Instructions for use Installation Programming the amount of time after which the burner turns off All the operations concerned with the installation A time, after which a burner turns off, can be set (electrical and gas connections, adaptation to type of independently for each burner.
Page 4
to the right of the decimal point will flash and you can change the minutes in the same way described for the LEVEL SET. hours. When you press PT, the time setting will be saved. TURN-OFF TIME Sec. Sec. Sec. Sec.
Page 5
Mod: 60 cm The lighting of an LED means that the function is active for that burner. A flashing LED indicates that the timer of the relative burner has been activated. Setting Setting Setting Setting Timer Turning burner A burner B burner C burner D setting...
- We recommend the use of pots and pans with a diameter matching that of the burner, thus preventing the flame from escaping from the bottom part and surrounding the pot (Fig. 4); - do not leave any empty pots or pans on the fire; When cooking is finished, it is also a good norm to close the main gas pipe tap and/or cylinder.
Instructions for the installer Installation This appliance is not provided with a combustion product discharge. It is recommended that it be installed insufficiently aerated places, in terms of the laws in force. The quantity of air which is necessary for combustion must not be below 2.0 m /h for each kW of installed power.
Page 8
Mod: 60 cm Note: Semifilotop models do not need to be lowered by 1.5 1 - AUXILIARY 2 - SEMI-RAPID 3 - RAPID Fig. 6 Mod: 77 cm Note: Semifilotop models do not need to be lowered by 1.5 1 - AUXILIARY 2 - SEMI-RAPID 3 - RAPID 4 - TRIPLE CROWN...
Page 9
Mod: 90 cm Note: Semifilotop models do not need to be lowered by 1.5 1 - AUXILIARY 2 - SEMI-RAPID 3 - RAPID 4 - TRIPLE CROWN Fig. 8 Mod: 112 cm Note: Semifilotop models do not need to be lowered by 1.5 1120 1121 1 - AUXILIARY...
Page 10
Gas connection (Fig. 10) The earth connectionis compulsory in terms of the law. Should there be no cable and/or plug on the equipment, The connection to a gas tank or gas line must be made use suitable absorption material for the working by a qualified person in conformity to current updated temperature as well, as indicated on the matrix UNI-CIG 7129 and 7131 standards after making...
Page 11
Adaptation to varius types of gas (Fig. 12) factory setting, and will display a flashing ^ or v to indicate, respectively, a higher or lower flow than the factory setting. To confirm the minimum flow desired, you must press the Should the appliance be pre-set for a different type of PT key.
Page 12
Error Problem type Possible cause Possible solution displayed Restore the gas and unlock the No gas burners Clean or reposition the Single burner locked Ionization electrode dirty or not hit by the flame electrode and unlock the burners Check the cables and unlock The cook top is not grounded the burners Parasite flame/flame detection...
Page 13
USER CHARACTERISTICS GAS BURNERS FEED Ø INJECTORS THERMAL TYPE PRESSURE mbar BURNER CONSUMPTION 1/100 CAPACITY NORM. fast 3000 semifast 1750 Natural gas auxiliary 1000 wok 3 4000 fast 3000 semifast 1750 Liquefied G30/G31 28-30/37 auxiliary 1000 wok 3 4000 fast 3000 semifast 1750...
