Artesyn RTM-ATCA-747x-10G Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RTM-ATCA-747x-10G
Installation and Use
P/N: 6806800S80B
May 2014
Arrow.com.
Downloaded from

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTM-ATCA-747x-10G and is the answer not in the manual?

Questions and answers

Related Manuals for Artesyn RTM-ATCA-747x-10G

Summary of Contents for Artesyn RTM-ATCA-747x-10G

  • Page 1 RTM-ATCA-747x-10G Installation and Use P/N: 6806800S80B May 2014 Arrow.com. Downloaded from...
  • Page 2 Artesyn reserves the right to revise this document and to make changes from time to time in the content hereof without obligation of Artesyn to notify any person of such revision or changes.

  • Page 3: Table Of Contents

    3.2.2 Keys ............... . 57 RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com.
  • Page 4 Related Documentation ............. . . 65 Artesyn Embedded Technologies - Embedded Computing Documentation ....65 RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com.
  • Page 5 Sensor Data Records ............63 Table A-1 Artesyn Embedded Technologies - Embedded Computing Publications ....65 RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com.
  • Page 6 List of Tables RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from...
  • Page 7 Location of Critical Temperature Spots (Top Side) ......35 Figure 2-2 Location of Temperature Sensors of RTM-ATCA-747x-10G-D (Variant #1) ..35 Figure 2-3 Location of Temperature Sensors of RTM-ATCA-747x-10G-SP (Variant #2) .
  • Page 8 List of Figures RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from...

  • Page 9: About This Manual

    Definition ANSI American National Standards Institute ATCA Advanced Telecommunications Computing Architecture Attention Baseboard Management Controller CISPR Comité Internationale Spécial des Perturbations Radioelectrotechnique Command RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from...
  • Page 10 IPMI Intelligent Platform Management Interface International Organization for Standardization JBOD Just a Bunch Of Disks Keyboard Controller Style Light Emitting Diode Least Significant Bit/Byte Logical Unit Number RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 11 SATA Serial ATA Sensor Data Record SELV Safety Extra Low Voltages Small Form-Factor Pluggable Underwriters Laboratory Inc. Universal Serial Bus VCCI Voluntary Control Council for Interference RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 12 Omission of information from example/command that is not necessary at the time being Ranges, for example: 0..4 means one of the integers 0,1,2,3, and 4 (used in registers) Logical OR RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 13 53, and Figure 3-8 on page Updated the sections Installing the Hard Disk Module on page Installing the RTM on page 42 Removing the RTM on page RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 14 About this Manual About this Manual RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from...

  • Page 15: Safety Notes

    The blade has been tested in a standard Artesyn system and found to comply with the limits for a Class A digital device in this system, pursuant to part 15 of the FCC Rules, EN 55022 Class A respectively.
  • Page 16 High humidity and condensation on the blade surface causes short circuits. Do not operate the blade outside the specified environmental limits. Make sure the blade is completely dry and there is no moisture on any surface before applying power. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com.
  • Page 17 Eye Damage Optical SFP modules may emit laser radiation when no cable is connected. This laser radiation is harmful to your eyes. Do not look into the optical lens at any time. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com.
  • Page 18 SFP module inoperable. Only remove the optical plug when you are ready to connect a cable to the SFP module. When no cable is connected, cover the port with an optical port plug. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com.

