Header Command
240
Test solenoids
238
Test output lines
236 Read opto states
232
Perform self test
231
Modify inhibit status
230
Request inhibit status
Read buffered credit or error
229
codes
228 Modify master inhibit status
227
Request master inhibit status
222
Modify sorter override status
221 Request sorter override status
219 Enter new PIN
218
Enter PIN
Request data storage
216
availability
213 Request option flags
210 Modify sorter paths
209 Request sorter paths
202
Teach mode control
201
Request teach status
196 Request creation date
195
Request last modification date
Request build code
192
(incl. Write protection info)
BA_v2_colibri_ccTalk_EN_1-0
Function, No. of data bytes [expected/returned]
[1/0]
Bit 0: gate 0 (acceptance)
Bit 1: gate 1 (internal sorter)
Bit 2: gate 2 (internal sorter)
Bit 3: gate 3 (internal sorter)
[0/1]
Bit 0: 1 = open escrow to cash box
Bit 1: 1 = open escrow to return
Bit 2: 1 = activate return lever motor
[0/1]
Bit 0: SO1 (Sizing Optics)
Bit 1: SO2 (Sizing Optics)
Bit 4: CP3 (Coin Position)
Bit 5: CP4 (Coin Position)
[0/1]
0 = no error
1 = EEPROM checksum fault (settings corrupt)
(cf. Chap. 10.2.1.3 ccTalk error code table, p. 42)
[4/0] (no function)
[4/0] (no function)
0,0,0,0,0 [0/5]
[0/1]
Bit 7: MSB, 1 = remote teach support
Bit 6: 1 = escrow control supported
Bit 5: 1 = return lever motor control
Bit 4..0: 0 (not used)
5 bytes [5/0] or 2 bytes [2/0]
4 bytes [1/4]
[1/0]
(cf. Chap. 10.2.1.5 ccTalk teach mode (not
for ACMI version), p. 43)
[0/2]
(cf. Chap. 10.2.1.5 ccTalk teach mode (not
for ACMI version), p. 43)
"DE0" (no protection)
"DE1" (ACMII)
"DE2" (VDAI)
"DE2" (extra)
T
echnical DaTa
Optional ACMI deviations for
Italian gambling machine market
[2/0]
[0/2]
[0/11]
[1/0]
[0/1]
[1/0]
[0/1]
no reply
2 bytes [2/0]
1 byte [1/1]
no reply
no reply
[2/0]
[2/0]
"IT0" (no protection)
"IT1" (ACMII)
"IT2" (VDAI)
"IT3" (extra)
