INSTALLATION

III

III.1 PRELIMINARY INDICATIONS

Carefully read the guide before installation and use of the appliances.
The installation requires safety equipment and a range of tool as per fig.3.1.
Fig. 3.1
The aspiration hob is equipped with all the hardware needed for its installation and is
suitable for most furniture.
Important: eventually, more screws than necessary for installation have been provided so
it is normal to have some left at the end of the installation.
Check minimum dimensions of the base requested for installation (Fig. 3.2). Minimum
height of the kitchen plinth is very important (min. 100 mm) in order to allow the passage
of the air ducts below the base of the furniture. Upon request, it is possible to purchase
a special kit for kitchen plinth up to 60 mm height.
Fig. 3.2
7