  • Page 19: Sicherheitshinweise

    Produkt mit vielfältigen Einsatzmöglichkeiten handelt, können wir die Vollständigkeit der im Handbuch enthaltenen Informationen nicht garantieren. Falls Sie weitere Informationen benötigen sollten, wenden Sie sich bitte an die für Sie zuständige Geschäftsstelle von Artesyn. Das System erfüllt die für die Industrie geforderten Sicherheitsvorschriften und darf ausschließlich für Anwendungen in der Telekommunikationsindustrie und im Zusammenhang...
  • Page 20 Sicherheitshinweise Das Blade wurde in einem Artesyn Standardsystem getestet. Es erfüllt die für digitale Geräte der Klasse A gültigen Grenzwerte in einem solchen System gemäß den FCC-Richtlinien Abschnitt 15 bzw. EN 55022 Klasse A. Diese Grenzwerte sollen einen angemessenen Schutz vor Störstrahlung beim Betrieb des Blades in Gewerbe- sowie Industriegebieten...
  • Page 21 Sicherheitsstandards entsprechen, kann Verletzungen zur Folge haben sowie zur Beschädigung des RTMs und von SFP-Modulen führen. Verwenden Sie daher nur SFP-Module, die zertifiziert sind und die den Sicherheitsstandards entsprechen. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 22 Die Schutzkappe eines SFP-Modules dient dazu, die sensible Optik des SFP-Modules gegen Staub und Schmutz zu schützen. Entfernen Sie die Schutzkappe nur dann, wenn Sie beabsichtigen, ein Kabel anzuschließen. Andernfalls belassen Sie die Schutzkappe auf dem SFP-Modul. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com.

  • Page 23: Introduction

    Chapter 1 Introduction Features The RTM-ATCA-747x-10G is a high performance AdvancedTCA Rear Transition Module, designed according to PICMG 3.0 Revision 3.0 AdvancedTCA Base Specification. The RTM- ATCA-747x-10G has the following variants: RTM-ATCA-747x-10G-D  RTM-ATCA-747x-10G-SP  The RTM-ATCA-747x-10G-D offers the following features: 4x10G interfaces using SFP+ modules ...

  • Page 24: Block Diagram

    Introduction Block Diagram Figure 1-1 shows the block diagram of RTM. Figure 1-1 RTM Block Diagram RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 25 Introduction The SAS switches can be implemented using discrete mount/no-mount option. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 26: Standard Compliances

    Description UL 60950-1 Legal safety requirements EN 60950-1 IEC 60950-1 CAN/CSA C22.2 No 60950-1 CISPR 22 EMC requirements on system level (predefined Artesyn Embedded Technologies system) EN 55022 EN 55024 FCC Part 15 EN 300386 NEBS Standard GR-1089 CORE ISO 8601...

  • Page 27: Figure 1-2 Declaration Of Conformity

    Introduction The following figures contains the Declaration of Conformity for RTM-ATCA-747x-10G Series. Figure 1-2 Declaration of Conformity RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 28: Mechanical Data

    Ordering Information The following table lists the product variants and accessories that are available upon release of this publication. Consult your local Artesyn Embedded Technologies sales representative for the availability of other variants and accessories. Table 1-3 Product Variants and Accessories...

  • Page 29: Product Identification

    R479 R703 R307 C301 R459 R474 CB24 R727 R848 C300 CD452 R321 R308 LABEL C257 C258 COUNTRY OF ORIGIN RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 30 Introduction RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from...

  • Page 31: Hardware Preparation And Installation

    3. Remove the desiccant bag shipped together with the blade and dispose of it according to your country’s legislation. The blade is thoroughly inspected before shipment. If any damage occurred during transportation or any items are missing, please contact our customer's service immediately. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com.

  • Page 32: Environmental And Power Requirements

    Blade Overheating and Blade Damage Operating the blade without forced air cooling may lead to blade overheating and thus blade damage. When operating the blade, make sure that forced air cooling is available in the shelf. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com.

  • Page 33: Table 2-1 Environmental Requirements

    Blade level packaging (with HDD Half-sine, 6 ms at 180 m/s Installed) Free Fall 1.2 m/ packaged (according to ETSI 300 019-2-2) 100 mm unpackaged (according to Telcordia GR-63-core) RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 34: Table 2-2 Critical Temperature Limits

    Quad Gigabit Ethernet LAN Controller 70 °C Four Port SAS Controller 70 °C Four Port PCI Express Switch 70 °C Temperature limit is valid when measured on the component heat sink. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 35: Figure 2-1 Location Of Critical Temperature Spots (Top Side)

    R308 LABEL C257 C258 COUNTRY OF ORIGIN SAS_TEMP EHT3_10G_TEMP EHT2_10G_TEMP Figure 2-2 Location of Temperature Sensors of RTM-ATCA-747x-10G-D (Variant #1) SAS CONTROLLER TEMP PCIe SWITCH TEMP AIR INLET TEMP ETHERNET_1G_TEMP ETHERNET_10G_TEMP ETHERNET_10G_TEMP AIR OUTLET TEMP RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com.

