Innovo INV-DC200 Quick Manual

Quick Guide to the INV-DC200 Thermometer

Measuring forehead temperature

Hold the F1 button down and slide the thermometer along your forehead from one temple to the other. Please
note that the thermometer should be in CONTACT with the forehead at ALL times during measurement. This
should take <5 secs. Release the F1 button when complete. The maximum value of measurement will be
displayed on the LCD screen. Note: You might hear a soft clicking sound when swiping the thermometer
across the forehead. That is normal.

Measuring temperature via eardrum

Remove the sensor cover and insert the probe into the ear canal.
For children > 1 year old, gently pull the ear up to ensure that the ear canal is straight (See Figure 1). Position
the thermometer probe carefully so that it is aligned with the eardrum to ensure accurate measurement
readings. This applies to adults as well. For children < 1 year old, gently pull the ear straight back to ensure
that the ear canal is straight (see Figure 2).
Once you have inserted the thermometer probe into the ear, press the F2 button for 1 sec to take the
measurement. The temperature will be shown on the LCD display.
CAUTION! The sensor is extremely sensitive. Any dirt and/or grease on it might prevent an accurate
measurement. For best result, please check and clean it regularly. Please note that the sensor can look
deceptively "clean" when it is not. The surface of a clean sensor should be reflective and gleaming. If it
looks dull and lackluster, then it is dirty. Please clean the sensor with a cotton swab moistened with
alcohol and wait 5-10 mins for the alcohol to completely evaporate before using the thermometer.
°C/°F conversion
When the thermometer is off, press and hold button F2 for 6-9 seconds until the "- - -°C/°F" temperature unit is
blinking. Press button F2 again within 5 seconds to change the temperature unit to your choice.
To download the latest manual, please go to
For inquiries, please email cs@innovogroups.com
(1) Sensor/Probe (Take cover off to measure eardrum
temperature)
(2)

F1: Button for measuring forehead temperature

(3) F2: Button for measuring eardrum temperature and
access Menu options
(4)

LCD Display

(5)

Battery cover

Incorrect position Correct position
Figure 1
Figure 2
