C、Checking TCP/IP Setting - Windows XP
1.
Select Star Menu - Control
Panel - Network Connections
and click "Network
Connections".
2.
Right click the Local Area
Connection icon and select
Properties.
3.
Select the TCP/IP protocol
for your network card and
click the Properties button.
4.
If the DNS Server fields are
empty, select Use the
following DNS server
addresses, and enter the
DNS address or addresses
provided by your ISP, then
click OK.
5.
On the Gateway tab, enter the
DSA-3100's IP address in the
New Gateway field and click Add.
(Your LAN administrator can
advise you of the IP Address they
assigned to the DSA-3100.)