  • Page 36: Power Requirements

    Hardware Preparation and Installation Figure 2-3 Location of Temperature Sensors of RTM-ATCA-747x-10G-SP (Variant #2) AIR INLET TEMP ETHERNET_10G_TEMP ETHERNET_10G_TEMP PCIe SWITCH TEMP ETHERNET_10G_TEMP ETHERNET_1G_TEMP AIR OUTLET TEMP If you integrate the blade in your own system please contact your local sales representative for further safety information.

  • Page 37: Installing The Hard Disk Module

    Before touching the RTM or electronic components, make sure that you are working in an ESD-safe environment. Installing/removing the HDDs do not automatically invoke the OS intervention. The OS related steps have to be defined by the user. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com.

  • Page 38: Replacing The Hard Disk Module

    If the hot swap feature is not supported on your RTM, you cannot replace the hard disk module yourself. Please send the RTM to your local support representative to have the hard disk module replaced. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com.
  • Page 39 4. Pull the hard disk module outward by holding both screws and exerting equal force to keep it straight. 5. Align the replacement hard disk module to the guiding rails of the hard disk slot. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com.

  • Page 40: Installing And Removing The Rtm

    However, after the RTM is installed or replaced in a powered system the front blade has to be rebooted so that the OS can recognize the SAS controller or other PCI devices located on the RTM. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com.
  • Page 41 Installing the RTM with other blades than those listed in the table below may damage the RTM and the front blade. Only install the RTM with the Artesyn blades listed in the table below. Damage of Circuits Electrostatic discharge and incorrect RTM installation and removal can damage circuits or shorten their life.

  • Page 42: Installing The Rtm

    5. Apply equal and steady pressure to the RTM to carefully slide the RTM into the shelf until you feel resistance. Continue to gently push the RTM until the RTM connectors engage. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com.
  • Page 43 9. Plug interface cable into face plate connectors, if applicable. 10. Reboot the front blade. This is necessary so that the OS of the front blade can recognize the SAS controller or any other PCI device located on the RTM. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com.

  • Page 44: Removing The Rtm

    3. Remove interface cables from face plate connectors, if applicable. 4. Loosen the two RTM face plate screws. 5. Release the upper handle, just as in Step 1. 6. Remove the RTM from the slot. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com.

  • Page 45: Installing And Removing Sfp/Sfp+ Modules

    SFP/SFP+ modules can be installed/removed both while the RTM is powered and non- powered. The presence and also the type of SFP/SFP+ modules is automatically detected. The maximum power consumption of all installed SFP/SFP+ modules must not exceed 12W. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com.

  • Page 46: Sfp/Sfp+ Modules

    Finisar pluggable plus (SFP+) transceiver module - 850nm, SR, LC connector The SFP/SFP+ modules are not included as part of the RTM-ATCA-747x-10G deliverables. For more information on ordering them, contact your local Artesyn sales representative. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com.

  • Page 47: Installing An Sfp/Sfp+ Module

    Installing an SFP/SFP+ Module Procedure In order to install an SFP/SFP+ module, proceed as follows: 1. Slide SFP/SFP+ module into the slot until it locks into position. 2. Remove the optical port plug. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 48 Only remove the optical plug when you are ready to connect a cable to the SFP/SFP+ module. When no cable is connected, cover the port with an optical port plug. 3. Connect the network cable to SFP/SFP+ module RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com.

