  • Page 1 ATCA-F125 (6873M Artwork) Installation and Use P/N: 6806800J94L September 2015...
  • Page 2 Artesyn reserves the right to revise this document and to make changes from time to time in the content hereof without obligation of Artesyn to notify any person of such revision or changes.

  • Page 3: Table Of Contents

    2.8.2 Removing an SFP Module ........... . . 59 ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 4 4.7.2 ShMC Cross-Connect ............95 ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 5 Power-On Self Test ..............124 ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 6 5.10 ATCA-F125-Specific U-Boot Environment Variables ........
  • Page 7 Reset Signals ..............110 ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 8 Table 5-9 ATCA-F125 Specific U-Boot Environment Variables ....... .128 Table B-1 Artesyn Embedded Technologies - Embedded Computing Publications .
  • Page 9 ATCA-F125 Face Plate ........
  • Page 10 List of Figures ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)

  • Page 11: About This Manual

    Abbreviations This document uses the following abbreviations: Abbreviation Definition ATCA Advanced Telecom Computing Architecture Advanced Mezzanine Card IPMI Intelligent Platform Management Interface IPMC Intelligent Platform Management Controller JTAG Joint Test Action Group ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 12 Repeated item for example node 1, node 2, ..., node Omission of information from example/command that is not necessary at the time being Ranges, for example: 0..4 means one of the integers 0,1,2,3, and 4 (used in registers) ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 13 Figure "Declaration of Conformity" on page Edited Table "Faceplate LEDs" on page 6806800J94B March, 2012 Updated Chapter 4, Functional Description, on page Chapter P, EMC, on page 118, and Chapter P, Installation, on page 119. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 14 Replaced “Product Name Short” with ATCA- F125. 6806800J94H January, 2014 Updated Table 3-3 on page 6806800J94J April, 2014 Re- branded to Artesyn template. 6806800J94K August 2014 Removed instances of Stratum 3E and updated Declaration of Conformity. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)

  • Page 15: Safety Notes

    Artesyn Embedded Technologies and our suppliers take significant steps to make sure that there are no bent pins on the backplane or connector damage to the boards prior to leaving the factory.
  • Page 16 (EMI) shielding to maintain EMC compliance. Board products are tested in a representative system to show compliance with the above mentioned requirements. A proper installation in a compliant system maintains the required performance. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 17 Blade Damage Incorrect installation of the blade can cause damage of the blade, Only use handles when installing/removing the blade to avoid damage/deformation to the face plate and/or PCB. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 18 Overheating and Blade Damage Operating the blade without forced air cooling may lead to overheating and thus damage of the blade. When operating the blade, make sure that forced air cooling is available in the shelf. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 19 Setting/resetting the switches during operation can cause damage to the product. Check and change switch settings before you install the product. Product Damage Too much force may damage the reset switch. Use minimal force when pressing the reset switch. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 20 Installing AMC modules with small operating temperature ranges into the ATCA-F125 may further restrict the operating temperature range of the ATCA-F125. Make sure that the operating temperature of any installed AMC modules and the ATCA-F125 as a bundle are within allowed limits...
  • Page 21 Installing another battery type than the one that is mounted at product delivery may cause data loss since other battery types may be specified for other environments or may have a shorter lifetime. Only use the same type of lithium battery as is already installed. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 22 Do not use a screw driver to remove the battery from its holder. Environment Environmental Damage Improperly disposing of used products may harm the environment. Always dispose of used products according to your country’s legislation and manufacturer’s instructions. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)

