DANGER
Risk of electrical shock:
Improper connection of the equipment can result in a risk
of electric shock. Check with a qualified electrician for
any concerns. Do not modify the plug provided with the
product – if it will not fit the outlet have a proper outlet
installed by a qualified electrician.
This product is designed for the voltage indicated on the
power supply label. No adapters should be used with this
product.
CAUTION
Risk of electrical shock:
Before you plug in the power cord, check the following again:
• The voltage must be as specified on the power supply label.
• When the power cord is plugged in, the electrical control devices are operational.
NOTICE
In case of a main power breakdown, or if the power cord is unplugged during the mo-
vement of the drives, a manual reset may be necessary! Please see section 3.2 manual
reset.
2.4

System configuration (example)

The figure to the right shows the motor
driving assignment for a configuration
example. This configuration consists of:
1. Power Supply
2. Motor cables
3. Handset
4. Control unit
String Furniture AB
Sidebar
www.string.se info@string.se
4
Crossbar
2
House
Column
3
1
