SuperWorkstation
5039A-I
USER'S MANUAL
Revision 1.0

Advertisement

Table of Contents
loading

Related Manuals for Supermicro SuperWorkstation 5039A-I

Summary of Contents for Supermicro SuperWorkstation 5039A-I

  • Page 1 SuperWorkstation 5039A-I USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.

  • Page 3: About This Manual

    If you have any questions, please contact our support team at: support@supermicro.com. This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Warnings Special attention should be given to the following symbols used in this manual.

  • Page 4: Table Of Contents

    SuperWorkstation 5039A-I User's Manual Contents Chapter 1 Introduction 1.1 Overview ..........................7 1.2 Unpacking the System ......................7 1.3 System Features ........................8 1.4 Chassis Features .........................9 Control Panel ........................9 Front Features ........................10 Rear Features ........................11 1.5 Motherboard Layout ......................12 Quick Reference .......................13 Motherboard Block Diagram .....................14...
  • Page 5 Preface Adding an M.2 Storage Card ....................32 Installing an Optional Device ....................34 System Cooling .........................35 Rear Fan ........................35 Optional Front Fan ......................36 Power Supply ........................37 Chapter 4 Motherboard Connections 4.1 Headers and Connectors ....................38 Power Connectors ......................38 4.2 Input/Output Ports and Interface Buttons ................39 4.3 Headers and Connectors ....................40 Control Panel .........................44 4.4 Jumpers ..........................47...

  • Page 6: Contacting Supermicro

    SuperWorkstation 5039A-I User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 7: Chapter 1 Introduction

    Chapter 1 Introduction 1.1 Overview The SuperWorkstation 5039A-I is a single processor workstation in the SC732D3-903B chassis with an X11SRA motherboard. It is useful for small/medium businesses, professional video editing, or 3D modeling. In addition to the motherboard and chassis, several included parts are listed below.

  • Page 8: System Features

    SuperWorkstation 5039A-I User's Manual 1.3 System Features The following table provides you with an overview of the main features of the 5039A-I. Refer to Appendix C for additional specifications. System Features Motherboard X11SRA Chassis SC732D3-903B Supports Intel Xeon W-21xx series in Socket R4 (LGA 2066)

  • Page 9: Chassis Features

    Chapter 1: Introduction 1.4 Chassis Features The SC732D3-903B is a mid-tower chassis. Control Panel The chassis front features a control panel to monitor functions and power off and on the system. Figure 1-1. Control Panel View Control Panel Features Item Feature Description Turns primary power on or off to the server from the power supply, but...

  • Page 10: Front Features

    SuperWorkstation 5039A-I User's Manual Front Features Figure 1-2. Chassis Front View Front Chassis Features Item Feature Description Optional Drive Area Supports two optional peripheral 5.25" drives (such as a DVD) Control Panel Front control panel (see preceding page) USB 3.0 Ports Two USB 3.0 ports (USB10/11, Type A)

  • Page 11: Rear Features

    Chapter 1: Introduction Rear Features Figure 1-3. Chassis Rear View Rear Chassis Features Item Feature Description Power Supply Fixed module I/O Backpanel Rear input/output ports (see Section 4.2) PCIe Slots Supports four full-height, full-length PCIe expansion cards Figure 1-4. Input/Output Ports...

  • Page 12: Motherboard Layout

    SuperWorkstation 5039A-I User's Manual 1.5 Motherboard Layout Below is a layout of the X11SRA motherboard with jumper, connector and LED locations. See the table on the following page for brief descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4.

  • Page 13: Quick Reference

    Chapter 1: Introduction Quick Reference Jumper Description Default Setting JBT1 CMOS Clear Open: Normal, Closed: Clear CMOS JPAC1 Audio Enable Pins 1-2 (Enabled) JPME2 Manufacturing Mode Select Pins 1-2 (Normal) Connector Description AUDIO_FP1 Front Panel Audio Header Onboard Battery COM1 COM Header FAN1 ~ FAN4, FANA System/CPU Fan Headers...

