ASROCK Rack E3C232D2I Quick Installation Manual

*15G065079100AK*
P/N: 15G065079100AK V1.0
Quick Installation Guide
E3C236D2I / E3C232D2I
The server board User's Manual is available for download from the ASRock Rack's official website
at http://www.asrockrack.com.
Take note of the following precautions before you install server board components or change any
server board settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the server board's components due to static electricity, NEVER place your
server board directly on the carpet or the like. Also remember to use a grounded wrist strap or
touch a safety grounded object before you handle the components.
3. Hold components by the edges and do not touch the ICs.
4. Whenever you uninstall any component, place it on a grounded anti-static pad or in the bag
that comes with the component.
5. When placing screws into the screw holes to secure the server board to the chassis, please do
not over-tighten the screws! Doing so may damage the server board.
Motherboard Layout
2
2 3
1 4
PECI1
PMBUS_SEL_DAT1 T 1 R
1 1 1 1
PMBUS_SEL_ALT1
PMBUS_SEL_CLK1
1
32
Top:
USB 2.0
IPMI
T: USB_1
B: USB_2 LAN
USB 3.0
LAN1
T: USB_1
B: USB_2
USB 3.0
LAN2
T: USB_3
B: USB_4
31
30
29
BMC
1
ME_RECOVERY1
28
27
3 I/O Panel
2 4
3
1
No. Description No. Description
1 USB 2.0 Ports (USB_1_2) 5
2 LAN RJ-45 Port (IPMI_LAN) 6
3 VGA Port (VGA1) 7
4 Serial Port (COM1) 8
5
17.0cm (6.7 in)
ATXPWR1
DDR4_B1 (64 bit, 288-pin module)
DDR4_A1 (64 bit, 288-pin module)
E3C236D2I
RoHS
BMC_SMB1 REAR_FAN1
1
NMI_BTN1
IPMB1
AUX_PANEL1
1
1
1
BIOS
TPM1 PSU_SMB1
1 1
ROM
PCIE7
26 25 24 23
4
6 8
5 7
USB 3.0 Ports (USB3_1_2)
LAN RJ-45 Port (LAN1)
USB 3.0 Ports (USB3_3_4)
LAN RJ-45 Port (LAN2)
1 Install the Server Board
1
Insert the server board into the chassis.
2
A f f i x t he screws clock w ise into t he
mounting holes in all of the corners of
the server board.
Do not over-tighten the screws
6
CMOS
Battery
CPU_FAN1 FRNT_FAN1
Note:
CLRMOS1
E3C236D2I:
Intel C236
E3C232D2I:
Intel C232
Intel
C236
(See Note)
SATA_SGPIO1
1
SATA_SGPIO2
USB3_7
1
SATA_0 SATA_1 SATA_2
SATA_3
SATA_4
ATX12V1
M2_1
PANEL1
PLED PWRBTN
SATA_5
1
HDLED RESET
USB3_5_6
SPEAKER1
1
1
NUT1
22 21 20 19
Jumper Cap On/Off
When the jumper cap is placed on the pins, the
jumper is "Short". If no jumper cap is placed on the
pins, the jumper is "Open".
The illustration shows a 3-pin jumper whose pin1
and pin2 are "Short" when a jumper cap is placed on
these 2 pins.
www.asrockrack.com
No. Description
1 CPU PECI Mode Jumper (PECI1)
2 PMBUS Mode Jumper (PMBUS_SEL_ALT1)
3 PMBUS Mode Jumper (PMBUS_SEL_DAT1)
7
4 Thermal Sensor Header (TR1)
5 ATX Power Connector (ATXPWR1)
8
6 CPU Fan Connector (CPU_FAN1)
9
7 Front Fan Connector (FRNT_FAN1)
2 x 288-pin DDR4 DIMM Slots
8
(DDR4_A1, DDR4_B1, Blue)
9 Clear CMOS Pad (CLRMOS1)
10 SATA SGPIO Connector (SATA_SGPIO1)
11 SATA SGPIO Connector (SATA_SGPIO2)
E3C236D2I: Vertical Type A USB 3.0 (USB3_7)
12
10
E3C232D2I: Vertical Type A USB 2.0 (USB3_7)
11
12
13 SATA3 Connector (SATA_0)
13
14
14 SATA3 Connector (SATA_1)
15
15 SATA3 Connector (SATA_3)
16
16 SATA3 Connector (SATA_2)
17
17 SATA3 Connector (SATA_4)
18
18 SATA3 Connector (SATA_5)
19 Speaker Header (SPEAKER1)
20 M.2 Slot (M2_1)* (supports M.2 module type 2230)
21 System Panel Header (PANEL1)
22 USB 3.0 Header (USB3_5_6)
23 ATX 12V Power Connector (ATX12V1)
24 PSU SMBus (PSU_SMB1)
25 Auxiliary Panel Header (AUX_PANEL1)
26 TPM Header (TPM1)
Intelligent Platform Management Bus header
27
(IPMB1)
28 ME Recovery Jumper (ME_RECOVERY1)
29 Non Maskable Interrupt Button (NMI_BTN1)
30 BMC SMBus Header (BMC_SMB1)
31 Rear Fan Connector (REAR_FAN1)
32 PMBUS Mode Jumper (PMBUS_SEL_CLK1)
