StarTech.com TBT3TBTADAP Quick Start Manual

Quick-start guide
Thunderbolt™ 3 to Thunderbolt Adapter
TBT3TBTADAP
FR: Guide de l'utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l'uso - it.startech.com

Package contents

• 1 x Thunderbolt™ 3 to Thunderbolt adapter

System requirements

• Host desktop computer or laptop with a Thunderbolt 3 port
• Thunderbolt or Thunderbolt 2 device
• Thunderbolt cable
System requirements are subject to change. For the latest
requirements, please visit www.startech.com/TBT3TBTADAP.
Introduction
Use the TBT3TBTADAP adapter to connect a Thunderbolt 3 desktop
or laptop computer to legacy Thunderbolt devices, including
external hard drives, Thunderbolt displays, and Mac computers that
are Thunderbolt capable. The TBT3TBTADAP is compatible with first-
generation Thunderbolt and Thunderbolt 2 devices, making it a cost-
effective method to connect newer devices to older peripherals.
You can use the TBT3TBTADAP to connect to first-generation
Thunderbolt devices at 10Gbps and Thunderbolt 2 devices at
20Gbps.

Product diagram

Thunderbolt 3 USB-C connector
For the latest information, technical specifications, and support for
this product, please visit www.startech.com/TBT3TBTADAP.
Thunderbolt 2 port
*actual product may vary from photos
The following is an example of a setup that includes the Thunderbolt
adapter:
Connect the Thunderbolt adapter
Your computer's Thunderbolt 3 ports might not function properly
until you update one or more of the following on your computer:
• BIOS
• Thunderbolt firmware
• Thunderbolt 3 controller drivers
• Thunderbolt 3 software
The required updates will vary depending on your computer.
For an up-to-date list of affected computers and instructions, visit
http://thunderbolttechnology.net/updates. If your manufacturer
isn't listed on the Thunderbolt website, contact your manufacturer.
Make sure that the Thunderbolt device that you're using with the
TBT3TBTADAP is compatible with the OS that you're running on your
computer.
1. Connect the Thunderbolt 3 USB-C connector to the Thunderbolt
3 USB-C port on your desktop or laptop.
2. Use a Thunderbolt cable to connect the Thunderbolt device to the
Thunderbolt 2 port on the Thunderbolt adapter.
3. If you're using a Windows® operating system, a pop-up message
may appear requesting permission to allow the adapter to
connect to your computer. If this message appears, click OK > Yes.
In the drop-down list, select Connect always and click OK.
Manual Revision: 08/04/2016