  • Page 14: Motherboard Block Diagram

    SuperWorkstation 5039A-I User's Manual Description Status M.2 Status LED Blinking Green: Read/Write M.2 Status LED Blinking Green: Read/Write LEDPWR Power LED Solid Green: Power On Motherboard Block Diagram Voltage monitor FAN SPEED CTRL Temp Sensor NCT6792D-B COM Header Figure 1-6. Intel C422 PCH series Chipset: Block Diagram Note: This is a general block diagram and may not exactly represent the features on your motherboard.

  • Page 15: Chapter 2 Workstation Setup

    SuperWorkstation 5039A-I User's Manual Chapter 2 Workstation Setup 2.1 Overview This chapter provides advice setting up your system. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 3 for details on installing those specific components.

  • Page 16: Chapter 3 Maintenance And Component Installation

    SuperWorkstation 5039A-I User's Manual Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and part numbers. Installation or replacement of most components require that power first be removed from the system.
  • Page 17 Chapter 3: Maintenance and Component Installation Caution: Except for short periods of time, do not operate the server without the cover in place. The chassis cover must be in place to allow for proper airflow and to prevent overheating. Figure 3-1. Removing the Chassis Covers...

  • Page 18: Motherboard Components

    • Use an Intel-certified multi-directional heatsink. • Refer to the Supermicro website for updates on CPU support. Installing the Processor 1. Remove power from the system as described in Section 3.1. 2. There are two load levers on the LGA2066 socket. To open the socket cover, press and release the load lever labeled "Open 1st".
  • Page 19 Chapter 3: Maintenance and Component Installation 4. Lift the load plate to open it completely. If necessary, gently push down on the "Open 1st" lever to open the load plate. If needed, gently push down to pop the load plate open. 5.
  • Page 20 SuperWorkstation 5039A-I User's Manual 6. Use your thumb and index finger to hold the CPU on its edges. Align the CPU keys, which are semi-circle cutouts, against the socket keys. Socket Keys CPU Keys 7. Once they are aligned, carefully lower the CPU straight down into the socket. To avoid damaging the CPU or socket, do not drop the CPU onto the socket, move it horizontally or vertically, or rub it against the socket pins.
  • Page 21 Chapter 3: Maintenance and Component Installation 9. Close the load plate with the CPU inside the socket. Lock the "Close 1st" lever first, then lock the "Open 1st" lever second. Gently push the load levers down to the lever locks. Push down and lock Gently close the 'Close 1st' lever.

  • Page 22: Installing The Cpu Heatsink

    SuperWorkstation 5039A-I User's Manual Installing the CPU Heatsink Do not apply thermal grease to the heatsink or the CPU--the required amount has already been applied. 1. Remove the power cord from the system. 2. Place the heatsink on top of the CPU so that the four mounting screws on the heatsink are aligned with holes on the socket.

  • Page 23: Removing The Heatsink

    Chapter 3: Maintenance and Component Installation Removing the Heatsink Note: We do not recommend that the CPU or the heatsink be removed. However, if you must remove the heatsink, follow the instructions below to avoid damage. 1. Remove power from the system as described in Section 3.1. 2.

  • Page 24: Memory

    Mixed DIMM speeds can be installed, however, all DIMMs will run at the speed of the slowest DIMM. Check the Supermicro website for possible updates to memory support (www.supermicro. com).

  • Page 25: Memory Module Installation

    Chapter 3: Maintenance and Component Installation Memory Module Installation When installing memory modules, the DIMM slots should be populated in the following order: DIMMA1, DIMMB1, DIMMC1, DIMMD1, then DIMMA2, DIMMB2, DIMMC2, DIMMD2. The blue slots must be populated first. Note: The motherboard supports installing an odd number of DIMM modules (1, 3, etc.). However, installing modules in pairs provides best memory performance.
  • Page 26 SuperWorkstation 5039A-I User's Manual Installing Memory 1. Remove power from the system as described in Section 3.1. 2. Starting with the slot in the order described previously, push the release tab outward to unlock it. Notch Release Tab 3. Align the key of the DIMM with the receptive point on the memory slot and with your thumbs on both ends of the module, press it straight down into the slot until the module snaps into place.

  • Page 27: Motherboard Battery

    Chapter 3: Maintenance and Component Installation Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery 1. Remove power from the system as described in section 3.1 and remove the node from the chassis.

