- Page 1 Digital Video Recorder Quick Start Guide User Manual...
- Page 2 BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
- Page 3 Digital Video Recorder Quick Start Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
-
Page 4: Symbol Conventions
Digital Video Recorder Quick Start Guide Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Provides additional information to emphasize or supplement important points of the main text. Indicates a potentially hazardous situation, which if not avoided, could result in equipment damage, data loss, performance degradation, or unexpected results. -
Page 5: Power Supply Instructions
Digital Video Recorder Quick Start Guide Power Supply Instructions Use only power supplies listed below. For DS-7104HQHI-K1, DS-7108HQHI-K1, and DS-7104HUHI-K1. Standard Power Supply Models Manufacturer MSA-C1500IC12.0-18P-GB MOSO Technology Co., Ltd. British Shenzhen Honor Electronic Co., ADS-26FSG-12 12018EPB Ltd. MSA-C1500IC12.0-18P-DE MOSO Technology Co., Ltd. -
Page 6: Chapter 1 Rear Panel Interfaces Description
Digital Video Recorder Quick Start Guide Chapter 1 Rear Panel Interfaces Description The rear panel interfaces vary with different models. Refer to Table 1-1 for the common interfaces description of rear panels. Common Interfaces Description of Rear Panels Item Description Item Description BNC interface for Turbo HD... -
Page 7: Bracket Installation
Digital Video Recorder Quick Start Guide Before you start Ensure power is disconnected. Prepare a factory recommended HDD, and cross screwdriver. Bracket Installation Bracket installation is applicable when it requires to remove the device cover, and install HDD on the internal bracket. -
Page 8: Rs-485 And Controller Connection
Digital Video Recorder Quick Start Guide Fix Mounting Ear Open Front Panel Insert HDD Fix-on-Bottom Installation Fix-on-bottom installation is applicable when it requires to install the HDD at the internal bottom. Unfasten screws on each panel to remove the device cover. Refer to Figure 2-7. Connect the data cable and power cable. -
Page 9: Chapter 3 Menu Operation
Digital Video Recorder Quick Start Guide Controller Connection Chapter 3 Menu Operation Startup Proper startup is crucial to expand the life of DVR. It is HIGHLY recommended to use an Uninterruptible Power Supply (UPS) with the device. Plug power supply into an electrical outlet. Press the power button (certain models may have power button on the front or rear panel). -
Page 10: Set Unlock Pattern
Digital Video Recorder Quick Start Guide Enter the password in Create Channel Default Password to activate the network camera(s) connected to the device. Click OK to save the password and activate the device. Set Admin Password What to do next: ... -
Page 11: User Login
Digital Video Recorder Quick Start Guide Draw the Unlock Pattern User Login You have to log in to the device before operating the menu and other functions. Select User Name. Enter password for the selected user. Click OK to log in. For the admin, if you have entered the wrong password for 7 times, the account will be locked for 60 seconds. - Page 12 Digital Video Recorder Quick Start Guide Network Settings Configure Hik-Connect Hik-Connect provides mobile phone application and platform service to access and manage your connected devices, which enables you to get a convenient remote access to the surveillance system. Go to System > Network > Advanced > Platform Access. Check Enable to activate the function.
-
Page 13: Add Ip Cameras
Digital Video Recorder Quick Start Guide Set the analog signal input channels and types, and the connectable maximum IP camera number. Disabling analog channel(s) would increase the connectable IP camera number. Signal Input Status The interface of different models may vary. (Optional) You can enable 5 MP Long Distance Transmission for the Turbo HD and AHD signal input. - Page 14 Digital Video Recorder Quick Start Guide Ensure the network connection is valid and correct, and the IP camera to add has already been activated. Please refer to the User Manual for activating the inactive IP camera. Go to Camera > IP Camera. Click Custom Add.
-
Page 15: Live View
The maximum connectable AT/AF camera number varies according to different models. Please turn off the PoC function if the camera does not support PoC, or the camera is not produced by Hikvision. Otherwise, it may result in permanent damage to the camera or DVR. Live View Enter the live view mode ( ... -
Page 16: Chapter 4 Accessing By Web Browser
Digital Video Recorder Quick Start Guide Chapter 4 Accessing by Web Browser You can get access to the device via web browser. The following web browsers are supported: Internet Explorer 6.0, Internet Explorer 7.0, Internet Explorer 8.0, Internet Explorer 9.0, Internet Explorer 10.0, Apple Safari, Mozilla Firefox, and Google Chrome.
