D-Link DSA-3100 Quick Installation Manual page 9

B、Check TCP/IP Setting - Windows 2000
1. Select "Control Panel" -"Network
and Dial-up Connections", then
click "Properties".
2. Right click
Connection"
"Properties",
TCP/IP protocol for your network
card.
3. Click on the Properties button.
4. If the DNS Server fields are
empty, select Use the following
DNS server addresses, and enter
the DNS address or addresses
provided by your ISP, then click
OK.
5. On the Gateway tab, enter the
DSA-3100's IP address in the
New Gateway field and click Add.
(Your LAN administrator can
advise you of the IP Address they
assigned to the DSA-3100.)
the "Local Area
icon and select
then select the
