2.
Confirm the PC is networked with the cameras then launch the utility. If properly networked, the utility
will automatically detect cameras on the network (click Refresh to refresh the list).
3.
Select the desired device from the list of available cameras.
4.
Click IP Setup and assign the desired IP.
5.
Fill out installer and company information.
6.
To activate the camera, you will be required to assign a complex password.
7.
Confirm the camera Live View preview is as desired and click Continue.
8.
Adjust any/all camera settings including the camera name and VIGIL Connect alias. Be sure to remember
the VIGIL Connect Alias as well as the username and password you assign to the camera. These
credentials will be required to add the camera to other VIGIL utilities.
9.
Fill out remaining information and complete steps in the setup tool to receive an installation summary
e-mail.
Note: The V-Series camera will automatically check for updates and format the SD card. Please allow
15 minutes before power cycling the camera.
Remote Monitoring and Viewing - Adding a V-Series Camera to VIGIL Client
Steps:
To interface a V-Series Camera with VIGIL Client:
1.
Launch VIGIL Client (Local Mode only; VCM mode will only display Servers from a networked VCM Server)
and select Servers from the Servers top menu. This will launch the Servers window. VISIX V-Series
devices are considered edge recording devices and thus are recognized as their own VIGIL Server within
the VIGIL suite.
2.
Click Add. This will deploy the Add/Edit VIGIL Server window.
3.
Enable the Use VIGIL Connect option. If connecting using traditional network connection criteria is
desired, enter the cameras IP Address/DNS Name and confirm TCP/IP port status.
4.
Enter in the VIGIL Connect alias of the desired V-Series Camera (VIGILTest1 used in the below example).
Skip this step if using traditional network connection criteria (IP/Port).
5.
Click Test VIGIL Connect to confirm the camera can be communicated with through the Connect system
using the provided alias. Skip this step if using traditional network connection criteria (IP/Port).
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
Adding V-Series Camera to VIGIL Client
Figure 2-1
V-Series Camera Quick Start Guide | VX-3V-ID-RIAWD
9