  • Page 28: Chassis Components

    3. Rotate the drive cage outward. Release Tab (A) Drive Cage Figure 3-5. Rotating the Drive Cage Note: Enterprise level hard disk drives are recommended for use in Supermicro servers. For information on recommended HDDs, visit the Supermicro website at http://www.supermicro. com/products/nfo/storage.cfm.
  • Page 29 Chapter 3: Maintenance and Component Installation Installing a 3.5" Storage Drive 1. If you are replacing a drive, unplug the power and data cables. 2. Press the release tab on the side of the drive carrier and slide the carrier out of the drive cage.

  • Page 30: Adding 2.5" Storage Drives

    SuperWorkstation 5039A-I User's Manual 6. Connect the power and data cables to the hard drive. 7. Rotate the hard drive cage 90 degrees inward, returning it to the closed, operational position in the chassis. Adding 2.5" Storage Drives Up to four 2.5" drives may be installed into the chassis using an optional drive cage (p/n MCP-220-73201-0N).

  • Page 31: Ssd Storage

    Chapter 3: Maintenance and Component Installation 4. Press the release tab on the side of the drive carrier and slide the carrier out of the drive cage. 5. If you are replacing a drive, remove the drive from the carrier by pulling the sides of the carrier outwards.

  • Page 32: Adding An M.2 Storage Card

    SuperWorkstation 5039A-I User's Manual Securing M.2 module M.2 module Securing Knob into this area into this area Knob HD AUDIO KB/MOUSE LAN1 LAN2 USB 0/1 USB 8/9(3.0) USB 12/13(3.1) MH12 JNVI2C1 FAN4 MH10 DIMMB1 DIMMB2 MH13 MH11 DIMMA1 DIMMA2 BAR CODE...
  • Page 33 Chapter 3: Maintenance and Component Installation 3. Holding the M.2 card nearly horizontal, insert it into the slot on the motherboard and lower the semi-circular notch onto the standoff. Figure 3-10. Installing an M.2 Storage Module 4. Insert the plastic securing knob into the standoff. Figure 3-11.

  • Page 34: Installing An Optional Device

    SuperWorkstation 5039A-I User's Manual Installing an Optional Device The system supports a 3.5" optional device, such as an all-in-one card reader. Installing a 3.5" Device 1. Remove power from the system as described in section 3.1. 2. Remove the front bezel from the chassis by lifting it upwards from the bottom, and pulling off the front of the chassis.

  • Page 35: System Cooling

    Chapter 3: Maintenance and Component Installation System Cooling Rear Fan The system includes a super quiet system exhaust fan that provides cooling. No tools or screws are required for installation. If the power supply fan fails, the power supply itself must be replaced.

  • Page 36: Optional Front Fan

    SuperWorkstation 5039A-I User's Manual Optional Front Fan 1. Remove power from the system as described in section 3.1, and remove the left chassis cover. 2. Insert four rubber pins through the fan bracket and into the mounting holes in the fan.

  • Page 37: Power Supply

    Chapter 3: Maintenance and Component Installation Power Supply The power supply is auto-switching capable. This feature enables it to automatically sense the input voltage and operate at a 100-120v or 180-240v. An amber light is illuminated on the power supply when the power is switched off. An illuminated green light indicates that the power supply is operating.

  • Page 38: Chapter 4 Motherboard Connections

    SuperWorkstation 5039A-I User's Manual Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.

  • Page 39: Input/Output Ports And Interface Buttons

    Chapter 4: Motherboard Connections 4.2 Input/Output Ports and Interface Buttons The rear of system offers these input/output ports. Figure 4-1. Rear I/O Ports Rear I/O Ports Description Description Description Description PS2 KB/Mouse LAN1 USB9 (3.0) S/PDIF Out USB1 (2.0) USB13 (3.1) USB8 (3.0) Line In USB0 (2.0)

