Innovo INV-DC200 User Manual

Quick Guide to the INV-DC200 Thermometer

Measuring forehead temperature

1. With the sensor/probe cover attached, position the thermometer at the center of the forehead, just above
the eyebrow. Ensure that the thermometer is in contact with the forehead.
2. Press and release the F1 button. The temperature will be displayed on the screen instantly.
Note: Make sure that the forehead is free of hair and perspiration.

Measuring temperature via eardrum

1. Gently remove the sensor/probe cover and insert the ear probe into the ear canal.
2. Press and release the F2 button. The temperature will be displayed on the screen instantly.
Note: Make sure that the ear canal is straight so that the sensor is in line with the eardrum
For children older than 1 year old, gently pull the ear up to ensure that the ear canal is straight (See Figure 1).
Position the thermometer probe carefully so that it is aligned with the eardrum to ensure accurate
measurement readings. This applies to adults as well. For children younger than 1 year old, gently pull the ear
straight back to ensure that the ear canal is straight (see Figure 2).
CAUTION! The sensor is extremely sensitive. Any debris and/or grease on the sensor lens might
prevent an accurate measurement. For best result, please check and clean the lens regularly. Please
note that the sensor lens can look deceptively "clean" when it is not. The lens of a clean sensor should
be reflective and gleaming. If it looks dull and lackluster, then it is dirty. Please clean the lens with a
cotton swab moistened with alcohol and wait 5-10 mins for the alcohol to completely evaporate before
using the thermometer.
°C/°F conversion
When the thermometer is off, press and hold the F2 button for 6-9 seconds until the "- - -°C/°F" temperature
unit is blinking. Press the F2 button again within 5 seconds to change the temperature unit to your choice.
To download the latest manual, please go to http://innovo-medical.com/products/innovo-medical-thermometer
For inquiries, please email cs@innovogroups.com
(1) Sensor/Probe cover (shown unattached to thermometer)
(2) Ear probe
(3) F1: Button for measuring forehead temperature
(4) F2: Button for measuring eardrum temperature and
access Menu options
(5) LCD display
(6) Battery cover
95.8°F
Incorrect position Correct position
Figure 1
Figure 2
98.4°F