  • Page 23: Sicherheitshinweise

    Installieren Sie keine Ersatzteile oder führen Sie keine unerlaubten Veränderungen am System durch, sonst verfällt die Garantie. Wenden Sie sich für Wartung oder Reparatur bitte an die für Sie zuständige Geschäftsstelle von Artesyn Embedded Technologies. So stellen Sie sicher, dass alle sicherheitsrelevanten Aspekte beachtet werden.
  • Page 24 Sie sicher, dass ausreichend Schutz vor Störstrahlung vorhanden ist. Die Blades müssen mit der Frontblende installiert und alle freien Steckplätze müssen mit Blindblenden abgedeckt sein. Änderungen, die nicht ausdrücklich von Artesyn Embedded Technologies erlaubt sind, können Ihr Recht das System zu betreiben zunichte machen. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 25 Beschädigung des Produktes und der Zusatzmodule Fehlerhafter Ein- oder Ausbau von Zusatzmodulen führt zu Beschädigung des Produktes oder der Zusatzmodule. Lesen Sie deshalb vor dem Ein- oder Ausbau von Zusatzmodulen die Dokumentation und benutzen Sie angemessenes Werkzeug. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 26 Absicherung, um die Gebäude-internen Schnittstellen mit Leitungen außerhalb des Gebäudes zu verbinden.Die intra-Gebäude Port (s) des Gerätes oder einer Unterbaugruppe müssen abgeschirmte innerGebäudeVerkabelung / Verdrahtung, die an beiden Enden geerdet ist zu verwenden. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 27 Verstellen Sie nur solche Schalter, die nicht mit 'Reserved' gekennzeichnet sind. Beschädigung des Produktes Das Verstellen von Schaltern während des laufenden Betriebes kann zur Beschädigung des Produktes führen. Prüfen und ändern Sie die Schaltereinstellungen, bevor Sie das Produkt installieren. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 28 Ein leerer AMC-Steckplatz kann zu verminderter Kühlung des Shelfs sowie starker elektromagnetischer Strahlung führen und somit eine Überschreitung von EMV-Grenzwerten zur Folge haben. Installieren Sie daher immer ein Filler-Panel in einen anderweitig nicht verwendeten AMCSteckplatz. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 29 Bestimmungen für Laserprodukte eingehalten werden. Verletzungsgefahr der Augen Optische SFP/SFP+-Module können Laserstrahlen aussenden, wenn kein Kabel angeschlossen ist. Blicken Sie daher nicht direkt in die Öffnung eines SFP/SFP+-Moduls, um Verletzungen der Augen zu vermeiden. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 30 Benutzen Sie keinesfalls einen Schraubendreher, um die Batterie aus der Halterung zu nehmen. Umweltschutz Umweltverschmutzung Falsche Entsorgung der Produkte schadet der Umwelt. Entsorgen Sie alte Produkte gemäß der in Ihrem Land gültigen Gesetzgebung und den Empfehlungen des Herstellers. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)

  • Page 31: Introduction

    Introduction Features The ATCA-F125 is a hub board as defined in PICMG 3.0 Revision 3.0 Advanced TCA Base Specification and PICMG 3.1 Revision 1.0 Specification Ethernet/Fiber Channel for AdvancedTCA Systems. It supports several Base and Fabric Channel Ethernet interfaces to the Zone 2 backplane.

  • Page 32: Standard Compliances

    ETSI storage requirements in system level (not temperature- controlled storage locations) ETSI Transportation: EN 300 019-2-2 ETSI public transportation requirement on system level Class 2.3 Telcordia GR-1089 Ports and Iitra-building lightning for telecommunication port ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 33 Ethernet ports. The product has been designed to meet the directive on the restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS) Directive 2011/65/EU. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)

  • Page 34: Figure 1-1 Declaration Of Conformity

    Guan Road West, Shiqi District, 528400 Zhongshan City Guangdong, PRC Declares that the following product, in accordance with the requirements of 2004/108/EC, 2006/95/EC, 2011/65/EU and their amending directives, Product: ATCA-F125 Series Switch Blade & RTM-ATCA-F125 Series Model Name/Number: ATCA-F125, ATCA-F125-14S, ATCA-F125-14S-C10, ATCA-F125-STD-01-L2, ATCA-F125-STD-02-L2, ATCA-F125-TCLK3, ATCA-F125-TCLK3-C01, RTM-ATCA-F125, RTM-ATCA-F125-C01,...

  • Page 35: Mechanical Data

    NOTE: This manual covers the ATCA-F125-14S product. It also covers ATCA-F125-TCLK3 product manufactured with 6873M PWB artwork. For 6859G PWB artwork documentation, refer to ATCA-F125 Installation & Use manual 6806800J94B. The PWB artwork may be identified by the assembly number, which is marked...

  • Page 36: Blade Accessories

    Table 1-4 Blade Accessories - Ordering Information Accessory Description RTM-ATCA-F125 RTM for the ATCA-F125 with SFP and SFPP receptacles SFP-MM-SX-LC 1G Single Form Factor (SFP) module - 850NM, SX, LC connector SFP-CO-RJ-45 1G copper Single Form Factor (SFP) module - RJ-45 connector...

  • Page 37: Product Identification

    Introduction Product Identification The following graphic shows the location of the serial number label. Figure 1-2 Serial Number Locater ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 38 Introduction ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)

  • Page 39: Hardware Preparation And Installation

    Chapter 2 Hardware Preparation and Installation Overview This chapter provides the information that you need to install the ATCA-F125 and its accessories into your AdvancedTCA system. Removal procedures are also included. To install the blade, follow these steps: 1. Unpack and inspect the blade.

  • Page 40: Requirements

    Improper disposal of used products may harm the environment.  Always dispose of used products according to your country’s legislation and  manufacturer’s instructions. Requirements This section shows the environmental and power requirements of the ATCA-F125 (6873M Artwork). ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)

  • Page 41: Environmental Requirements

    Operating temperatures refer to the temperature of the air circulating around the blade, and not to component temperatures. If you integrate the blade in your own non-Artesyn Embedded Technologies system, please contact your local sales representative for further safety information.

