  • Page 1 TB7100 base station TB8100 base station TB9100 base station TBA0STU / TBA0STP Calibration and Test Unit Operation Manual MBA-00013-01 Issue 1 September 2005...
  • Page 2 Website: http://www.taitworld.com To our European customers: Tait Electronics Limited is an environmentally responsible company which supports waste minimization and material recovery. The European Union’s Waste Electrical and Electronic Equipment Directive requires that this product be disposed of separately from the general waste stream when its service life is over.

  • Page 3: Table Of Contents

    Using the CTU with a TB7100 ....... . . 11...

  • Page 4: Preface

    Scope of Manual This manual provides information on using the TBA0STU/TBA0STP base station Calibration and Test Unit (CTU) with a Tait base station. It describes the input and output connectors and controls available on the CTU, and includes a description of the accessories supplied with the CTU.

  • Page 5: Document Conventions

    Tait products, to provide technical details not included in manuals, and to offer solutions for any problems that arise. All available product documentation is provided on the Product CD supplied with the base station. Updates may also be published on the Tait Technical Support website (http:/ /support.taitworld.com).

  • Page 6: Publication Record

    Publication Record Issue Publication Date Description September 2005 First release TBA0STU/TBA0STP CTU Operation Manual © Tait Electronics Limited September 2005...

  • Page 7: Introduction

    Introduction The base station calibration and test unit (CTU) is designed to make it easier to connect a Tait base station to standard test equipment, and to a PC running the appropriate programming and calibration software. The CTU can be used with TB7100, TB8100 and TB9100 base stations, and comes...
  • Page 8 Introduction TBA0STU/TBA0STP CTU Operation Manual © Tait Electronics Limited September 2005...

  • Page 9: Modification History

    This chapter provides details about any production modifications made to the CTU that may affect its performance, or the way in which it interacts with the TB7100, TB8100 or TB9100 base stations. The unbalanced input on the CTU was changed from DC to AC coupled...
  • Page 10 Modification History TBA0STU/TBA0STP CTU Operation Manual © Tait Electronics Limited September 2005...

  • Page 11: Using The Ctu With A Tb7100

    12, and their functions are explained in the paragraphs which follow. Some items are not used with the TB7100, and others serve one function with the TB7100 and another with the TB8100 or TB9100. Any differences in function are described in the table that accompanies Figure 3.1.
  • Page 12 Figure 3.1 CTU connections and controls top view 1& rear view Using the CTU with a TB7100 TBA0STU/TBA0STP CTU Operation Manual © Tait Electronics Limited September 2005...
  • Page 13 DC input not used system control bus connector not used a. The TB7100 uses the 25-way connector with the TB7100 CTU adaptor board (refer to “The TB7100 CTU Adaptor Board” on page 17). b. Switches 1 to 4 can be configured as digital inputs or channel select. Switch 6 is used for Rx inhibit. The other switches are not used.
  • Page 14 Not used with TB7100. IOIOI The POWER LED is lit when the CTU is powered up. The TB7100 POWER system interface provides power to the CTU over the 25-way system interface connector (see also Figure 3.2 on page 16). This supply powers the noise source, speaker, LEDs, and RS-232 communications.
  • Page 15 These switches let you set the digital inputs into the TB7100 high or low, DIGITAL/ PROGRAMMING and are connected to the digital inputs on the system interface connector. INPUTS Switches 1 to 4 can be used for channel selection, and switch 6 is used to control Rx Inhibit.
  • Page 16 Figure 3.2 Example CTU connection to a TB7100 To PC running Programming or Calibration Application T2000-A19 programming lead plus TMAA20-04 adaptor (recommended) Power System Interface TB7100 25-way cable TB7100 CTU adaptor board Using the CTU with a TB7100 TBA0STU/TBA0STP CTU Operation Manual...
  • Page 17 “Preparation for Operation” chapter in the Installation and Operation Manual). This green LED indicates the status of Rx digital in/out 1 (pin 19 on the TB7100 system interface connector). It is lit when the line is pulled low.
  • Page 18 Note You can also use the TB7100 CTU adaptor board with the earlier TBA0ST1 and TBA0STP CTUs (using the supplied 25-way cable). As the adaptor board was not supplied with these CTUs, you can order it separately under the product code TBB0STU-TBB.

