to save the captured pictures of region entrance detection. Follow the steps to set the detection rules and detection areas. 1) Select an Arming Region to configure.
  • Page 147 Network Video Recorder User Manual Go to System > Event > Smart Event. Click Region Exiting. Region Exiting Detection Select a camera to configure. Check Enable Region Exiting Detection. Optionally, check Save VCA Picture to save the captured pictures of region exiting detection.

  • Page 148: Unattended Baggage Detection

    Network Video Recorder User Manual Unattended Baggage Detection Purpose: Unattended baggage detection function detects the objects left over in the pre-defined region such as the baggage, purse, dangerous materials, etc., and a series of actions can be taken when the alarm is triggered. Go to System >...

  • Page 149: Object Removal Detection

    Network Video Recorder User Manual 3) Click Draw Region and draw a quadrilateral in the preview window by specifying four vertexes of the detection region. Set the arming schedule. Refer to Chapter 11.1 Configure Arming Schedule. Set the linkage actions. Refer to Chapter 11.2 Configure Alarm Linkage Actions. Click Apply.

  • Page 150: Audio Exception Detection

    Network Video Recorder User Manual 2) Drag the sliders to set Time Threshold and Sensitivity. Time Threshold: The time of the objects removed from the region. If the value is 10, alarm is triggered after the object disappeared from the region for 10s. Its range is [5s- 20s].

  • Page 151: Sudden Scene Change Detection

    Network Video Recorder User Manual 2) Select Audio Loss Exception, Sudden Increase of Sound Intensity Detection, or Sudden Decrease of Sound Intensity Detection. Audio Loss Exception: Detects the sound steep rise in the surveillance scene. You can set the detection sensitivity and threshold for sound steep rise. You need to configure its Sensitivity and Sound Intensity Threshold.

  • Page 152: Defocus Detection

    Network Video Recorder User Manual Sudden Scene Change Select a camera to configure. Check Enable Sudden Scene Change Detection. Optionally, check Save VCA Picture to save the captured pictures of sudden scene change detection. Drag the Sensitivity slider to set the detection sensitivity. Sensitivity range: [1-100]. The higher the value is, the more easily the change of scene can trigger the alarm.

  • Page 153: Pir Alarm

    Network Video Recorder User Manual Defocus Detection Select a camera to configure. Check Enable Defocus Detection. Optionally, check Save VCA Picture to save the captured pictures of defocus detection. Drag the Sensitivity slider to set the detection sensitivity. Sensitivity range: [1-100]. The higher the value is, the more easily the defocus image can be detected.
  • Page 154 Network Video Recorder User Manual FIR Alarm Select a camera to configure. Check PIR Alarm. Optionally, check Save VCA Picture to save the captured pictures of PIR alarm. Set the arming schedule. Refer to Chapter 11.1 Configure Arming Schedule. Set the linkage actions. Refer to Chapter 11.2 Configure Alarm Linkage Actions. Click Apply.

  • Page 155: Chapter 14 Smart Analysis

    Network Video Recorder User Manual Chapter 14 Smart Analysis With the configured VCA detection, the device supports the smart analysis for people counting and heat map. Face Search The chapter is only available for iDS-7316HUHI-K4/16S and iDS-9016HUHI-K8/16S. Purpose: When there are detected face picture captured and saved in HDD, you can enter the Face Search interface to search the picture and play the picture related video file according to the specified conditions.

  • Page 156: Vehicle Search

    Network Video Recorder User Manual Vehicle Search The chapter is only available for iDS-7316HUHI-K4/16S and iDS-9016HUHI-K8/16S. Purpose: You can search and view the matched captured vehicle pictures. Go to Smart Analysis > Smart Search > Vehicle Search. Select the IP camera for the vehicle search. Set search conditions.

  • Page 157: Heat Map

    Network Video Recorder User Manual People Counting Interface (Optional) Click Export to export the report in excel format. Heat Map Purpose: Heat map is a graphical representation of data. The heat map function is usually used to analyze how many people visited and stayed in a specified area. The heat map function must be supported by the connected IP camera and the corresponding configuration must be set.
  • Page 158 Network Video Recorder User Manual As shown in the figure above, red color block (255, 0, 0) indicates the most welcome area, and blue color block (0, 0, 255) indicates the less-popular area. (Optional) Click Export to export the statistics report in excel format.

