Nameplate; Switching Functions/Coin Channel Assignment Sticker - CPI V2 COLIBRI 36B Series Operating Instructions Manual

D
esign
4.3

Nameplate

The nameplate [Fig. 1/4]/[Fig. 2/4] shows the characteristic data of the device like the device
series, type and operation as well as the customer‑specific currency and coin programming:
10
9
8
7
1 Device type
2 Bar code
3 Ordering code (10‑digit),
order number (4‑digit),
device serial number (4-digit)
4 Machine interface
5 Nominal voltage
6 Date of manufacture
4.4 Switching functions/coin channel assignment sticker
For easy operation of the coin validator, you will find a sticker on the
back of the device; [Fig. 1/9]/[Fig. 2/9] at the top, it briefly shows the
functions of the individual DIL switches
and below this the coin channels from memory block 0 and 1 that
are assigned to the individual programmed coins
double block data-management, p. 20)
Currency and coin denomination
Normal channel (No.)
Narrow channel (No.)
Super narrow channel (No.)
16
1
36B26/7
35039003
GBP 2,- / 1,- / -,50 / -,20 / -,10 / -,10N2 / -,05 / -,05N2
EUR 2,- / 1,- / -,50 / -,20 / -,10 / -,05
+49 (0) 4161 / 729 - 0
info@craneps.com
Fig. 5: Nameplate
(cf. Chap. 4.5 Switch blocks, p. 17)
:
The unique assignment to the device and nameplate is
given by means of the model and data block number
below.
After configuration, we recommend that you change the
nameplate and the sticker to reflect the new settings or
that you make a note of the new settings in a different
form for the workshop and the place of use.
Fig. 6: Switching functions/coin channel assignment sticker
2
0000036006/0000/0020
|ccTalk|
10-27V DC
07/12
7 Coin programming – memory block 1
(if DIL switch S1.10 to ON)
8 Coin programming – memory block 0
(if DIL switch S1.10 to OFF)
N = new coinage
9 Data block number (– revision number)
10 Model number 3xBxx/7
36B top entry version
37B front entry version with MIDI front plate
38B front entry version with MINI front plate
39B front entry version without front plate
B26 with sorting line
Inhibit channel 1..8
on
S1
off
Open channel 1..8
Inhibit channel 9..16
on
(cf. Chap. 5.2 Single or
S2
off
Open channel 9..16
Block 0
GBP 2,-
GBP 1,-
GBP -,50
GBP -,20
GBP -,10
GBP -,10N2
GBP -,05
GBP -,05N2
35039003-001
3
4
5
6
CASINO Mode
Block 1
Block 0
NORMAL Mode
TEACH Mode
Teach band
wide
normal
NORMAL Mode
Block 1
01 09 12 EUR 2,- 01 07 13
02 12 13 EUR 1,- 02 08 --
03 11 EUR -,50 03 09
14 --
04 -- -- EUR -,20 04 10 --
05 -- -- EUR -,10 05 11 --
06 -- -- EUR -,05 06 12 --
07 -- --
13 -- --
36B26/7
BA_v2_colibri_ccTalk_EN_1-0
