Centellis 2100 Shelf Release 3.0
Installation and Use
P/N: 6806800T37D
August 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Centellis 2100 Shelf Release 3.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Artesyn Centellis 2100 Shelf Release 3.0

Summary of Contents for Artesyn Centellis 2100 Shelf Release 3.0

  • Page 1 Centellis 2100 Shelf Release 3.0 Installation and Use P/N: 6806800T37D August 2017...
  • Page 2 Artesyn reserves the right to revise this document and to make changes from time to time in the content hereof without obligation of Artesyn to notify any person of such revision or changes.

  • Page 3: Table Of Contents

    Mounting Options ..............74 Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 4 4.8.3 Storing the Filters ............123 Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 5 8.2.2 Shelf Geographical Address ..........145 Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 6 11.1.2.1 IPMI Firmware Upgrade ..........176 Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 7 Related Documentation ............. . 187 Artesyn Embedded Technologies - Embedded Computing Documentation ....187...
  • Page 8 Contents Contents Contents Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 9 Available Software Upgrade Tools ..........176 Table B-1 Artesyn Embedded Technologies - Embedded Computing Publications ... . . 187 Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 10 List of Tables Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 11 Blade Power-Down Before Extraction ........182 Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 12 List of Figures Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 13: About This Manual

    DHCP server and describes how to boot the blades from a TFTP server via network. Redundancy on page 169, contains information on cold standby, dual star network  topology and actions of shelf manager and system manager during switchover, takeover, failover, insertion, and extraction. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 14 Federal Communications Commission Firmware Upgrade Utility Field Replaceable Unit FUMI Firmware Update Management Instrument Hardware Platform Interface International Electric Code IP Multimedia Subsystem IPMB Intelligent Platform Management Bus IPMC Intelligent Platform Management Controller Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 15 Rear Transition Module SELV Safety Extra Low Voltage Shelf Geographical Address Shelf Manager ShMC Shelf Management Controller Secure Shell TFTP Trivial File Transfer Protocol Twisted-Pair Ethernet VCCI Voluntary Control Council for Interference Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 16 Repeated item for example node 1, node 2, ..., node Omission of information from example/command that is not necessary at the time being Ranges, for example: 0..4 means one of the integers 0,1,2,3, and 4 (used in registers) Logical OR Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 17 Figure 8-2. 6806800T37C May 2016 Removed AC and DC variants Declaration of Conformity. 6806800T37B August 2015 Updated AC Shelf Power requirements and DC Shelf Power requirements. 6806800T37A March 2015 Initial Version Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 18 About this Manual About this Manual Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 19: Safety Notes

    Artesyn intends to provide all necessary information to install and handle the product in this manual. Because of the complexity of this product and its various uses, we do not guarantee that the given information is complete.
  • Page 20 The equipment is suitable for installation in a Common Bonding Network (CBN) or Isolated Bonding Network (IBN). System Installation System Damage To avoid system damage verify that the system environment meets the environmental and power requirements given in this manual before installing the system. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 21 Personal Injury or System Damage (For AC) The system is supplied by AC mains primary voltage. This voltage is considered hazardous. Take appropriate precaution when cabling the system. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 22 Do not operate a damaged shelf, this can cause damage to devices that interfere with it. Personal Injury High leakage current can be hazardous and cause injury. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 23 Removing the RTM from the system while the payload of the front blade is powered up may damage the front blade and RTM. Whenever removing the RTM from the system, power down the payload of the front blade first. This does not apply to hot-swap RTMs. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 24 Make sure that the fresh air supply is not mixed with hot exhaust from other devices. Make sure that all slots are populated with either blades, filler blades, or dummy blades. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 25 To guarantee proper airflow through the system the air filters have to be replaced at least every six months. Artesyn recommends to replace the air filters every 90 days. Filter replacement frequency depends on the environment the system is subjected to.
  • Page 26 à la prise de terre. System Overheating If you reduce the blower speed via Hardware Platform Interface (HPI) the system temperature will rise. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 27 Do not wear any metallic attire or commodity on your hands, wrists, or hanging from your neck when working at the power input terminals or power input cables. Be extremely careful when you use electrically conductive tools near the PSUs/PEMs. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 28 Inserting or extracting the PEM with the PEM breaker in the ON position may damage your system. If power is connected to the shelf, make sure the PEM breaker is in the OFF position before you insert or extract a PEM. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 29 Make sure that there is always one operating fan tray present in the system. Personal Injury Rotating Fans Inserting tools or fingers into operational fans may cause injuries. Keep clear of the fans as long as they are rotating. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 30 The cabling should follow existing cable paths using existing or similar cable fastenings. Never change the system's cabling as delivered by Artesyn. Check proper function of the system after cabling extensions. To avoid injuries always ensure that cables are securely installed so that nobody can trip over them.
  • Page 31 Do not look into the optical lens at any time. Environment Environmental Damage Improperly disposing of used products may harm the environment. Always dispose of used products according to your country’s legislation and manufacturer’s instructions. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 32 Safety Notes Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 33: Sicherheitshinweise

