Roland SoundCanvas SC-88 Pro Owner's Manual page 89

OD1 Amp Sw (OD1 Amp Switch)
Turn OD1 Amp on/off.
OD1 Pan (OD1 Output Pan)
Set the stereo location of the overdrive or distortion
sound for set 1. L63 is far left, 0 is center, and R63
is far right.
OD1 Level
Adjust the overdrive or distortion volume for set 1.
<OD2 (Overdrive/Distortion 2)>
OD2 Sel (OD2 Select)
Select either Overdrive or Distortion for set 2.
#OD2 Drive (OD2 Drive)
Adjust the depth of distortion for set 2. The volume
will change together with the depth of distortion.
OD2 Amp (OD2 Amp Simulator Type)
Select the type of guitar amp for set 2.
Small : small amp
BltIn : single-unit type amp
2-Stk : large double stack amp
3-Stk : large triple stack amp
OD2 Amp Sw (OD2 Amp Switch)
Turn OD2 Amp on/off.
OD2 Pan (OD2 Output Pan)
Set the stereo location of the overdrive or distortion
sound for set 2. L63 is far left, 0 is center, and R63
is far right.
OD2 Level
Adjust the overdrive or distortion volume for set 2.
Level (Output level )
Adjust the output level.
60: OD / Rotary (Overdrive/Distortion, Rotary)
This connects Overdrive or Distortion in parallel with
Rotary.
Overdrive/
L
Distortion
R
Rotary
Off/On [4]
L63 - 0 - R63 [16]
0 - 127 [17]
Odrv/Dist [6]
0 - 127 [7]
Small/BltIn/2-Stk/3-Stk [8]
Off/On [9]
L63 - 0 - R63 [18]
0 - 127 [19]
0 - 127 [20]
[11H, 04H]
Pan
Pan
Chapter 4. Insertion Effects
<OD (Overdrive/Distortion)>
OD Sel (OD Select)
Select either Overdrive or Distortion.
+OD Drive (OD Drive)
Adjust the depth of overdrive or distortion. The vol-
ume will change together with the depth of distor-
tion.
OD Amp (OD Amp Simulator Type)
Select the type of guitar amp for overdrive or distor-
tion.
Small : small amp
BltIn : single-unit type amp
2-Stk : large double stack amp
3-Stk : large triple stack amp
OD Amp Sw (OD Amp Switch)
Turn the OD Amp parameter on/off.
OD Pan (OD Output Pan)
Set the stereo location of the overdrive or distortion
sound. L63 is far left, 0 is center, and R63 is far
right.
OD Level
Adjust the volume of the overdrive or distortion
sound.
<RT (Rotary)>
RT L Slow (RT Low Frequency Slow Rate)
Adjust the speed of the low-range rotor for the low-
speed (Slow) setting.
RT L Fast (RT Low Frequency Fast Rate)
Adjust the speed of the low-range rotor for the high-
speed (Fast) setting.
RT Lo Accl (RT Low Frequency Acceleration)
Adjust the time over which the rotation speed of the
low-range rotor will change from low-speed to high-
speed (or high-speed to low-speed) rotation.
Smaller values will require greater time to reach the
new rotational speed.
RT Lo Lev (RT Low Frequency Level) 0 - 127 [9]
Adjust the volume of the low-range rotor.
Odrv/Dist [1]
0 - 127 [2]
Small/BltIn/2-Stk/3-Stk [3]
Off/On [4]
L63 - 0 - R63 [16]
0 - 127 [17]
0.05 - 10.0 [6]
0.05 - 10.0 [7]
0 - 15 [8]
87