  • Page 40: Headers And Connectors

    SuperWorkstation 5039A-I User's Manual 4.3 Headers and Connectors Fan Headers The motherboard has five fan headers (FAN1–FAN4, FANA). All of these 4-pin fan headers are backwards-compatible with the traditional 3-pin fans. However, fan speed control is available for 4-pin fans only by Thermal Management via the IPMI 2.0 interface.
  • Page 41 Chapter 4: Motherboard Connections SGPIO Headers Two I-SGPIO (Serial Link General Purpose Input/Output) headers are located on the motherboard. They support the onboard I-SATA 3.0 ports. SGPIO Header I-SGPIO 1/2 Pin Definitions Pin# Definition Pin# Definition I-SGPIO1 I-SATA 3.0 Ports 2-3 I-SGPIO2 I-SATA 3.0 Ports 4-7 Data...
  • Page 42 SuperWorkstation 5039A-I User's Manual Intel RAID Key Header The JRK1 header supports VMD used in creating optional advanced NVMe RAID configurations. Intel RAID Key Pin Definitions Pin# Definition Ground +3.3 V Standby Ground PCH RAID key Front Accessible Audio Header A 10-pin audio header (AUDIO_FP1) allows you to use the onboard sound for audio playback.
  • Page 43 Chapter 4: Motherboard Connections Power SMB (I C) Header The Power System Management Bus (I C) connector (JPI C1) monitors the power supply, fan, and system temperatures. Power SMB Header Pin Definitions Pin# Definition Clock Data PMBUS_Alert Ground +3.3V Thunderbolt Header This motherboard supports one Thunderbolt header (JTBT) on the back panel.

  • Page 44: Control Panel

    SuperWorkstation 5039A-I User's Manual Control Panel JF1 contains header pins for various control panel connections. See the figure below for the pin locations and definitions of the control panel buttons and LED indicators. All JF1 wires have been bundled into a single cable to simplify this connection. Make sure the red wire plugs into pin 1 as marked on the motherboard.
  • Page 45 Chapter 4: Motherboard Connections Power Fail LED The Power Fail LED connection is located on pins 5 and 6 of JF1. Power Fail LED Pin Definitions (JF1) Pin# Definition 3.3V PWR Supply Fail Overheat (OH)/Fan Fail Connect an LED cable to pins 7 and 8 of JF1 to use the Overheat/Fan Fail LED connections. The LED on pin 8 provides warnings of overheat or fan failure.
  • Page 46 SuperWorkstation 5039A-I User's Manual Power LED The Power LED connection is located on pins 15 and 16 of JF1. Power LED Pin Definitions (JF1) Pin# Definition 3.3V Power LED NMI Button The non-maskable interrupt button header is located on pins 19 and 20 of JF1.

  • Page 47: Jumpers

    Chapter 4: Motherboard Connections 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 48 SuperWorkstation 5039A-I User's Manual Manufacturer Mode Select Close pin 2 and pin 3 of jumper JPME2 to bypass SPI flash security and force the system to operate in the manufacturer mode, which will allow the user to flash the system firmware from a host server for system setting modifications.

  • Page 49: Led Indicators

    Chapter 4: Motherboard Connections 4.5 LED Indicators LAN LEDs The LAN ports are located on the I/O back panel on the motherboard. Each Ethernet LAN port has two LEDs. The yellow LED indicates activity. Link LED, located on the left side of the LAN port, may be green, amber or off indicating the speed of the connection.

  • Page 50: Chapter 5 Software

    You must first configure RAID settings (if using RAID) before you install the Windows OS and the software drivers. To configure RAID settings, please refer to the RAID Configuration User Guides posted on our website at www.supermicro.com/support/manuals. Installing the Windows OS for a RAID System 1.

  • Page 51: Driver Installation

    Chapter 5: Software 5.2 Driver Installation The Supermicro FTP site contains drivers and utilities for your system at ftp://ftp.supermicro. com. Some of these must be installed, such as the chipset driver. After accessing the FTP site, go into the CDR_Images directory and locate the ISO file for your motherboard.

  • Page 52: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 53: Chapter 6 Bios

    Chapter 6: BIOS Chapter 6 BIOS 6.1 Introduction This chapter describes the AMI BIOS setup utility for the X11SRA and provides the instructions on navigating the setup screens. The BIOS is stored in a Flash EEPROM and can be updated. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted since this manual was published.