    Verletzungen oder Schäden am System zur Folge haben. Artesyn ist darauf bedacht, alle notwendigen Informationen zum Einbau und zum Umgang mit dem System in diesem Handbuch bereit zu stellen. Da es sich jedoch bei dem System um ein komplexes Produkt mit vielfältigen Einsatzmöglichkeiten handelt, können wir die...
  • Page 34 Das Produkt ist für den Einsatz in Netzwerken mit gemeinsamem Potentialausgleich oder mit isoliertem Potentialausgleich geeignet. Systeminstallation Beschädigung des Systems Bevor Sie das System installieren, überprüfen Sie, ob die im Handbuch beschriebenen Anforderungen erfüllt werden. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 35 Betreiben Sie das System an einem erschütterungsfreien Ort, an dem weder Staub, Rauch noch elektrostatische Entladungen auftreten. Stellen Sie außerdem sicher, dass die klimatischen Bedingungen, die in diesem Handbuch spezifiziert sind, eingehalten werden und genug Raum für die Luftzirkulation vorhanden ist. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 36 Das System ist schwer, und eine unangemessene Handhabung kann zu Zerrungen oder Rückenschäden führen. Heben Sie deshalb das System nur zu zweit oder benutzen Sie zusätzliche Hilfsmittel. Verwenden Sie zum Heben des Systems nicht die Griffe der eingebauten Module. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 37 Wenn Sie RTMs und AdvancedTCA Boards in der falschen Reihenfolge installieren, können die RTMs und AdvancedTCA Boards beschädigt werden. Installieren Sie zuerst das RTM und erst danach das passende AdvancedTCA Board. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 38 Unsachgemäßer Ein- und Ausbau von Boards kann zu einer Fehlfunktion des Boards führen. Vergewissern Sie sich, dass das Board über alle Stecker an die AdvancedTCA-Backplane angeschlossen und die Stromversorgung gewährleistet ist. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 39 Beschädigung des Systems Luftfilter Verunreinigungen in der Luft können den Luftfilter verschmutzen und so die Luftzufuhr des Systems beeinträchtigen. Das kann zur Überhitzung des Systems und zu Schäden an Systemteilen führen. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 40 Sicherheitshinweise Um einen reibungslosen Luftstrom durch das System zu gewährleisten, sollten Sie die Luftfilter spätestens alle sechs Monate austauschen. Artesyn empfiehlt, die Filter alle 90 Tage auszutauschen. Wie häufig Sie die Filter austauschen müssen, hängt von der Umgebung ab, in der das System betrieben wird.
  • Page 41 Vermeiden Sie Kurzschlüsse, indem Sie sehr vorsichtig mit dem Werkzeug umgehen. Beschädigung des Systems Falscher Anschluss von Stromkabeln beschädigt das System. Achten Sie darauf, dass Sie das Stromkabel mit der richtigen Polarität anschließen. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 42 Wenn Sie den Trennschalter einer Spannungsversorgungseinheit (PEM) auf ON stellen, während ein Kurzschluss im System vorliegt, kann dies das PEM beschädigen. Stellen Sie deshalb sicher, dass kein Kurzschluss im System vorliegt. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 43 Berühren Sie die Lüfterschaufeln nicht, solange sie sich drehen. Shelf-Manager-und-Hub-Board Datenverlust Das Entfernen des Boards bei blinkender blauer LED kann zu Datenverlust führen. Warten Sie, bis die blaue LED dauerhaft leuchtet, bevor Sie das Board entfernen. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 44 Sicherheitshinweise Verkabelung/Kabelführung Verletzungsgefahr Verändern Sie nie die von Artesyn ausgelieferte Verkabelung des Systems. Stellen Sie sicher, dass die Verkabelung schon existierenden Kabelführungen folgt und bestehende oder ähnliche Befestigungen verwendet. Überprüfen Sie nach der Erweiterung der Verkabelung, ob das System ordnungsgemäß arbeitet.
  • Page 45 Strahlungsbelastungen führen. Schauen Sie niemals direkt in den Laserstrahl. Umweltschutz Umweltschäden Unsachgemäße Entsorgung von Produkten kann zu Umweltbelastungen führen. Entsorgen Sie gebrauchte Produkte stets gemäß der in Ihrem Land gültigen Gesetzgebung und den Empfehlungen des Herstellers. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 46 Sicherheitshinweise Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 47: Introduction

    Chapter 1 Introduction The Artesyn Embedded Technologies Centellis™ 2100 platform core is a high availability platform ideally suited for data intensive, central office, and enterprise networking applications. The low profile makes the Centellis 2100 the optimal candidate for distributed networking functions, low density subscriber areas, or specialized applications.

