10.2.1.5 ccTalk teach mode (not for ACMI version)
Header 202 – Teach mode control
Transmitted data: Position (1 byte)
Received data:
Header 201 – Request teach status
Transmitted data: None
Received data:
10.2.2 v colibri – external 3-fold sorting device
2
Pin Function
1
GND
2
Sensor supply 12V DC
3
Sorting line 5
4
Sorting line 6
5 –
6 –
7 Possible sorting line 1
8 Possible sorting line 2
9 Possible sorting line 3
10 Possible sorting line 4
BA_v2_colibri_ccTalk_EN_1-0
ACK
Position: Bit 0..6: Coin type (1..16)
Bit 7: 0 = normal acceptance band
1 = wide acceptance band
Position = 0 = abort teaching process
Byte 1 = No. of coins inserted
Byte 2 = Status code:
252 = teaching process aborted (see header 202)
253 = teaching error (overlapping with existing acceptance band, coin type not found)
254 = teaching in process
255 = teaching process completed
The status code remains active until reset or the next teaching process.
T
echnical DaTa
1 2
9 10