  • Page 54: Main Setup

    SuperWorkstation 5039A-I User's Manual 6.2 Main Setup When running the AMI BIOS setup utility, it starts with the Main screen. You can always return to it by selecting the Main tab on the top of the screen. The Main tab page allows you to set the date and time, and it displays system information.

  • Page 55: Advanced Setup Configurations

    Chapter 6: BIOS 6.3 Advanced Setup Configurations Use the arrow keys to select the Advanced tab and press <Enter> to access the submenu items. Caution: Take caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency, or an incorrect DRAM timing setting may make the system unstable. If this occurs, revert to the manufacture default settings.

  • Page 56: Cpu Configuration

    SuperWorkstation 5039A-I User's Manual • Manageability Features State This feature allows the user to enable and disable Manageability Features support in FW. To disable support platform, the system must be in an unprovisioned state first. The options are Enabled and Disabled.
  • Page 57 Chapter 6: BIOS Enable Intel TXT Select Enabled to enable Intel Trusted Execution Technology (TXT) support to enhance system security and data integrity. The options are Disabled and Enabled. Intel (VMX) Virtualization Technology Select Enable to use Intel Virtualization Technology so that I/O device assignments will be reported directly to the VMM (Virtual Memory Management) through the DMAR ACPI Tables.
  • Page 58 SuperWorkstation 5039A-I User's Manual Extended APIC Based on the Intel Hyper-Threading technology, each logical processor (thread) is assigned 256 APIC IDs (APIDs) in 8-bit bandwidth. When this feature is set to Enable, the APIC ID will be expanded from 8 bits to 16 bits to provide 512 APIDs to each thread to enhance CPU performance.

  • Page 59: Chipset Configuration

    Chapter 6: BIOS CPU C State Control Autonomous Core C-State Select Enable to support Autonomous Core C-State control which will allow the proces- sor core to control its C-State setting automatically and independently. The options are Enable and Disable. CPU C6 Report Select Enable to allow the BIOS to report the CPU C6 state (ACPI C3) to the operating system.
  • Page 60 SuperWorkstation 5039A-I User's Manual Custom Refresh Enable This feature enables a custom memory refresh rate. The options are Disable and Enable. MC BGF threshold Enter a value for the HA to MC BGF threshold, which is used for scheduling MC request in bypass conditions.
  • Page 61 Chapter 6: BIOS Patrol Scrub Interval Use this item to specify the number of hours (between 0 to 24) required for the sys- tem to complete a full patrol scrubbing. Enter 0 for patrol scrubbing to be performed automatically. The default setting is 24. Note: This item is hidden when Patrol Scrub item is set to Disable.
  • Page 62 SuperWorkstation 5039A-I User's Manual PCI-E Port Max (Maximum) Payload Size Select Auto for the system BIOS to automatically set the maximum payload value for a PCI-E device specified by to user to enhance system performance. The options are Auto, 128B, and 256B.

  • Page 63: South Bridge

    Chapter 6: BIOS to improve virtualization efficiency by simplifying interrupt migration and lessening the need of physical interrupts. The options are Enable and Disable. Coherency Support (Non-Isoch) Select Enable for the Non-Iscoh VT-d engine to pass through DMA (Direct Memory Access) to enhance system performance.
  • Page 64 SuperWorkstation 5039A-I User's Manual Port 60/64 Emulation Select Enabled for I/O port 60h/64h emulation support, which in turn, will provide complete legacy USB keyboard support for the operating systems that do not support legacy USB devices. The options are Enabled and Disabled.

  • Page 65: Acpi Settings

    Chapter 6: BIOS Spin Up Device When this feature is disabled, all drives will spin up at boot. When it is enabled, it will perform Staggered Spin Up on any drive this feature is activated. The options are Enabled and Disabled.
  • Page 66 SuperWorkstation 5039A-I User's Manual Boot Feature Boot Feature Fast Boot When this feature is enabled, a minimal set of devices required to launch during system bootup is initialized. The options are Disabled and Enabled. Quiet Boot Use this feature to select the screen display between POST messages or the OEM logo at bootup.