  • Page 48: Shelf Overview

    Two slots which can be equipped with application specific user cards  Two shelf management slots  Front and rear ESD wrist strap attachment points  Rear grounding studs  Figure 1-1 AC System Front View Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 49: Figure 1-2 Dc System Front View

    Introduction Figure 1-2 DC System Front View Figure 1-3 AC System Rear View Figure 1-4 DC System Rear View Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 50: Shelf

    : Fabric interface configurations support 1G, 10G and 40G operation 1.2.2.1 Node slots The backplane in Centellis 2100 Shelf Release 3.0 shelf provides two node slots, oriented horizontally in the lower and upper part of the shelf. They are accessible from the front of the shelf.

  • Page 51: Rear Transition Modules

    The node slots can be connected to rear transition modules (RTM) to provide easy access to I/O signals through the zone 3 connector defined by the AdvancedTCA specification. The Artesyn RTMs can be used as rear expansion boards for node blades to access the different interfaces on an AdvancedTCA blade through the RTM faceplate.

  • Page 52: Figure 1-5 Atca-Mf106 Hub Interfaces

    Port 0 Port 4 Port 1 Port 2 Port 3 Port 2 Port 3 Ch #1 Ch #1 Ch #2 Ch #2 IPMC IPMC ATCA Blade (Slot #1) ATCA Blade (Slot #2) Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 53: Mini-Hub Port Mapping

    AC Power Supply Unit and DC Power Entry Modules The Centellis 2100 supports up to two redundant AC power supplies, or up to two field hot- swappable DC PEMs with a 30 A breaker with line filtering. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 54: Fan Trays

    Spare pins for at least four bidirectional LVDS ports Power connector  Use the TYCO 5646956-3, pin power connector. The backplane power connector provides the following signals: – Redundant -48 VAC/VRTN – Shelf ground Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 55 When installing and using optical SFP/SFP+ modules which are classified as laser products, make sure to comply to the respective regulations. Designers of user cards should contact the Artesyn Embedded Technologies engineering team to obtain the detailed pin-out of the backplane connectors and mechanical data.

  • Page 56: Shelf Management

    AdvancedTCA systems and its purpose is to ensure proper operation of AdvancedTCA blades and other system components like fans and Rear Transition Modules (RTMs). Figure 1-6 Shelf Management Architecture Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 57: System Management

    The system manager function is provided by the end user and is responsible for managing one or more Centellis 2100 shelves. The shelf manager of the ATCA-MF106 board provides an interface (Hardware Platform Interface, HPI) to monitor and control the assigned shelves. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 58: Figure 1-7 Advancedtca System Management

    Introduction Note: System Services Framework (evaluation license included) provides an easy way to set up and manage an Artesyn platform with an attractive web browser-based graphical user interface, command line interface or XML interface. Figure 1-7 AdvancedTCA System Management The shelf manager provides the information about the shelf and all its FRUs via the following...
  • Page 59 For more information on HPI and RMCP, see the System Management Interface Based on HPI-B (Centellis CO31kX/4100/2000) User's Guide. For debugging and maintenance purposes, you can also access the shelf manager via a Command Line Interface (CLI). Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 60: Standard Compliances

    FCC Part 15 Industry Canada ICES-003 NEBS Standard GR-1089 CORE VCCI Japan ETSI ETS 300 753 Environmental requirements NEBS Standard GR-63-CORE ETSI EN 300 019 series ETSI EN 300 132-2 Power requirements Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 61 The system is compliant to NEBS and ETSI acoustic noise emission standards, if the system is equipped with Artesyn blades and with properly designed and configured third party blades. In a system thus configured, the fans will settle at approximately 10%-20% speed at an ambient temperature of 23 °C (+/- 2 °C) (73.4 °F +/- 3.6 °F) under normal operating conditions.
  • Page 62 To dispose of equipment marked with the WEEE symbol, Artesyn has contracted with certified companies that can reprocess this equipment per European Union requirements. Please visit the Artesyn web site or contact your Artesyn representative to find out whom to contact and how to dispose of the equipment.

  • Page 63: Ordering Information

    Consult your local sales representative for ordering information on spare parts not listed. Figure 1-8 AC and DC Sample Shelf Label Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 64: Table 1-2 Ordering Information Excerpt

    CENT-2000/2100 ANSI 24" Frame MTG BRKT kit C2000-CBLTR CENT-2000/2100 cable tray bracket (One unit) AXP-F-FILL-PANEL Blank filler panel, AXP1620, AXP1440, AXP1410, C2000/C2100 - Front AXP-R-FILL-PANEL Blank filler panel, AXP1620, AXP1440, AXP1410, C2000/C2100 - Rear Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 65 Centellis 2100 Front Fan Tray Module - Black CENT-2100-RFTM Centellis 2100 Rear Fan Tray Module CENT-2000-PSU Centellis 2000/2100 AC Power Supply Unit - Black CENT-2000-SFM Centellis 2000/2100 Replacement Air Filter (One unit) Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 66 Introduction Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 67: Site Preparation

    Compare the shipment thoroughly with the delivery note. 5. Visually inspect the shelf to ensure that all of the connector pins are straight, shrouds are properly seated, screws are tight, etc. 6. Check the rails for proper alignment. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 68: Planning Site And Installation

