Renesas Synergy™ S124
Sensor Panel Board User Guide
Introduction
This User guide describes about the Renesas Sensor Panel Board. In this Sensor Panel solution, Renesas Synergy™
S124 Microcontroller Group and Renesas RL78/G1D Bluetooth Low Energy (hereafter called BLE) are the highlighted
Components. Using this Sensor Panel Board, developers can easily start to evaluate on Renesas Lighting solution, using
wireless connectivity and Renesas Synergy™ S124 device including Temperature sensor, Light
®
RL78/G1D Bluetooth
sensor and necessary user interface.
Target Device
R7FS124773A01CFM
Contents
1.
Overview ......................................................................................................................... 2
1.1
Specification Outline .................................................................................................................. 2
2.
Sensor Panel System ..................................................................................................... 3
Renesas Synergy™ S124 device ............................................................................................... 3
2.1
2.2
RL78/G1D module (RY7011) ....................................................................................................... 3
3.
Building Sample Project ................................................................................................ 4
Renesas Synergy™ S124 Firmware .......................................................................................... 4
3.1
3.1.1
3.1.2
3.2
Renesas RL78/G1D Firmware .................................................................................................... 7
3.2.1
3.2.2
4.
Programming to Sensor Panel ...................................................................................... 9
Renesas Synergy™ S124 device ............................................................................................... 9
4.1
4.2
RL78/G1D module (RY7011) ..................................................................................................... 10
5.
Circuit Diagram ............................................................................................................. 11
R12AN0074EU0100 Rev.1.00
Nov 15, 2017

APPLICATION NOTE

2
studio Workspace ................................. 5
2
studio Workspace .............................. 6
2
studio Workspace ................................................. 7
2
studio Workspace ............................................... 8
R12AN0074EU0100
Rev.1.00
Nov 15, 2017
Page 1 of 19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Synergy S124 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Renesas Synergy S124

Summary of Contents for Renesas Synergy S124

  • Page 1: Table Of Contents

    Nov 15, 2017 Introduction This User guide describes about the Renesas Sensor Panel Board. In this Sensor Panel solution, Renesas Synergy™ S124 Microcontroller Group and Renesas RL78/G1D Bluetooth Low Energy (hereafter called BLE) are the highlighted Components. Using this Sensor Panel Board, developers can easily start to evaluate on Renesas Lighting solution, using wireless connectivity and Renesas Synergy™...

  • Page 2: Overview

    Renesas Synergy™ S124 Sensor Panel Board User Guide Overview The Sensor Panel Board uses the Renesas Synergy™ S124, 32-MHz Arm ® ® Cortex -M0+ microcontroller with 256 KB of code flash, 24 KB of SRAM, and 4 KB of data flash. It has two push button switches, one reset button, and three ®...

  • Page 3: Sensor Panel System

    Renesas Synergy™ S124 Sensor Panel Board User Guide Sensor Panel System Figure 2 shows the Sensor Panel System Block diagram. Typically the Sensor Panel board has five sections: Renesas Synergy™ S124 microcontroller (MCU), Bluetooth ® , user input/output, Sensors, and regulated power supply with battery.

  • Page 4: Building Sample Project

    Building Sample Project Renesas Synergy™ S124 Firmware This Sensor Panel board populates with Renesas Synergy™ S124 microcontroller to evaluate with onboard sensors. Thus, Sensor Panel board can be used as development platform. When using this Sensor Panel board, PMOD™ module can be added for extended feature through UART or CSI peripheral.

  • Page 5: Importing The Renesas Synergy™ Project In E

    Renesas Synergy™ S124 Sensor Panel Board User Guide Figure 4 e studio Workspace environment Import Projects Importing the Renesas Synergy™ Project in e 3.1.1 studio Workspace To import the project into e studio workspace, following the below step 1 to 5.

  • Page 6: Debugging The Renesas Synergy™ Project In E Studio Workspace

    Select Arm’s J-Link for debug hardware and R7FS12477 for Target Device. Click Debug to start debugging. Figure 7 shows the Debug window. Click Resume (F8) to run the program in Debug mode. studio workspace in debugging mode for Renesas Synergy™ S124 Figure 7 e R12AN0074EU0100 Rev.1.00...

  • Page 7: Renesas Rl78/G1D Firmware

    Renesas Synergy™ S124 Sensor Panel Board User Guide Renesas RL78/G1D Firmware ® This Sensor Panel board populates with Renesas Bluetooth module, RY7011 that includes RL78/G1D device to ® evaluate for Bluetooth communication. Thus, Sensor Panel board is suitable for developing a wireless communication platform.

  • Page 8: Debugging The Rl78/G1D Project In E Studio Workspace

    Set the Debug configuration by selecting a project to debug. Figure 10 shows the Debug Configuration window. Select Debug Configuration from the Run pulldown menu. Right-click Renesas GDB hardware Debugging. Select New from the options menu to create a new debug launch. Select the Debugger tab (see Figure 6).

  • Page 9: Programming To Sensor Panel

    Renesas Synergy™ S124 Sensor Panel Board User Guide Programming to Sensor Panel Renesas Synergy™ S124 device Step 1. Attach the J-Link connector (J1) to the SEGGER J-Link debugger unit and attach PC USB connector via micro USB cable for power supply. See Figure 3.

  • Page 10: Rl78/G1D Module (Ry7011)

    To program the RL78/G1D Bluetooth , you use the E1 programmer and perform the following steps: Step 1. Connect the Renesas E1 programmer/Debugger to connector J9 on the Sensor Panel board. See Figure 8 for connection. Step 2. To program RL78/G1D Beacon project output (R5F11AGJ_Beacon_SPB.hex), launch the Renesas Flash Programmer (RFP).

