Overload protection!
If the total load on the equipment is to high you will only be able to drive for 2 seconds.
The system will then stop and you need to release the table from load before new drive.
After load release, press button again.
Overheat protection!
If heavy loaded and driven continuously for a long period of time the motor might get
overheated. The software observes this and if overheated system will shut down and you
will have to wait about 9 minutes before being able to run again.
Anti Collision "AC" (optional)!
The ECS+ can be equipped with intelligent software for pinch protection. If a collision is
detected system will stop and back off about 1 inch.
IMPORTANT! Make sure to remove the blocking item causing the pinch before trying to
operate the table again. Failure to do so may cause injury to user or equipment.
During low ration the currents to each connected motor is continuously measured and
any variation of current is evaluated about 50 times each second.
3.1.1 Upward desktop movement
This function enables you to adjust the desktop upwards. To change
its position, proceed as follows: Press the handset "up" button. Keep
pressing the button until the required desktop height is reached.
NOTICE
The desktop will continue moving upwards until you release the button or the maximum
height is reached
3.1.2 Downward desktop movement
This function enables you to adjust the desktop downwards.
To change its position, proceed as follows: Press the handset
"down" button. Keep pressing the button until the required desk-
top height is reached.
String Furniture AB www.string.se info@string.se
Upwards
Downwards
