4.
5.

Equalizer parameter functions

Use the EFX PARAM [l l l l ] [r r r r ] buttons to adjust the EQ Gain(Low) or the
Low Frequency. Use the EFX VALUE [l l l l ] [r r r r ] buttons to adjust the EQ
Gain(High) or the High Frequency.
* The equalizer settings you make here are common to all Parts. They cannot be set indepen-
dently for individual Parts.
When you finish making settings, press [SELECT] once again to end the
procedure.
USER
INST SELECT
EFX ON/OFF
2 5
EQ Gain (Low): -12 — 0 — +12dB
EQ Gain (High): -12 — 0 — +12dB
Specify the amount of boost or cut (gain) for the high frequency range (high) and the
low frequency range (low). Positive (+) settings will boost, and negative (-) settings will
cut.
* With a Gain setting of 0, the equalizer will have no effect.
EQ Low Freq (Equalizer Low Frequency): 200/400 Hz
EQ High Freq (Equalizer High Frequency): 3/6 kHz
These parameters set the cutoff frequencies of the ranges boosted or cut by the
equalizer.
Chapter 3.System Effects
1
PART
ALL
LEVEL

MUTE

REVERB
SC - 55
MAP
KEY SHIFT
SC - 88
MAP
DELAY
VIB RATE VIB DEPTH
CUTOFF
ATTACK DECAY
EFX TYPE EFX PARAM
3
4
INSTRUMENT
PAN
CHORUS
MIDI CH
VIB DELAY
RESONANCE
RELEASE
EFX VALUE
4
49