  • Page 159: Chapter 15 Human Body Detection

    Network Video Recorder User Manual Chapter 15 Human Body Detection The chapter is only available for iDS-7316HUHI-K4/16S and iDS-9016HUHI-K8/16S. Smart Analysis Enable Smart Analysis Purpose Smart analysis function models human body pictures captured via smart events, including human body detection, line crossing detection, intrusion detection, region entrance, and region exiting, and analyzes human body appearance, including gender, age, etc.
  • Page 160 Network Video Recorder User Manual Task Configuration Check cameras to enable corresponding analysis mode. Ensure engine is available for the selected analysis mode. Enable auto analysis. 1) Click Edit. 2) Optionally, check Enable of Display Status and Notify Surveillance Center. 3) Set Start Time of video to analyze.

  • Page 161: View Engine Status

    Network Video Recorder User Manual  Task status includes 3 situations: Disabled, Waiting, and Enabled.  Disabled: No analysis task is enabled on the camera.  Waiting: The analysis task of the camera is enabled. Device is waiting to start analyze data.

  • Page 162: Search By Picture

    Network Video Recorder User Manual Specify search conditions. Click Start Search. Search by Human Body Appearance Automatically Obtained from Uploaded Sample Purpose Search human body pictures according to human body appearance automatically obtained from uploaded sample pictures. Before you start Import a human body picture in USB flash drive and connect it to device.

  • Page 163: Add Search Result As Sample Picture

    Network Video Recorder User Manual  When there are multiple targets existing in the same picture, up to 30 target pictures can be analyzed and displayed.  The maximum allowed picture size is 3840*2160.  The picture must be in jpg or jpeg format. ...

  • Page 164: Chapter 16 Network Settings

    Network Video Recorder User Manual Chapter 16 Network Settings Configure TCP/IP Settings Purpose TCP/IP settings must be properly configured before operating the device over network. Go to System > Network > TCP/IP. TCP/IP Settings Select Net-Fault Tolerance or Multi-Address Mode under Working Mode. ...

  • Page 165: Configure Hik-Connect

    Network Video Recorder User Manual  Check Enable DHCP to obtain IP settings automatically if a DHCP server is available in the network.  Valid range of MTU value is 500 to 9676. Click Apply. Configure Hik-Connect Purpose Hik-Connect provides mobile phone application as well as service platform to access and manage your connected devices with remote access to the surveillance system.

  • Page 166: Configure Ddns

    Network Video Recorder User Manual (Optional) Check Custom and enter the server address as needed. The default server address is dev.hik-connect.com. (Optional) Check Enable Stream Encryption and verification code will be required for remote access and live view. Click Apply. ...

  • Page 167: Configure Pppoe

    Network Video Recorder User Manual DDNS Settings Click Apply. Configure PPPoE If the device is connected to Internet through PPPoE, you need to configure user name and password accordingly under System > Network > TCP/IP > PPPoE. Contact your Internet service provider for details about PPPoE service. Configure NTP Purpose Connection to a network time protocol (NTP) server can be configured on your device to ensure...

  • Page 168: Configure Snmp

    Network Video Recorder User Manual NTP Settings Check Enable. Configure NTP settings as need.  Interval (min): Time interval between two time synchronizations with NTP server.  NTP Server: IP address of the NTP server.  NTP Port: Port of the NTP server. Click Apply.

  • Page 169: Configure Email

    Network Video Recorder User Manual SNMP Settings Check Enable. A message box will pop up to prompt possible security risk and click Yes to continue. Configure the SNMP settings as needed.  Trap Address: IP address of the SNMP host. ...
  • Page 170 Network Video Recorder User Manual Go to System > Network > Advanced > Email. Email Settings Configure the following Email settings.  Enable Server Authentication: Check to enable the function if the SMTP server requires user authentication and enter user name and password accordingly. ...

  • Page 171: Configure Ports

    Network Video Recorder User Manual Configure Ports You can configure different types of ports to enable relevant functions. Go to System > Network > Advanced > More Settings and configure port settings as needed.  Alarm Host IP/Port: With a remote alarm host configured, the device will send the alarm event or exception message to the host when an alarm is triggered.
  • Page 172 Network Video Recorder User Manual Port Settings...

