SX610 pH-Meter Instruction Manual

1. Brief Introduction

Thank you for purchasing the Apera Instruments SX610 pH Pen Tester. This tester performs quick & reliable pH measurements
with a single-button. The slim-bodied tester is a cost-effective choice for your regular pH testing including: hydroponics,
aquaculture, water treatment, pools & spas, brewing, etc. The pH probe is replaceable and suitable for test tube measurements.

2. Specifications

1) pH Range: 0 to 14.0 pH
2) Resolution: 0.1 pH
3) Accuracy: ± 0.1 pH, ±1 digit
4) Automatic Temperature Compensation (ATC): 0-60ºC (32-140°F)
5) Automatic calibration: 1-point calibration (pH 7.00)
6) Power: CR2032 Cell Batteries x 2
7) Dimension and Weight: 148*29*14mm/49g
8) Waterproof rating: IP57

3. Instructions

1) Calibration: Rinse the probe in distilled water and dry it with a tissue (never wipe the glass bulb). Dip the probe
in the standard buffer solution pH7.00. Stir gently, hold still, and wait for a stable reading to appear and stay. Then
long-press the CAL button for >two seconds until CAL appears on the screen. When the calibration value 7.0 flashes,
the calibration will finish after a few seconds. The meter will then return to measurement mode with the icon
appearing on the screen.
2) Measurement: Rinse the probe in distilled water and dry it. Dip the probe in the sample solution. Stir gently and
wait for a stable reading to appear and stay.
3) Temperature Unit Selection: Long press CAL button when meter is off.
4) Storage: After measurement, rinse the probe with distilled water and dry it with a tissue. Put the protection cap
back on the electrode. It's a good practice to pour a small amount of the 3M KCL storage solution (provided in the
purchased kit) into the protection cap when storing the meter. This will help ensure the accuracy of the pH probe.

4. Notes

1) The instrument can typically be used for 1 to 2 weeks before recalibrating.
2) To ensure the reliability of calibration, pH standard buffer solution should be replaced once it becomes
contaminated (after 10-15 uses).
3) Maintenance is necessary for the tip of the probe because it can become contaminated after long-term usage. In
order to maintain the probe, wash the tip with soapwater and a light brush. Then rinse the bulb with distilled water.
4) The typical service life of the pH electrode is about 1-2 years. When the icon "Err" appears on the screen or the
quickness and accuracy are far off, please replace the probe with a new one. The replacement probe's model
number is SX615. Please go to support.aperainst.com to watch a tutorial video for how to replace the pH probe.
5) The instrument will automatically power off after 10 minutes being unused.
6) Replace the batteries when appears on screen.
V2.3
