Artesyn ATCA-F125 Quick Start Manual

ATCA-F125

Quick Start Guide

P/N:6806800K92C (May 2014)
1
What's in the box?
Make sure you receive all items of your
shipment:
• One ATCA-F125 blade
• One printed copy of Quick Start Guide
(this document)
• One printed Safety Notes Summary
• Other items that were ordered
When installing or servicing the
module or accessories, strictly
observe the safety precautions in
the Safety Notes. Otherwise, per-
sonal injury or property damage
may occur.
2
Observe ESD-safe
measures
• Use either a properly grounded ESD
wrist strap or make sure that you are
working in an ESD-safe environ-
ment.
• Connect to the ESD connector at the
front or the rear of the system.
3
Prepare the installation
site
• For information on the environmen-
tal and power requirements, see the
ATCA-F125 Installation and Use man-
ual.
• Operating temperatures refer to the
temperature of the air circulating
around the blade and not to the
actual component temperature.
4

Install the SATA storage

1. Attach the standoffs to the appropri-
ate holes in the HDD.
2. Attach the tape to the HDD making
sure the vent hole of the HDD is not
covered.
3. Assemble the SATA mounting plate
to the two brackets using four M3x3
mm screws
4. Attach the brackets to the HDD
using four M3x3 mm screws.
5. Install the HDD assembly and secure
it from the bottom side using the
four M3x5 mm screws. Torque
should be based on manufacturer's
recommendation.
5 5 5
Install the /QSFP+SFP+
modules
1. Slide the QSFP+/SFP+ module into
the slot until it locks into position.
2. Remove the optical port plug.
3. Connect the network cable to the
QSFP+/SFP+ module.
6

Install the PrAMC

1. If the AMC bay is occupied by an
AMC filler panel, remove it first.
2. Make sure that the AMC module
handle is in the extracted position:
pulled outward, away from the face
plate.
3. Carefully slide the AMC module
into the guide rails until resistance
is felt.
4. Apply equal and steady pressure on
the face plate as necessary until the
module is fully engaged with the
connector. Avoid using excessive
force.
5. Press the module handle inwards
toward the face plate to lock the
AMC module into the AMC bay.