    There should be a inlet and outlet of the fans and therefore the airflow is not blocked  For Installation in restricted access location  For use by trained personnel  Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 69: Requirements

    Some of the climatic values may exceed the specification of some system components  (for example, hard disks). As Artesyn cannot guarantee the functionality of third party products that are handled or operated out of their specifications, the environmental conditions may be limited to the specifications of these components.
  • Page 70 The fan speed is adjusted to the lowest speed which still keeps the evaluated temperature readings below or at their respective "upper non-critical threshold". Hence, the fan speed depends on the ambient temperature, blade design, temperature threshold settings, and system configuration. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 71: Table 2-2 Critical Temperature Limits

    “hot surface” icon is attached. The cables must be approved to be used in this temperature range. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 72: Power Requirements

    PSU Subsystem 6.15 Fan Subsystem 10G Uplink Subsystem Shelf Management ATCA Blades (Two at 400 W or one at 500 W and one at 300 W) Total Shelf Power 47.15 1120 Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 73: Dimensions And Weight

    90 x 63 x 303 1.33 DC PEM 90 x 63 x 303 1.37 Front fan tray 134 x 92 x 337 0.52 Rear fan tray 134 x 92 x 210 0.57 Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 74: Mounting Options

    If the rack is equipped with stabilizing devices, make sure that they are installed and extended so that the rack is secure. Then proceed to mount or service the system. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 75: Cooling Considerations

    Each tray houses two fans, one pair located at the front, the other at the rear of the shelf. The airflow direction is from front to rear in the chassis. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 76: Acoustic Noise Control

    This system has a built-in noise control due to the fan speed control. If the system is installed in an environment where the noise may be harmful to personnel being exposed to the noise during extended time periods, additional protective measures should be considered. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 77: System Installation

    1 mm To maintain the maximum power rating of the Centellis 2100 DC, the power input cables must have a minimum cross section of 2.5 mm , AWG 12. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 78: Tools You Will Need

    The following table describes the torque values used while handling and maintaining the system. Table 3-1 Torque Values For... Value in N m Ground nuts Pluggable screw terminals Captive screws on MF106 Thumb screws for FRUs Thumb screws on AdvancedTCA blades Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 79: Installation

    NEC Table 310.16 and other national regulations. AC PSU input is fused at 16A. External wiring and circuit interruption should be sized accordingly. Artesyn is not responsible for regulatory compliance or malfunction of any user-modified product. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 80: Installing The System In A Rack

    For Centellis 2100 AC, use power input cables with a cross section (minimum) of 1 mm For Centellis 2100 DC, use power input cables with a cross section (minimum) of 2.5 mm AWG 12. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 81 The shelf is also fitted with ESD snaps for the use with conductive wrist straps. Please take care for proper ESD protection of the operator. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 82: Figure 3-1 Rack Mounting Dimensions

    The following clearances are required when installing the system into an at least 600 mm (23.62 inch) deep rack. The physical dimensions in the figure below are in millimeters. Make sure that 60% of the rack's rear is open. Figure 3-1 Rack Mounting Dimensions Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 83: System Grounding/Bonding

    Always be sure that equipment is properly grounded and that you follow proper grounding procedures before beginning any installation procedure. Figure 3-2 System’s Ground Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 84: Powering-Up The System

    Table 3-1 for torque values. The lugs are marked with the corresponding grounding symbol. Artesyn recommends to use an earth grounding cable with a two-hole lug, distance 5/8" (15.9 mm). Grounding cable of size 1.25 mm for AC system, and 2.5 mm...

  • Page 85: Ac System Startup Procedure

    5. Connect the AC International Electric Code (IEC) wired connector to the AC power supplies. Product Damage Improper cabling damages your product. Take extreme care not to connect the power cable in reverse polarity. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 86 System Installation 6. Turn on the external power supply. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 87: Dc System Startup Procedure

    2. Connect the strap to the shelf by attaching the front or rear ESD jack/ESD snap. 3. Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all times. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 88 7. Crimp the ends of the power cables. 8. Loosen the screws on both sides of the pluggable screw terminals. 9. Remove the pluggable screw terminals from the rear of the shelf. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 89 11.Fasten the screws at the bottom of the pluggable screw terminals. 12.Plug the screw terminals (including the attached power cables) to the power connectors. 13.Fasten the screws on both sides of the pluggable screw terminals. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 90 The power is connected correctly. You may switch on the breaker now. In LED (green) on 16.Push the breaker to the ON position. The BP LEDs (on the right) indicate that power is available to the backplane from the power supply. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 91: Removal

    Removing the system  3.3.1 Powering Down the System For data integrity reasons Artesyn recommends to save data and close all applications before powering down the system. AC System Power-Down Procedure To power down the AC system, proceed as follows: 1.