  • Page 67: Serial Port 1 Configuration

    Chapter 6: BIOS Power Button Function This feature controls how the system shuts down when the power button is pressed. Select 4 Seconds Override for the user to power off the system after pressing and holding the power button for 4 seconds or longer. Select Instant Off to instantly power off the system as soon as the user presses the power button.

  • Page 68: Serial Port Console Redirection

    SuperWorkstation 5039A-I User's Manual Device Settings This item displays the base I/O port address and the Interrupt Request address of a serial port specified by the user. Note: This item is hidden when Serial Port 1 is set to Disabled.
  • Page 69 Chapter 6: BIOS Parity A parity bit can be sent along with regular data bits to detect data transmission errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits is even. Select Odd if the parity bit is set to 0, and the number of 1's in data bits is odd.
  • Page 70 SuperWorkstation 5039A-I User's Manual Legacy Serial Redirection Port Select a COM port to display redirection of Legacy OS and Legacy OPROM Messages. The options are SOL and COM1. PCIe/PCI/PnP Configuration Option ROM execution SR-IOV Support (Available if the system supports Single-Root Virtualization) Select Enabled for Single-Root IO Virtualization support.
  • Page 71 Chapter 6: BIOS CPU Slot 6 PCI-E x16 OPROM Use this feature to select which firmware type to be loaded for the add-on card in this slot. The options are Disabled, Legacy, and EFI. Onboard LAN Option ROM Type Select Enabled to enable Option ROM support to boot the computer using a network device specified by the user.

  • Page 72: Event Logs

    SuperWorkstation 5039A-I User's Manual 6.4 Event Logs Use this tab page to configure Event Log settings. Change SMBIOS Event Log Settings  Enabling/Disabling Options SMBIOS Event Log Change this item to enable or disable all features of the SMBIOS Event Logging during system boot.
  • Page 73 Chapter 6: BIOS SMBIOS Event Log Standard Settings Log System Boot Event This option toggles the System Boot Event logging to enabled or disabled. The options are Enabled and Disabled. MECI The Multiple Event Count Increment (MECI) counter counts the number of occurences that a duplicate event must happen before the MECI counter is incremented.

  • Page 74: Security

    SuperWorkstation 5039A-I User's Manual 6.5 Security Use this tab page to configure Security settings. Administrator Password Press Enter to create a new, or change an existing Administrator password. Minimum Length - 3 Maximum - 20 Password Check Select Setup for the system to check for a password at Setup. Select Always for the system to check for a password at bootup or upon entering the BIOS Setup utility.
  • Page 75 Chapter 6: BIOS Secure Boot System Mode - Setup Vendor Keys - Not Modified Secure Boot Enable - The options are Enabled and Disabled. When a Platform Key(PK) is enrolled, this feature may be enabled. Secure Boot Mode Use this item to select the secure boot mode. The options are Standard and Custom. CSM Support Select Enabled to support the EFI Compatibility Support Module (CSM), which provides compatibility support for traditional legacy BIOS for system boot.
  • Page 76 SuperWorkstation 5039A-I User's Manual Secure Boot variable: Size/Key#/Key Source Platform Key (PK) This feature allows the user to configure the settings of the platform keys. Key Exchange Keys---Please confirm Select Yes to load the KEK from the manufacturer's defaults. Select No to load the KEK from a file.
  • Page 77 Chapter 6: BIOS OsRecovery Signatures Set New Key Select Yes to load the DBR from the manufacturer's defaults. Select No to load the DBR from a file. The options are Yes and No. Append Key Select Yes to add the DBR from the manufacturer's defaults list to the existing DBR. Select No to load the DBR from a file.

  • Page 78: Boot

    SuperWorkstation 5039A-I User's Manual 6.6 Boot Use this tab page to configure Boot Settings. Boot Configuration Setup Prompt Timeout Enter the wait time in seconds to wait for the setup activation key. Enter 65535 for indefinite wait time. The default is 1.
  • Page 79 Chapter 6: BIOS The options are Hard Dish, CD/DVD, USB Hard Disk, USB CD/DVD, USB Key, USb Floppy, USB Lan, Network, and Disabled. Delete Driver Option  NETWORK Drive BBS Priorities This feature allows the user to specify which UEFI network drive devices are boot devices. Boot Option #1 ...