  • Page 11: Circuit Diagram

    Renesas Synergy™ S124 Sensor Panel Board User Guide Circuit Diagram This section shows the Sensor Panel board schematics in total 6 sheets and RL78/G1D Module (RM-110-RFB-2) schematics in total one sheet. R12AN0074EU0100 Rev.1.00 Page 11 of 19 Nov 15, 2017...
  • Page 12 REVISIONS REVISIONS REVISIONS (MAINTAIN ALL SHEETS AT SAME REVISION LEVEL) (MAINTAIN ALL SHEETS AT SAME REVISION LEVEL) (MAINTAIN ALL SHEETS AT SAME REVISION LEVEL) NOTES: DESCRIPTION DESCRIPTION DESCRIPTION EO NO EO NO EO NO DATE DATE DATE APPROVED APPROVED APPROVED 1/3/17 1/3/17 1/3/17...
  • Page 13 REVISIONS REVISIONS REVISIONS (MAINTAIN ALL SHEETS AT SAME REVISION LEVEL) (MAINTAIN ALL SHEETS AT SAME REVISION LEVEL) (MAINTAIN ALL SHEETS AT SAME REVISION LEVEL) DESCRIPTION DESCRIPTION DESCRIPTION EO NO EO NO EO NO DATE DATE DATE APPROVED APPROVED APPROVED 1/3/17 1/3/17 1/3/17 RELEASE...
  • Page 14 REVISIONS REVISIONS REVISIONS (MAINTAIN ALL SHEETS AT SAME REVISION LEVEL) (MAINTAIN ALL SHEETS AT SAME REVISION LEVEL) (MAINTAIN ALL SHEETS AT SAME REVISION LEVEL) DESCRIPTION DESCRIPTION DESCRIPTION EO NO EO NO EO NO DATE DATE DATE APPROVED APPROVED APPROVED 1/3/17 1/3/17 1/3/17 RELEASE...
  • Page 15 REVISIONS REVISIONS REVISIONS (MAINTAIN ALL SHEETS AT SAME REVISION LEVEL) (MAINTAIN ALL SHEETS AT SAME REVISION LEVEL) (MAINTAIN ALL SHEETS AT SAME REVISION LEVEL) DESCRIPTION DESCRIPTION DESCRIPTION EO NO EO NO EO NO DATE DATE DATE APPROVED APPROVED APPROVED 1/3/17 1/3/17 1/3/17 RELEASE...
  • Page 16 2.2uF P147/ANI18 P20/ANI0/AVREFP P147 P23/ANI3 P03/ANI16/RxD1 P22/AIN2 P02/ANI17/TxD1 P21/ANI1/AVREFM P01/TO00 RENESAS BLUETOOTH MODULE RENESAS BLUETOOTH MODULE RENESAS BLUETOOTH MODULE THIS DOCUMENT CONTAINS SECTIONS THIS DOCUMENT CONTAINS SECTIONS THIS DOCUMENT CONTAINS SECTIONS SCHEMATIC DIAGRAM SCHEMATIC DIAGRAM SCHEMATIC DIAGRAM WHICH ARE CONSIDERED...
  • Page 17 REVISIONS REVISIONS REVISIONS (MAINTAIN ALL SHEETS AT SAME REVISION LEVEL) (MAINTAIN ALL SHEETS AT SAME REVISION LEVEL) (MAINTAIN ALL SHEETS AT SAME REVISION LEVEL) DESCRIPTION DESCRIPTION DESCRIPTION EO NO EO NO EO NO DATE DATE DATE APPROVED APPROVED APPROVED 1/3/17 1/3/17 1/3/17 RELEASE...
  • Page 18 SILK: Unmount Unmount P120 SILK: P137 Unmount P120 P137 P123 MOD1 0ohm RY7011A0 SILK: P123 1Kohm 10Kohm 2.2Kohm 2.2Kohm GPIO_30 P30/INTP3 P61/SDAA0 GPIO_61 GPIO_16 P16/TI01/TO01/INTP5 P60/SCLA0 GPIO_60 10pF P15/SCK20/SCL20(TI02)/(TO02) P123/XT1 P14/SI20/SDA20/(SCLA0)/(TI03)/(TO03) P124/XT2/EXCLKS 32.768kHz P137 P13/SO20/(SDAA0)/(TI04)/(TO04) P137/INTP0 UART_Tx P12/SO00/TxD0/TOOLTxD/(TI05)/(TO05) RESET E1&RST 12pF UART_Rx P11/SI00/RxD0/TOOLRxD/SDA00/(TI06)/(TO06)
  • Page 19 Renesas Synergy™ S124 Sensor Panel Board User Guide Website and Support Renesas Electronics Website http://www.renesas.com/ Inquiries http://www.renesas.com/contact/ All trademarks and registered trademarks are the property of their respective owners. R12AN0074EU0100 Rev.1.00 Page 19 of 19 Nov 15, 2017...
  • Page 20 Revision History Description Rev. Date Page Summary – 1.00 Nov 15, 2017 Initial Release...
  • Page 21 General Precautions in the Handling of Microprocessing Unit and Microcontroller Unit Products The following usage notes are applicable to all Microprocessing unit and Microcontroller unit products from Renesas. For detailed usage notes on the products covered by this document, refer to the relevant sections of the document as well as any technical updates that have been issued for the products.