  • Page 92: Disconnecting The System From Power Supply

    2. To ensure that the PSUs are not energized, verify that the LEDs on the front of the power supplies are off. 3. Loosen the connector fastening screws at both sides of the pluggable screw terminals. 4. Disconnect the AC power cords from the system. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 93: Dc System Disconnection Procedure

    2. To ensure that the PEMs are not energized, verify that the In LEDs (in the middle) are off. 3. Loosen the connector fastening screws at both sides of the pluggable screw terminals. 4. Remove the pluggable screw terminals. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 94: Removing The System

    2. Disconnect all cables from the blades, RTMs, ATCA-MF106 and user cards. 3. Remove the grounding connections. 4. Loosen and remove the mounting screws. 5. Remove the system from the rack. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 95: Fru Installation

    Centellis 2100 shelf, and the upper handle corresponds to the left handle. For RTMs which are mounted at the rear, the upper handle corresponds to the right handle and the lower handle to the left handle. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 96: Replacing The Shelf Manager And Hub Board

    ATCA-MF106. If the shelf contains only one ATCA-MF106, you have to power down the shelf before exchanging the ATCA-MF106. For more information on the ATCA-MF106, refer ATCA-MF106 Installation and Use manual. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 97 Before touching the product make sure that your are working in an ESD-safe environment or wear an ESD wrist strap or ESD shoes. Hold the product by its edges and do not touch any components or circuits. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 98 The handle switch activator triggers the blinking of the blue LED. The hot swap state remains in the state “extraction pending”, so that the blue LED is still blinking. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 99: Covering Unused Slots

    8. Attach cables to the front panel connectors as necessary. Covering Unused Slots All unused slots of the shelf must have Artesyn approved filler blades. Filler blades are available from Artesyn. The user card slots are populated with filler blades from the factory.

  • Page 100: Replacing Ac Power Supply Units

    3. Switch the external disconnect device of the PSU to be replaced to the OFF (tripped) position, if it is not already in this position. 4. Unfasten the two captive screws of the PSU. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 101 5. Remove the PSU from the shelf bay by pulling the PSU handle. 6. Insert the replacement PSU. 7. Fasten the two PSU captive screws. 8. Turn on the power supply if it is not already turned on. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 102: Replacing Dc Power Entry Modules

    10.Switch the external disconnect device to the ON position. 11.Verify that the green PSU LED is lit. Replacing DC Power Entry Modules This section describes the procedure for the replacement of the power entry modules (PEMs). Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 103 Hot PEMs may cause injury. Allow the PEM to cool before servicing. 1. Put on an ESD wrist strap. 2. Connect the strap to the shelf by attaching the front or rear ESD jack/ESD snap. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 104 5. Remove the PEM from the shelf bay by pulling the PEM handle. 6. Insert the replacement PEM. 7. Fasten the two PEM captive screws. 8. Switch the breaker to the ON position. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 105 Reverse LED (red) off The power is connected correctly. You may switch on the breaker now. In LED (green) on 10.Verify that the green BP LED (on the right) is lit. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 106: Installing Circuit Breaker Cover For Dc Pems

    PEM. When installing the cover, make sure to remove only one screw at a time so that the circuit breaker switch does not get pushed into the PEM. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 107 Do not fully tighten the screw so that the cover can be adjusted to align with the second screw. 2. Unfasten the second screw and attach the cover. 3. Fasten the two screws. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 108: Replacing Fan Trays

    Before touching the product make sure that your are working in an ESD-safe environment or wear an ESD wrist strap or ESD shoes. Hold the product by its edges and do not touch any components or circuits. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 109 If the control board has failed, the fan will be operating at 100% speed. Personal Injury Rotating Fans Inserting tools or fingers into operational fans may cause injuries. Keep clear of the fans as long as they are rotating. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 110 3. Grasp the handle and pull the tray carefully out of the shelf. Personal Injury Rotating Fans Inserting tools or fingers into operational fans may cause injuries. Keep clear of the fans as long as they are rotating. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 111 FRU Installation 4. Take the replacement fan tray and insert it into the shelf. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 112 FRU Installation Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 113: Maintaining Air Filters

    7. Query the shelf manager to ensure the fan tray is operating properly. Maintaining Air Filters Routine filter maintenance is required to ensure that the shelf operates efficiently. The following section describes the procedure for the replacement and storage of the air filters. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 114: Replacing The System Filters

    To guarantee proper airflow through the system the air filters have to be replaced at least every six months. Artesyn recommends to replace the air filters every 90 days. Filter replacement frequency depends on the environment the system is subjected to.
  • Page 115 If you have difficulties in removing the frame with your fingers, you can also use a tool such as a screw driver. In this case, pay attention not to damage the frame or the shelf. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 116 FRU Installation 5. Pull the frame carefully out of the shelf. 6. Detach the air filter from the frame. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 117 10.Slide the frame into the slot until you feel resistance. 11.Push the frame upward until it snaps in. 12.Replace the bottom air filter or insert the front fan tray as described in section Replacing Fan Trays on page 108. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 118 If you have difficulties in removing the frame with your fingers, you can also use a tool such as a screw driver. In this case, pay attention not to damage the frame or the shelf. 3. Pull the frame carefully out of the shelf. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 119 7. Press the air filter to the hook-and-loop fastener on the frame. 8. Insert the frame into the shelf by placing the right edge in the guide. 9. Slide the frame into the slot until you feel resistance. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 120 The shelf contains two filter sensors. An error will be generated when the shelf is operating with the filter removed. For a description of the filter sensors refer to the ATCA-MF106: Control via IPMI Reference Guide. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 121: Replacing The Ac Psu Air Filter

