EN
Before fixing the induction hob fix the foam gasket provided with the appliance on the
back of the hob.
CAUTION! It is forbidden to install the appliance without the foam gasket!
Remove the protective film and fix the foam gasket at a 2 mm distance from the edge of
the glass (A=2mm), The gasket must be attached along the entire length and should not
overlap at the corners (Fig.3.10).
Fig. 3.11
Fig. 3.10
Lay in the silicon sealant flush with the hole (Fig. 3.11), along the milling and lay the hob
on (Fig.3.12)
Fig. 3.12
