Tait Confidential
Applicability
1 Introduction

2 Related Documentation

3 Equipment Required

3.1 TB8100 PMU and Rackframe
3.2 T805-26-XY0Z
The last four numbers of
the equipment specify the
RSU equipment
configuration.
Telephone:+64-3-357-9991
support@taitworld.com
http://support.taitworld.com
TECHNICAL NOTE TN-1013-AN
Using the TB8100 Base Station in Tait
QS
TB8100 Base station.
T805 Simulcast Remote Site Unit (RSU).
The TB8100 base station is suitable for use in simulcast systems with the
Tait T805 RSU. This technical note aims to explain what you specifically
need to do to use the TB8100 base station in a simulcast system: order the
correct TB8100 equipment, make the necessary hardware connections, and
configure the TB8100 base station (using the Service Kit application).
The following documentation is related to this technical note:
TB8100 Service Kit Users Manual or the on line help.
TB8100 Installation and Operation Manual.
TB8100 Specifications Manual.
2
Taitnet QS
Simulcast System Manual.
If you intend to use the TB8100 base station in a simulcast system, make
sure that you specify these options when you order the TB8100:
TBA30xx-x100 PMU with internal 13.8 V DC 40 Watt auxiliary power
supply. This is used to supply power to the external frequency
reference and the RSU. Please refer to the TB8100 specifications
manual for product code information.
If the RF links are also using TB8100 system components, a TBA2520
dual channel rackframe should be used
X = 0, Grey/Beige front panel
8, Black front panel
Y = 1 to 4, Number of QS2 Channel Cards fitted
Z = 0, GPS receiver not fitted
= 1, GPS receiver fitted
TN-1013-AN
Date of Print: 12/03/07
2
Simulcast Systems
9 March 2007
Tait Electronics Ltd
Page 1 of 9

Advertisement

Table of Contents
loading

Related Manuals for Tait TB8100

Summary of Contents for Tait TB8100

  • Page 1: Related Documentation

    The TB8100 base station is suitable for use in simulcast systems with the Tait T805 RSU. This technical note aims to explain what you specifically need to do to use the TB8100 base station in a simulcast system: order the correct TB8100 equipment, make the necessary hardware connections, and configure the TB8100 base station (using the Service Kit application).
  • Page 2 Tait Confidential Tait Electronics Ltd 4 Connecting the TB8100 to the T805 Equipment. 4.1 DB25 SIF Connections using TBA40xx-0B00 & TBA40xx-0C00 Reciters. RSU J414 on T805 TB8100 SIF Function Function RX Audio + RX Line Out + RX Audio -...

  • Page 3: Configuring The Reciter

    5.1 Configuring the Auxiliary Power Supply and External Reference. Service Kit Menu Item (SK): Configure > Base Station > Miscellaneous The specific changes that you will need to make to the TB8100 base station’s configuration file (using the Service Kit application) are as follows.
  • Page 4 Tait Confidential Tait Electronics Ltd Configuring the Auxiliary Power Supply and External Reference continued. SK: Configure > Base Station > Task Manager 1. Enable the If Base station in run mode Then Enable auxiliary supply Configure the following statement. It is important that this supply remains on if powering the parameters.

  • Page 5: Configuring The Channel Profile

    Tait Confidential Tait Electronics Ltd 5.2 Configuring the Channel Profile. SK: Configure > Base Station > Channel Profiles> Default > Signal Path Tab Configure the following 1. Enable Tx paths A and B parameters. 2. On Tx path B, select Bypass. This step is to ensure that, in the event high deviation demands on path A due to speech peaks, the sub- audible signal inserted on path B is not stripped off by the limiter.

  • Page 6: Configuring The Channel Table

    4. Ensure the channel profile is set to Default. Set the Filter to Pre/De- Emph Speech Band. Note: If you are using the Advanced Profiles Software Feature Enabler, see the TB8100 Service Kit User Manual. Name the Set Rx and Tx Do NOT set a channel.

  • Page 7: Configuring The Base Transmitter Alarms

    5.5 Reciter 2: Configured as a Second Simulcast Channel (Optional). Set up Reciter 2 in the TB8100 subrack as you did Reciter 1. Reciter 2 cannot control any PMU settings or correctly detect PA and PMU fan alarms.

  • Page 8: Reciter 2: Configured As A Link Transmitter And Receiver

    12. If Line Fail Talk Through is not required, set timer TR1 to zero (tr1,0) 7 Position and Layout of Equipment During operation, the TB8100 base station can become hot. This is normal since it is designed to operate at high temperatures. (The power amplifier (PA) fan turns on when the PA temperature reaches 60°...

  • Page 9: Issuing Authority

    Confidential – This message or document contains proprietary information intended only for the person(s) or organisation(s) to whom it is addressed. All Recipients are legally obliged to not disclose Tait technological or business information to any persons or organisations without the written permission of Tait.