    To guarantee proper airflow through the system, the air filters have to be replaced at least every six months.Artesyn recommends to replace the air filters every 90 days. Filter replacement frequency depends on the environment, the system is subjected to.
  • Page 122 When AC PSU is on, be careful of the rotating fans behind the hex grill. 2. Remove the old air filter and place the new filter into the frame. Make sure that the cutout notch is oriented towards the top to clear the status light. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 123: Storing The Filters

    ° ° ° Artesyn does not recommend storing foam filters for many months or years at a time. Purchase enough to keep adequate inventory for no more than a few months. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 124 FRU Installation Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 125: Non-Field-Replaceable Units

    Redundant SEEPROMs for storage of shelf FRU data  The following interfaces are located within the zone 2: Base interface  Fabric interface  Update channel interface  Synchronization clock interface  Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 126: Base Interface

    The base interface is fully compliant to the PICMG 3.0 R3.0 Specification. Therefore, details are not described within this chapter. For more information, see the ATCA-MF106 Installation and Use and the PICMG 3.0 R3.0 Specification. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 127: Fabric Interface

    The fabric interface is fully compliant to the PICMG 3.0 R3.0 Specification and the 10GBASE-KR standard. Therefore, details are not described within this chapter. For more information, see the PICMG 3.0 R3.0 Specification. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 128: Update Channel

    Alarm State LED Color Minor AMBER Major Critical The signaling is controlled by the system manager via commands via ATCA-MF106. The alarm states are controlled by the system manager. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 129: Power Inlet

    PSU/PEM input connectors as well as connectivity for safety ground to the system. For further information on the power supplies and the power distribution, refer to section Power Subsystem on page 133. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 130 Non-Field-Replaceable Units Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 131: Cooling Subsystem

    The shelf manager controls the fan speed based on sensor and failure information acquired from fan and board sensors. If a fan tray loses IPMI communication to the shelf manager, it automatically runs its fan motor at full speed. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 132 Cooling Subsystem Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 133: Power Subsystem

    Redundancy such that a single PEM failure will still provide full power to the system  Hot-swap  Power filtering  30 A Circuit Breaker  The PEM supports the complete functionality as defined by the PICMG 3.0 specification. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 134: Power Distribution

    ShMC, fan tray, node and user card slot. In both interconnects, the FRUs are expected to OR the two sources to allow for redundancy. The PSUs are capable of supplying 16 A of current. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 135: Figure 7-1 Two-Psu Shelf Power Distribution

    For the blades, power is distributed as defined in the PICMG 3.0 Specification. The following figure illustrates the power distribution system as it pertains to the FRUs found in the two-PSU shelf. Figure 7-1 Two-PSU Shelf Power Distribution Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 136: Dc Power Interconnect

    For the blades, power is distributed as defined in the PICMG 3.0 Specification. The following figure illustrates the power distribution system as it pertains to the FRUs found in the two-PEM shelf. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 137: Ac Psu Specifications

    Power Subsystem Figure 7-2 Two-PEM Shelf Power Distribution 7.1.4 AC PSU Specifications The following sections outline the power input and the power filtering. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 138: Ac Psu Input Power Requirements

    Primary-secondary and primary to ground (PE) isolation shall follow EN60950 and harmonized international applicable standards. AC PSU input is fused at 16 A. External wiring and circuit interruption should be sized accordingly. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 139: Ac Psu Output Specifications

    The DC PEM is equipped with input power filtering. The filter provides transient voltage immunity conforming to IEC 61000-4-4 Part 4 for electronic fast transient/burst immunity, test level 1 in accordance with NEBS generic EMC requirements. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 140 Power Subsystem Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 141: Network Management And System Access

    The ATCA-MF106 stores the shelf FRU data and the SGA persistently. Access via the faceplate interface: ATCA-MF106 IP Address Left MF106 192.168.<SGA>.8 Right MF106 192.168.<SGA>.9 Active MF106 192.168.<SGA>.171 Standby MF106 192.168.<SGA>.181 Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 142: Network Management

    When you need to access system components, there are various network addresses you need to be aware of. The following subsections describe the default addresses and how they can be changed. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 143: Slot Numbers And Slot Addresses

    Port 0 Port 4 Port 1 Port 2 Port 3 Port 2 Port 3 Ch #1 Ch #1 Ch #2 Ch #2 IPMC IPMC ATCA Blade (Slot #1) ATCA Blade (Slot #2) Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 144: Table 8-1 Slot Numbering And Slot Addresses