  • Page 173: Chapter 17 System Maintenance

    Network Video Recorder User Manual Chapter 17 System Maintenance Storage Device Maintenance Configure Disk Clone Purpose: Select the HDDs to clone to eSATA HDD. Before you start: Connect an eSATA disk to the device. Go to Maintenance > HDD Operation > HDD Clone. HDD Clone Check the HDD to clone.

  • Page 174: S.m.a.r.t Detection

    Network Video Recorder User Manual Message Box S.M.A.R.T Detection Purpose: The device provides HDD detection function including S.M.A.R.T. and Bad Sector Detection technique. The S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) is a monitoring system for HDD to detect and report on various indicators of reliability in the hopes of anticipating failures.

  • Page 175: Bad Sector Detection

    Network Video Recorder User Manual S.M.A.R.T Settings Interface If you want to use the HDD even when the S.M.A.R.T. checking is failed, you can check Continue to use the disk when self-evaluation is failed. Bad Sector Detection Go to Maintenance > HDD Operation > Bad Sector Detection. Select the HDD No.

  • Page 176: Hdd Health Detection

    Network Video Recorder User Manual Bad Sector Detection  You can also pause/resume or cancel the detection.  After testing completed, click Error information to see the detailed damage information. HDD Health Detection Purpose: You can view the health status of Seagate HDD that generated after October 1th, 2017 and provides capacity ranges from 4 TB to 8 TB.

  • Page 177: Search & Export Log Files

    Network Video Recorder User Manual Click a HDD to view details. Search & Export Log Files Purpose: The operation, alarm, exception and information of the device can be stored in log files, which can be viewed and exported at any time. Search the Log Files Go to Maintenance >...

  • Page 178: Export The Log Files

    Network Video Recorder User Manual  Click to view the related video file. Export the Log Files Before You Start: Connect a storage device to your device. Search the log files. Refer to Chapter 17.2.1 Search the Log Files. Select the log files you want to export, and click Export. Or you can click Export ALL on the Log Search interface to export all the system logs to the storage device.

  • Page 179: Import/Export Ip Camera Configuration Files

    Network Video Recorder User Manual Import/Export IP Camera Configuration Files Purpose: The information of added IP camera can be generated into an excel file and exported to the local device for backup, including the IP address, manage port, password of admin, etc. And the exported file can be edited on your PC, like adding or deleting the content, and copy the setting to other devices by importing the excel file to it.

  • Page 180: Import/Export Device Configuration Files

    Network Video Recorder User Manual Import/Export Device Configuration Files Purpose: The configuration files of the device can be exported to local device for backup; and the configuration files of one device can be imported to multiple devices if they are to be configured with the same parameters.

  • Page 181: Upgrade System

    Network Video Recorder User Manual Upgrade System Purpose: The firmware on your device can be upgraded by local backup device or remote FTP server. Upgrade by Local Backup Device Before You Start: Connect your device with a local storage device with update firmware file. Go to Maintenance >...

  • Page 182: Upgrade Camera

    Network Video Recorder User Manual FTP Upgrade Interface Enter IP address of FTP Server Address. Click Upgrade to start upgrading. After the upgrading is complete, reboot the device to activate the new firmware. Upgrade Camera Purpose You can upgrade multiple connected analog cameras supporting Turbo HD or AHD signal simultaneously with DVR.

  • Page 183: System Service

    Network Video Recorder User Manual Restore Defaults Select the restoring type from the following three options. Restore Defaults: Restore all parameters, except the network (including IP address, subnet mask, gateway, MTU, NIC working mode, default route, server port, etc.) and user account parameters, to the factory default settings.
  • Page 184 Network Video Recorder User Manual By default, the HTTP service is enabled. Set HTTP Authentication Purpose If you need to enable the HTTP service, you can set the HTTP authentication to enhance the access security. Go to System > System Service > System Service. HTTP Authentication Check the Enable HTTP to enable the HTTP service.