  • Page 80: Save & Exit

    SuperWorkstation 5039A-I User's Manual 6.7 Save & Exit Use this tab page to configure Save & Exit settings. Save Options Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration, and reboot the computer. Select Discard Changes and Exit from the Exit menu and press <Enter>.

  • Page 81: Discard Changes

    Chapter 6: BIOS Discard Changes Select this option and press <Enter> to discard all the changes and return to the AMI BIOS utility Program. Default Options Restore Defaults  To set this feature, select Restore Optimized Defaults from the Save & Exit menu and press <Enter>.

  • Page 82: Appendix A Bios Error Codes

    SuperWorkstation 5039A-i User's Manual Appendix A BIOS Error Codes A-1 BIOS Error Beep (POST) Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 83 When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOC-LPC80-20). For information on AMI updates, please refer to http://www.ami.com/products/.

  • Page 84: Appendix B Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 85 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.

  • Page 86: Installation Instructions

    SuperWorkstation 5039A-i User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬...

  • Page 87: Circuit Breaker

    Appendix B: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 88 SuperWorkstation 5039A-i User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.

  • Page 89: Power Disconnection Warning

    Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...

  • Page 90: Equipment Installation

    SuperWorkstation 5039A-i User's Manual ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت قبم‬ ‫انىصىل إىن امنناطق انداخهيت نههيكم نتثبيج أو إ ز انت مكىناث الجهاز‬ 경고! 시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에 반드시 전원...

  • Page 91: Restricted Area

    Appendix B: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 92 SuperWorkstation 5039A-i User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial,...

  • Page 93: Battery Handling

    Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...

  • Page 94: Redundant Power Supplies

    SuperWorkstation 5039A-i User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제...
  • Page 95 Appendix B: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.

  • Page 96: Backplane Voltage

    SuperWorkstation 5039A-i User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.

  • Page 97: Comply With Local And National Electrical Codes

    Appendix B: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.

  • Page 98: Product Disposal

    SuperWorkstation 5039A-i User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다.
  • Page 99 Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 100 SuperWorkstation 5039A-i User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 101 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 102 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 103 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 104: Appendix C System Specifications

    SuperWorkstation 5039A-I User's Manual Appendix C System Specifications Processor Supports single Intel Xeon W-21xx series processor in a Socket R4 (LGA 2066) Note: Refer to the motherboard specifications pages on our website for updates to supported processors. Chipset Intel C422 PCH series...
  • Page 105 Appendix C: System Specifications Regulatory Compliance Electromagnetic Emissions: FCC Part 15 Subpart B Class B, EN 55032 Class B, EN 61000-3-2/3-3, AS/NZS CISPR32 Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) VCCI 32 Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) Perchlorate Warning California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only to products...

  • Page 106: Appendix D Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 107 USB device or a writable CD/DVD. Note 1: If you cannot locate the "Super.ROM" file in your drive disk, visit our website www.supermicro.com to download the BIOS package. Extract the BIOS binary im- age into a USB flash device and rename it "Super.ROM" for the BIOS recovery use.
  • Page 108 SuperWorkstation 5039A-I User Manual 3. After locating the healthy BIOS binary image, the system will enter the BIOS Recovery menu as shown below. Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below.
  • Page 109 Appendix D: UEFI BIOS Recovery 5. After the BIOS recovery process is complete, press any key to reboot the system. 6. Using a different system, extract the BIOS package into a USB flash drive. 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu.
  • Page 110 SuperWorkstation 5039A-I User Manual 8. When the UEFI Shell prompt appears, type fs# to change the device directory path. Go to the directory that contains the BIOS package you extracted earlier from Step 6. Enter flash.nsh BIOSname.### at the prompt to start the BIOS update process.

  • Page 111: Appendix E Chinese Bsmi-Rohs

    Appendix E Chinese BSMI-RoHS Appendix E Chinese BSMI-RoHS 限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱：工作站/ Workstation 型號（型式）: SYS-5039A-I（系列型號：732-9（本型式係MB X11SRA之機種）） Type designation （Type） Equipment name 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 六價鉻 多溴聯苯 多溴二苯醚 鉛...