  • Page 42: Table 2-1 Environmental Requirements

    Half-sine, 11 ms at 30 m/s Blade level packaging Half-sine, 6 ms at 180 m/s Free Fall 1.2 m/ packaged (according to ETSI 300 019-2-2) 100 mm unpackaged (according to Tel- cordia GR-63-core) ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)

  • Page 43: Thermal Requirements

    Hardware Preparation and Installation 2.3.2 Thermal Requirements In order for the ATCA-F125 to cool properly when the operating temperature is at the maximum (55C), the chassis must meet or exceed CP-TA B.3 ATCA Chassis Specification. CP-TA B.4 compliance is preferred.

  • Page 44: Power Requirements

    The following table show typical examples of the power requirements, with and without accessories installed. For information on the accessories' power requirements, refer to the documentation delivered together with the respective accessory or consult your local Artesyn Embedded Technologies representative for further details.

  • Page 45: Rear Transition Modules

    Hardware Preparation and Installation Rear Transition Modules If applicable, install a rear transition module. For more information, refer the RTM-ATCA-F125 documents listed in Appendix B, Related Documentation. The RTMs are not hot-swappable. Before installation, make sure that no front blade is installed in its respective slot, or that the front blade is powered-down.

  • Page 46: Blade Configuration

    2.5.1 SATA Drive Installation An optional SATA drive may be installed on the ATCA-F125. An 80GB drive designed for extreme temperature and vibration environments has been test and approved for use on the ATCA-F125. Contact your Artesyn Embedded Technologies sales representative and order the HDD-80G-SATA kit which includes the hard drive, all the required mounting hardware, and the installation instructions.

  • Page 47: Installing Blade

    If there is a Rear Transition Module (RTM) to install, install and secure the RTM first as described in the RTM-ATCA-F125 Installation and Use Guide, then install the front blade. If an RTM is already installed, make sure that the RTM faceplate screws are fully tightened to secure the RTM to the shelf.
  • Page 48 Continue to gently push the blade until the blade connectors engage. 5. Squeeze the lever and the latch together and hook the lower and the upper handle into the shelf rail recesses. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 49 If an RTM is connected to the front blade, make sure that the handles of both the RTM and the front blade are closed in order to power up the blade’s payload. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)

  • Page 50: Removing Blade

    Damage of the blade Incorrect installation of the blade can cause damage of the blade.  Only use handles when installing/removing the blade to avoid damage/deformation to  the face plate and/or PCB. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 51 If the LED continues to blink, it is possible that the upper layer software rejects the blade extraction request. 3. Remove the face plate cables, if applicable. 4. Remove the blade from the shelf. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)

  • Page 52: Amc Module Installation And Removal

    Before touching the blade or electronic components, make sure that you are working in  an ESD-safe environment. AMC Module Damage The AMC bay supports only AMC modules that are officially supported by Artesyn  Embedded Technologies. Installing and operating other AMC modules may damage the AMC bay and the blade.
  • Page 53 LED. 1. Remove any cables that are connected to the AMC module face plate connectors. 2. Gently pull the module latch outwards, approximately 3 mm away from its locked position. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 54 4. Once the blue LED glows steadily, gently pull the AMC module handles outwards to disconnect the module from the AMC connectors. Continue to gently slide the module outwards along the guide rails. Install the filler panel. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)

  • Page 55: Installing And Removing Sfp Modules

    SFP modules can be installed/removed while the RTM is both powered and or powered off. The presence and also the type of SFP modules is automatically detected. The maximum power consumption of all installed SFP modules must not exceed 12 W. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)

  • Page 56: Installing An Sfp Module

    Hardware Preparation and Installation 2.8.1 Installing an SFP Module Procedure In order to install an SFP module, proceed as follows: 1. Slide the SFP module into the slot until it locks into position. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 57 SFP module inoperable. Only remove the optical plug when you are ready to connect a cable to the SFP module.  When no cable is connected, cover the port with an optical port plug. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 58 Hardware Preparation and Installation 3. Connect the network cable to the SFP module ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)

  • Page 59: Removing An Sfp Module

    In order to remove an SFP module, proceed as follows. 1. Remove any connected cable from the SFP module. 2. Open the SFP latch. Note that the latch mechanism of your SFP module may be ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 60 Hardware Preparation and Installation slightly different compared to the latch shown in the following figure. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 61 SFP module inoperable. Only remove the optical plug when you are ready to connect a cable to the SFP module.  When no cable is connected, cover the port with an optical port plug. ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)
  • Page 62 Hardware Preparation and Installation ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)

  • Page 63: Controls, Leds, And Connectors

    Overview Blade Layout The following figure shows the front panel face plate design. Figure 3-1 ATCA-F125 Face Plate Faceplate LEDs This section describes the details of the ATCA-F125 faceplate LEDs. Table 3-1 Faceplate LEDs Label Color Function Out of Service This LED is enabled by the IPMC upon initially entering the M4 state.
  • Page 64 Yellow Slave Clock Generator Green On - Master Clock Generator Blinking - Stand alone Master Blinking - Initializing LOCK Telco Clock LED 3 Yellow On -Hold over Blinking - Free Run Green Locked ATCA-F125 (6873M Artwork) Installation and Use (6806800J94L)

  • Page 65: Reset Switch