  • Page 49: Removing An Sfp/Sfp+ Module

    In order to remove an SFP/SFP+ module, proceed as follows. 1. Remove any connected cable from SFP/SFP+ module. 2. Open the SFP/SFP+ latch. Note that the latch mechanism of your SFP/SFP+ module RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com.
  • Page 50 Hardware Preparation and Installation may be slightly different compared to the latch shown in the following figure. 3. Grasp the SFP/SFP+ module and carefully slide it out of the slot. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 51 SFP/SFP+ module inoperable. Only remove the optical plug when you are ready to connect a cable to the SFP/SFP+ module. When no cable is connected, cover the port with an optical port plug. RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com.
  • Page 52 Hardware Preparation and Installation RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 53: Controls, Leds, And Connectors

    R479 R703 R307 C301 R459 R474 CB24 R727 R848 C300 CD452 R321 R308 LABEL C257 C258 COUNTRY OF ORIGIN RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 54: Face Plate

    1G/10G 1G/10G ETH3 ETH3 1G/10G 1G/10G ETH4 ETH4 1G/10G 1G/10G ETH5|6 ETH5|6 ETH7|8 ETH7|8 ETH9 1G/10G ETH10 1G/10G RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 55: Leds

    1G/10G 1G/10G ETH3 ETH3 1G/10G 1G/10G ETH4 ETH4 1G/10G 1G/10G ETH5|6 ETH5|6 ETH7|8 ETH7|8 ETH9 1G/10G ETH10 1G/10G RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 56: Face Plate Leds

    Blinking blue: Blade communicates with shelf manager OFF: Blade is active During blade removal: Blinking blue: Blade notifies shelf manager of its desire to deactivate Permanently blue: Blade is ready to be extracted RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 57: Keys

    On pressing it, a hard reset is triggered and all attached on-board devices are reset. You cannot reset the IPMC through Reset key. 3.2.3 Connectors The module provides the following connectors at its face plate: Ethernet    RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 58: Ethernet Connectors

    Controls, LEDs, and Connectors 3.2.3.1 Ethernet Connectors The RTM provides 4x10G (for RTM-ATCA-747x-10G-D) or 6x10G (for RTM-ATCA-747x-10G-SP) interface connectors and 4x1G Ethernet 10/100/1000Base-T interface connectors at its face plate. The location of the Ethernet connectors is shown in the following figure.

  • Page 59: Table 3-2 Ethernet Controller Types

    Intel 82599 (U40) 1G SFP,10G SFP+ ETH4 1G/10G ETH5/6 1G Intel i350 (U59) 10,100,1Gb Copper ETH7/8 1G ETH9 1G/10G Intel 82599 (U3) 1G SFP,10G SFP+ ETH10 1G/10G RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 60: Sas Connector

    Controls, LEDs, and Connectors 3.2.3.2 SAS Connector The RTM-ATCA-747x-10G-D blade provides one SAS connector at its face plate. The location of the connector is shown in the following figure. The RTM-ATCA-747x-10G-SP does not contain SAS connector. Figure 3-6 Location of SAS Connector RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com.

  • Page 61: Figure 3-7 Sas Connector Pinout

    Controls, LEDs, and Connectors The pinout of the serial interface connector is shown below. Figure 3-7 SAS Connector Pinout RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 62: Atca Backplane Connectors

    R479 R703 R307 C301 R459 R474 CB24 R727 R848 C300 CD452 R321 R308 LABEL C257 C258 COUNTRY OF ORIGIN RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 63: Sensor Data Records

    Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 64 Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 65: Related Documentation

    The publications listed below are referenced in this manual. You can obtain electronic copies of Artesyn Embedded Technologies - Embedded Computing publications by contacting your local Artesyn sales office. For released products, you can also visit our Web site for the latest copies of our product documentation.
  • Page 66 Related Documentation RTM-ATCA-747x-10G Installation and Use (6806800S80B) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 67 Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 68 Artesyn Embedded Technologies, Artesyn and the Artesyn Embedded Technologies logo are trademarks and service marks of Artesyn Embedded Technologies, Inc. All other product or service names are the property of their respective owners. © 2014 Artesyn Embedded Technologies, Inc. Arrow.com.