    Logical Slot Device# Address Address Number MF106 1 MF106 2 Front Blade 1 Front Blade 2 PSU 1 PSU 2 Rear Fan Tray Front Fan Tray User Card 1 User Card 2 Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 145: Shelf Geographical Address

    The ATCA-MF106 boards will come up with changed IP addresses. 8.2.2.2 Shelf Manager Replacement Scenarios This subsection describes different scenarios of replacing the shelf manager and determining the shelf FRU information. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 146: Ip Addresses

    ATCA-MF106. The shelf manager sets up these interfaces based on the information found in the shelf manager IP connection record of the shelf FRU information. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 147 IP address remains the same on each shelf manager when the shelf managers switch their active and standby roles. The virtual IP address is moved from the former active to the former standby shelf manager when they change their roles. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 148: Out-Of-Band Interface

    Physical IP Address Default Value 255.0.0.0 <IP1_1>.<IP1_2>.<SGA>.<HW> 192.168.0.8, 192.168.0.9 255.255.0.0 255.255.255.0 Virtual Active IP Address on Out-of-Band Interface Netmask of IP1 Virtual Active IP Address Default Value 255.0.0.0 <IP1_1>.<IP1_2>.<SGA>.171 192.168.0.171 255.255.0.0 255.255.255.0 Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 149 If the third octet of the IP address is changed using hpiship tool, it is temporary and will be changed automatically on the next reboot to match the shelf address. 3. Reboot the system for the changes to take effect. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 150 #hpishaddr shelf address type=BINARY, length=20: 09 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 shelf id: 9 shelf entity-path: {ADVANCEDTCA_CHASSIS,9} Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 151: Backplane Interfaces

    Use shelf manager hardware address as fourth octet.  Physical IP Address on Backplane Interface 1 Netmask of IP2 Physical IP Address Default Value 255.0.0.0 <IP2_1 + 1>.<IP2_2>.<SGA>.<HW> 172.17.0.8, 172.17.0.9 255.255.0.0 <IP2_1>.<IP2_2 + 1>.<SGA>.<HW> 255.255.255.0 <IP2_1>.<IP2_2>.<IP2_3 + 1>.<HW> Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 152 Modify the first two octets of the shelf IP connectivity Record #2  Change the shelf address  Modify the first two octets of the shelf IP connectivity Record #2 and also change the shelf  address Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 153 29 {ADVANCEDTCA_CHASSIS,9} Shelf Resource 4097 Shelf Manager IP Address 0 IP : 192.168.9.171 Gateway: 192.168.9.0 Submask: 255.255.255.0 8449 Shelf Manager IP Address 1 IP : 172.16.9.171 Gateway: 172.16.0.170 Submask: 255.255.0.0 *Change backplane address: Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 154: Configuration File

    (default), using DHCP, or by specifying a static IP address. Use the following parameters to the OOB_MODE variable to define the out-of-band interface configuration. none - Do not configure the interface Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 155 Static Configuration of the Backplane Network Interface If using the static parameter to configure the backplane interfaces, specify the desired IP addresses and netmasks using the following variables: BP_A_IPADDR= BP_A_NETMASK= BP_B_IPADDR= BP_B_NETMASK= Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 156 Enabling the DHCP Server  A DHCP server can be started on the out-of-band or backplane interfaces. To enable the server, specify "yes" to any combination of the following variables: OOB_DHCP_SERVER= BP_A_DHCP_SERVER= Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 157 - Do not configure the default route auto - Automatic configuration of the router static - Use other parameters to configure the router GATEWAY_MODE=auto – Static Configuration of the Default Route Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 158: Restoring Factory Settings

    1. Login either through the serial port, or by using ssh to the Shelf Manager. 2. Remove everything in the persistent file area. For example: cd /usr/local , rm -rf * 3. Reboot the Shelf Manager. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 159 Network Management and System Access Shelf Manager boots up using the factory settings. This does not include the Shelf IP addresses or Shelf Geographical Address stored in the Shelf FRU data. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 160 Network Management and System Access Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 161: Configuration And Network Boot

    The blades must have access to the DHCP server and to the TFTP server to retrieve files. Note that the kernel and ramdisk images are dependent on the blades plugged into the shelf and, therefore, are not part of this delivery. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 162: Preparing A Tftp Server For Network Boot And Installation

    Configuring a TFTP Server To configure TFTP as root on the host, proceed as follows: 1. Create (or edit) the file /etc/xinetd.d/tftp. Use the following format: #/etc/xinetd.d/tftp service tftp{ Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 163 ... 4. In the /tftpboot/pxelinux.cfg directory, create a softlink for the blade’s MAC address to the default.<boardname> file: ln –s default.<boardname> <MAC address with leading 01 and "–" as delimiter> Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 164: Preparing A Dhcp Server For Network Boot