  • Page 185: Managing Onvif User Accounts

    Network Video Recorder User Manual RTSP Authentication Select the authentication type. Two authentication types are selectable: digest and digest/basic. If you select digest, as the RTSP authentication, only the request with digest authentication can access the video stream by the RTSP protocol via the IP address.

  • Page 186: Managing Ip Camera Activation

    Network Video Recorder User Manual Select the user level to Media User, Operator and Admin. Click OK to save the settings. Result: The added user accounts have the permission to connect other devices to the device via ONVIF protocol. ONVIF protocol is disabled by default. Managing IP Camera Activation When you activate the device for the first-time access, you can set the activation password for the IP camera (s) as well.
  • Page 187 Network Video Recorder User Manual Attention Click Yes to duplicate the current password to the IP cameras which are connected with the default protocol.

  • Page 188: Chapter 18 General System Settings

    Network Video Recorder User Manual Chapter 18 General System Settings Configure General Settings Purpose: You can configure the BNC output standard, VGA output resolution, mouse pointer speed through the System > General interface. Go to System > General. General Settings Interface Configure the following settings.

  • Page 189: Configure Date & Time

    Network Video Recorder User Manual Mouse Pointer Speed: Set the speed of mouse pointer; 4 levels are configurable. Enable Wizard: Enable/disable the Wizard when the device starts up. Enable Password: Enable/disable the use of the login password. Click Apply to save the settings. Configure Date &...

  • Page 190: Configure Dst Settings

    Network Video Recorder User Manual Configure DST Settings The DST (daylight saving time) refers to the period of the year when clocks are moved one period ahead. In some areas worldwide, this has the effect of creating more sunlit hours in the evening during months when the weather is the warmest.
  • Page 191 Network Video Recorder User Manual User Management Interface Click Add to enter the operation permission interface. Enter the admin password and click Next. Add User In the Add User interface, enter the information for new user, including User Name, Password, Confirm (password), User Level (Operator/Guest) and User’s MAC Address. Strong Password recommended–We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the...

  • Page 192: Set Permission For A User

    Network Video Recorder User Manual Operator: The Operator user level has permission of Two-way Audio in Remote Configuration and all operating permission in Camera Configuration by default. Guest: The Guest user has no permission of Two-way Audio in Remote Configuration and only has the local/remote playback in the Camera Configuration by default.
  • Page 193 Network Video Recorder User Manual User Permission Settings Interface Set the operating permission of Local Configuration, Remote Configuration and Camera Configuration for the user.  Local Configuration Local Log Search: Searching and viewing logs and system information of device. Local Parameters Settings: Configuring parameters, restoring factory default parameters and importing/exporting configuration files.

  • Page 194: Set Local Live View Permission For Non-Admin Users

    Network Video Recorder User Manual Remote Alarm Control: Remotely arming (notify alarm and exception message to the remote client) and controlling the alarm output. Remote Advanced Operation: Remotely operating HDD management (initializing HDD, setting HDD property), upgrading system firmware, clearing I/O alarm output. Remote Shutdown/Reboot: Remotely shutting down or rebooting the device.

  • Page 195: Edit The Admin User

    Network Video Recorder User Manual Enable Live View Permission Click of non-admin user. Enter Camera Configuration interface. Select Camera Permission as Local Live View. Select cameras to live view. Click OK. Edit the Admin User For the admin user account, you can modify its password the unlock pattern. Go to System >...
  • Page 196 Network Video Recorder User Manual Edit User (Admin) Edit the admin user information as demand, including the new admin password (strong password is required), and MAC address. Edit the unlock pattern for the admin user account. 5) Check the checkbox of Enable Unlock Pattern to enable the use of unlock pattern when logging in to the device.

  • Page 197: Edit The Operator/Guest User

    Network Video Recorder User Manual Set Unlock Patter for Admin User Click the of Export GUID to enter the reset password interface to export the GUID file for the admin user account. When the admin password is changed, you can export the new GUID to the connected U flash disk in the Import/Export interface for the future password resetting.

  • Page 198: Delete A User

    Network Video Recorder User Manual Edit User (Operator/Guest) Edit the user information as demand, including the new password (strong password is required), and MAC address. Delete a User The admin user account has the permission to delete the operator/guest user account. Go to System >...