  • Page 19: Using The Ctu With A Tb8100

    Some items are not used with the TB8100, and others serve one function with the TB8100 and another with the TB7100 or TB9100. Any differences in function are described in the table that accompanies Figure 4.1.
  • Page 20 Figure 4.1 CTU connections and controls top view 1& rear view Using the CTU with a TB8100 TBA0STU/TBA0STP CTU Operation Manual © Tait Electronics Limited September 2005...
  • Page 21 DC input not used system control bus connector not used a. The TB7100 uses the 25-way connector with the TB7100 CTU adaptor board (refer to “The TB7100 CTU Adaptor Board” on page 17). b. Switches 1 to 4 can be configured as digital inputs or channel select. Switch 6 is used for Rx inhibit. The other switches are not used.
  • Page 22 This switch directs either the balanced or unbalanced receiver output audio UNBALANCED/OFF/ BALANCED to the CTU speaker. When set to “OFF”, no audio is present on the speaker. Using the CTU with a TB8100 TBA0STU/TBA0STP CTU Operation Manual © Tait Electronics Limited September 2005...
  • Page 23 This applies in particular to the ability to monitor bidirectional I/O lines, as these are connected only to switches, not LEDs (see also DIGITAL OUTPUTS TBA0STU/TBA0STP CTU Operation Manual Using the CTU with a TB8100 © Tait Electronics Limited September 2005...
  • Page 24 Task Manager. Figure 4.2 System interface bidirectional inputs/outputs Bidirectional I/O Line System Interface Input Task Manager Connector Task Manager Output Using the CTU with a TB8100 TBA0STU/TBA0STP CTU Operation Manual © Tait Electronics Limited September 2005...
  • Page 25 LEDs, and RS-232 communications. This DC input connector is not used if power is supplied via the system control bus or system interface connectors. TBA0STU/TBA0STP CTU Operation Manual Using the CTU with a TB8100 © Tait Electronics Limited September 2005...
  • Page 26 PMU Reciter (12 or 24V Only) 16-way cable Power To PC running RS-232 Service Kit or Calibration Kit 25-way cable 15-way cable (TaitNet) Using the CTU with a TB8100 TBA0STU/TBA0STP CTU Operation Manual © Tait Electronics Limited September 2005...

  • Page 27: Using The Ctu With A Tb9100

    28, and their functions are explained in the paragraphs which follow. Some items are not used with the TB9100, and others serve one function with the TB9100 and another with the TB7100 or TB8100. Any differences in function are described in the table that accompanies Figure 5.1.
  • Page 28 Figure 5.1 CTU connections and controls top view 1& rear view Using the CTU with a TB9100 TBA0STU/TBA0STP CTU Operation Manual © Tait Electronics Limited September 2005...
  • Page 29 DC input not used system control bus connector not used a. The TB7100 uses the 25-way connector with the TB7100 CTU adaptor board (refer to “The TB7100 CTU Adaptor Board” on page 17). b. Switches 1 to 4 can be configured as digital inputs or channel select. Switch 6 is used for Rx inhibit. The other switches are not used.
  • Page 30 1 & 2 (i.e. it is not grounded). The audio on LINE OUTPUT can also be monitored on the CTU speaker. Using the CTU with a TB9100 TBA0STU/TBA0STP CTU Operation Manual © Tait Electronics Limited September 2005...
  • Page 31 This banana socket is used as digital output 0 by the TB9100. RSSI Not used with TB9100. DIGITAL OUTPUTS TBA0STU/TBA0STP CTU Operation Manual Using the CTU with a TB9100 © Tait Electronics Limited September 2005...
  • Page 32 CTU is 32VDC. Use either a PMU 12VDC or 24VDC auxiliary output, or an external power supply. Not used with TB9100. SYSTEM CONTROL Using the CTU with a TB9100 TBA0STU/TBA0STP CTU Operation Manual © Tait Electronics Limited September 2005...
  • Page 33 Installation and Operation Manual for more details on this connection.) Power RJ45 Ethernet RS-232 Reciter Audio/Signalling Power RS-232 To PC running Calibration Software RS-232/Signalling TBA0STU/TBA0STP CTU Operation Manual Using the CTU with a TB9100 © Tait Electronics Limited September 2005...
  • Page 34 Using the CTU with a TB9100 TBA0STU/TBA0STP CTU Operation Manual © Tait Electronics Limited September 2005...

  • Page 35: Appendix A - Ctu Accessories

    Appendix A - CTU Accessories The TBA0STU base station CTU is supplied with the following accessories: a selection of cables which allow the CTU to be connected to a TB7100, TB8100, or TB9100 base station an adaptor board for connecting the CTU to a TB7100 base station...
  • Page 36 Description 219-03003-00 RJ45 cable 219-02893-00 SMA-to-N-type cable 219-02892-00 BNC-to-BNC cable TBB0STU-TBB TB7100 CTU adaptor board for use with 25-way cable 240-00022-11 power connector for PMU auxiliary DC output 219-02888-00 25-way cable (D-range) 219-02889-00 15-way cable (TaitNet D-range) 219-02890-00 16-way cable (system control bus)
  • Page 37 1. The PMU must be fitted with an optional auxiliary power supply board. 2. This type of connector is fitted to PMUs manufactured from August 2004 onwards . TBA0STU/TBA0STP CTU Operation Manual Appendix A - CTU Accessories © Tait Electronics Limited September 2005...
  • Page 38 Appendix A - CTU Accessories TBA0STU/TBA0STP CTU Operation Manual © Tait Electronics Limited September 2005...

  • Page 39: Appendix B - Ctu Block Diagram

    Appendix B - CTU Block Diagram A block diagram of the CTU is provided on following page. TBA0STU/TBA0STP CTU Operation Manual Appendix B - CTU Block Diagram © Tait Electronics Limited September 2005...
  • Page 40 Ground 9 = 9-way D-range, RJ = RJ45 provide the TB9100 channel seize input. Together they serve the “E” function of the E&M interface. Appendix B - CTU Block Diagram TBA0STU/TBA0STP CTU Operation Manual © Tait Electronics Limited September 2005...