    // fixed IP address which will be assigned to the client // according to the network addressing scheme fixed-address 192.168.9.111; // initial boot file which is to be loaded by the client filename "pxelinux.0"; Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 165 // fixed IP address which will be assigned to the client // according to the network addressing scheme, e.g. fixed-address 192.168.9.122; // initial boot file which is to be loaded by the client filename "pxelinux.0"; Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 166: Mini-Hub Configuration

    "hub- script" file. An example of a modified file is included here: # Enable L2 managed mode swinit # Create vlan 2 (untagged) with ports 0-3 Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 167 Configuration and Network Boot vlan create 2 vlan add 2 0-3 untag pvlan 0-3 2 # Create vlan 3 (tagged) with ports 0-4 vlan create 3 vlan add 3 0-4 Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 168 Configuration and Network Boot Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 169: Redundancy

    Closing of all open HPI sessions on the client's side. They have to be reestablished. Any  blocking HPI calls have to be avoided (for example, saHpiGetEvent) and calls with timeouts have to be used instead. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 170: Heartbeat

    10.1.2 System Manager If the system manager accesses the active shelf manager via the backplane Ethernet interfaces, it may use virtual IP plane and active virtual IP address 192.168.0.171 of the shelf manager. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 171: Redundancy Operations

    10.1.3.2 Shelf Manager Takeover Takeover is a process to switch the active and the standby roles of the ATCA-MF106. The system manager initiates and controls this process on the standby shelf manager. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 172: Shelf Manager Failover

    An IP plane failover is not needed and the connection to the applications via the same interface as before is kept. If the virtual IP address of the shelf manager is used, a plane failover is necessary. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 173: Shelf Manager Insertion

    It can be safely extracted afterwards. This is indicated by a solid illuminated blue LED on the front panel of the ATCA-MF106. The active shelf manager sends an HPI redundancy event (redundancy lost) to the system manager. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 174 Redundancy Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 175: Software

    IPMC firmware 11.1.1 BBS Installation If your Centellis 2100 shelf is equipped with Artesyn node blades, you need to install the Basic Blade Services (BBS) software on the node blades as described in the respective Basic Blade Services Software Programmer’s Reference. The BBS installation automatically installs all necessary files.

  • Page 176: Firmware Upgrade

    Please refer to the Release Notes to find out about software dependencies. 11.1.2.1 IPMI Firmware Upgrade Centellis 2100 Fan Tray IPMI Firmware: The fcu utility can be used to upgrade the Centellis 2100 Fan tray with the following syntax: Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 177: Hubcfg Utility

    <port_list> - to display the status of the links  Example: MDK.0> portmode 0-4 Port 0: 100fd, auto-neg, link up Port 1: 10fd, auto-neg, link up Port 2: 1000fd, auto-neg, link up Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 178 Port 3 statistics: Tx packets 6509 Tx bytes 417676 Tx errors Rx packets Rx bytes 6170 Rx errors Rx drops MDK.0> vlan create <vlan_id> - to create a new vlan  Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 179 MDK.0> vlan destroy 5 MDK.0> pvlan <port_list> [<vlan_id>] - show or set default vlan for the specified ports  Example: MDK.0> pvlan 0-3 2 MDK.0> All commands have help available:  Example: Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 180: Blade Insertion And Extraction

    This section describes the steps that are carried out by the software when a blade is inserted or supposed to be extracted. For the actual hardware installation procedures refer to the documentation of the blade. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 181: Power-On After Blade Insertion

    To change this, you need to change the shelf FRU information via the HPI FRU activation control. The default for the Auto Insert Timer in HPI is 60 s. Figure 11-1 Blade Power-On After Insertion Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 182: Power-Down Before Blade Extraction

    It may take a long time before the payload has finished carrying out all necessary steps and the blade can be powered down. Figure 11-2 Blade Power-Down Before Extraction Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 183: Troubleshooting

    Some component was jarred Check that components are loose during shipping. seated properly and the thump- wheel screws are tight. Pins in a backplane connector are Contact Artesyn Technical bent or broken. Support Services. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 184 In LED is green, but the BP position. LED (on the right) stays off. The PEM is defective. Replace the PEM. Remove and insert a PEM always with the breaker switched to the OFF position. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 185: Fans

    The red LED blinks and the The shelf FRU information of the Specify which shelf FRU boards are not powered boards is different. information is correct. Refer to section Shelf Manager Replacement Scenarios on page 145. Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 186 Troubleshooting Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)

  • Page 187: Related Documentation

    The publications listed below are referenced in this manual. You can obtain electronic copies of Artesyn Embedded Technologies - Embedded Computing publications by contacting your local Artesyn sales office. For released products, you can also visit our Web site for the latest copies of our product documentation.
  • Page 188 Related Documentation Centellis 2100 Shelf Release 3.0 Installation and Use (6806800T37D)
  • Page 190 Artesyn Embedded Technologies, Artesyn and the Artesyn Embedded Technologies logo are trademarks and service marks of Artesyn Embedded Technologies, Inc. All other product or service names are the property of their respective owners. © 2017 Artesyn Embedded Technologies, Inc.

Table of Contents
