Intermec CK60 Vehicle Dock Quick Start Manual

Environmental Specifications
Operating Temperature: -20°C to +50°C (-4°F to +122°F)
Storage temperature: -30°C to 70°C (-22°F to +158°F)
Relative Humidity: 5% to 95%
USB Host Micro DB9F Connector Pin Outs
Pin Number Signal Name I/O to Computer Description
1 USBH_D- I/O USB Host data negative
2 USBH_D+ I/O USB Host data positive
3 NC
4 NC
5 GND PWR
6 NC Ethernet receive negative
7 NC
8 NC
9 VBUS PWR PWR_OUT to power USB peripherals
Shell C-GND PWR Chassis Ground
Serial RS-232 DB9M Connector Pin Outs
Pin Number Signal Name I/O to Computer Description
1 DCD I RS-232 Data carrier detect
2 RXD I RS-232 Receive data
3 TXD O RS-232 Transmit data
4 DTR O RS-232 Data terminal ready
5 GND PWR Signal Ground
6 DSR I RS-232 Data set ready
7 RTS O RS-232 Request to send
8 CTS I RS-232 Clear to send
9 POWER PWR 5 volts @ .5 Amps 2.5 Watts
Shell C-GND PWR Chassis Ground
CK60 Vehicle Dock Quick Start Guide
*930-006-001*
P/N 930-006-001
Corporate Headquarters
6001 36th Avenue West
Everett, Washington 98203 U.S.A.
tel 425.348.2600
www.intermec.com
© 2005 Intermec Technologies
Corporation. All rights reserved.
CK60 Vehicle Dock

Quick Start Guide
