Oriental motor BLE2 Series Quick Start Manual

Many other useful features are also available
For example.....
The motor can be operated by external signals
Motor
Driver
To power supply
And others.....
To display the rotation speed of the

gearhead output shaft.

To display the conveyor transfer speed.
 To set the rotation speed externally.

To suppress the motor torque.
 To hold a load by the slight
position-keeping function.

To lock the data setting.
© Copyright ORIENTAL MOTOR CO., LTD. 2016
Operating using
external signals
p. 33
OPERATING MANUAL
Operating in two or
more speeds
p. 40
OPERATING MANUAL
Programmable controller,
etc.
As mentioned in the right, various
functions are available.
OPERATING MANUAL
Refer to "Convenient functions."
ORIENTALMOTOR CO.,LTD.
Brushless Motors
BLE2 Series
QUICK START GUIDE
Thank you for purchasing an Oriental Motor product.
Use the product correctly after thoroughly reading the section "Safety precautions" of the operating
manual.
This document describes methods till rotating the motor after connecting it to the driver.
For details about how to use the product, refer to the
Package contents
The package includes the items shown below.
□
Driver
□ QUICK START GUIDE (this document)
□ OPERATING MANUAL
Connection cable (sold separately)
There are two types of connection cables
which cable leading directions are di erent.
(→ Refer to the right gure)
Be sure to ground the Protective Earth Terminal
(ground terminal) to ensure the safe use of the product.
Refer to "1 Connecting" for details, and ground securely.
Operating manual supplied with the driver.
Motor (sold separately)
□ □
Motor Mounting screw set
The gure shows an Supplied with the
example of the combination type.
combination type.
□
OPERATING MANUAL
∗
Be sure to match the motor output power with the
driver output power.
To connect the motor and driver, the dedicated
connection cable is always needed.
Leading in direction of Leading in opposite direction
output shaft of output shaft
Model: CC__HBLB
Model: CC__HBLF
For the round shaft type, only the cable for leading in
opposite direction of output shaft can be used.
HM-5190
