SHOWTEC Fademaster 16 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Fademaster 16
V2
ORDERCODE 50406

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fademaster 16 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SHOWTEC Fademaster 16

Summary of Contents for SHOWTEC Fademaster 16

  • Page 1 Fademaster 16 ORDERCODE 50406...
  • Page 2 For more information: iwant@showtec.info You can get some of the best quality, best priced products on the market from Showtec. So next time, turn to Showtec for more great lighting equipment. Always get the best -- with Showtec ! Thank you!

  • Page 3: Table Of Contents

    Showtec Showtec Fademaster 16 Product Guide ™ Warning..…...................…………………………………………....Safety-instructions…………………………………………………………………………………….…...... Operating Determinations……………………………………………………………………………....... Return Procedure……………………………………………………………………………........Claims……………………………………………………………………………............Description..…................……….……………………………….…....Features…….……………………………………………………………………………………….……..…....Overview………………………………………………………………………………………………………....Controller front..............................Controller backside............................Installation................…...……………………………………..…....Installation............………………………………………..………........Common Terms...........………………………………………..………........Set Up and Operation..............……..…………………………….…....- Programming……………………….........……………………………..…......- Exit programming…………………….............………........- Chase / Manual............………................. - Chase Mode............………................

  • Page 4: Warning

    Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: • Fademaster 16 • Incl. Power adapter 1,75m • User manual...

  • Page 5: Operating Determinations

     If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.

  • Page 6: Return Procedure

    Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture.

  • Page 7: Description

    Description of the device Features The Fademaster 16 is a DMX controller from Showtec and features: • 32 channel programmable DMX controller • Total output channels: 16 x 2 (pages) • program 12 scenes • Manual Mode • Built-in chase •...

  • Page 8: Controller Backside

    14) ON/OFF power switch turns the controller on and off Installation Remove all packing materials from the Fademaster 16. Check that all foam and plastic padding is removed. Screw the equipment into a 19" rack. Connect all cables. Always disconnect from electric mains power supply before cleaning or servicing.

  • Page 9: Common Terms

    Common Terms The following are common terms used in intelligent light programming. Blackout is a state where all lighting fixtures’ light output are set to 0 or off, usually on a temporary basis. DMX-512 is an industry standard digital communication protocol used in entertainment lighting equipment.

  • Page 10: Set Up And Operation

    Set Up and Operation Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. Programming 1) Press PROGRAM and then press SCENE 1、5、6、8. 2) Use the fader and PAGE button to set the DMX value，...

  • Page 11: Maintenance

    4. Check power from the wall, all cables, the fuse, the settings (return to default), etc. 5. If all of the above appears to be O.K., plug the unit in again. 6. If nothing happens after 30 seconds, unplug the device. 7. Return the device to your Showtec dealer.

  • Page 12: Product Specifications

    Product Specification Model: Showtec Fademaster 16 Power Supply: DC 9Volt - 500mA Power connector: Adapter included Mode: Chase / Manual 32 DMX Channels Output: DMX-512 standard Output connector: 3-pin XLR female Input connector: 3-pin XLR male Dimensions: 535 x 195 x 100 mm (LxWxH)
