Please read the following instructions throughly before using this torchlight, and use it correctly.
CAUTION
⦁ Do not look at the light directly.
⦁ Do not open the front cover immediately after using the torchlight because the bulb is very hot.
⦁ Be sure to turn the switch OFF before replacing the bulb or when not using.
⦁ Do not expose the torchlight to rain.
⦁ Do not shock or disassemble the torchlight.
⦁ Do not allow the torchlight to contact gasoline, thinner etc.
⦁ Do not leave the torchlight in a car or the like that tends to be exposed to be searching heat of the sun
(above 60°C). Otherwise, troubles can result.
SPECIFICATIONS
Battery
Bulb
Operating time
Dimensions (without battery)
Weight (without battery)
HOW TO USE
1
Handle
Push
Insert
Push
Remove
Latch
Battery
1. BATTERY INSERT/REMOVAL
Correctly insert the battery into the torchlight. (Fig. 1)
Pressing on the latch, remove the battery from the torchlight. (Fig. 1)
2. HEAD ANGLE ADJUSTMENT
Adjusting the lighting angle, hold the handle then adjust the head angle.
It can be adjusted at 0°, 30°, 60°, 90° and 110°. (Fig. 2)
3. BULB REPLACEMENT
(1) Remove the front cover. (Fig. 3)
(2) Replace the bulb. (Fig. 4) (A spare bulb is set in the head.)
We declare under our sole responsibility that this product conforms to RoHS Directive 20011/65/EU.
Representative offi ce in Europe
Hitachi Power Tools Europe GmbH
Siemensring 34, 47877 Willich, Germany
Head offi ce in Japan
Hitachi Koki Co., Ltd.
Shinagawa Intercity Tower A, 15-1,
Konan 2-chome, Minato-ku, Tokyo, Japan
T O R C H L I G H T
EB14, EB18, BCC14, BCC18, BCH14, BCH18, BCL14, BCL18,
EBL14, EBM18 series (sold separately)
18 V, 0.6 A
Approx. 3 hours (Using full charged EB1820L battery)
Approx. 4.5 hours (Using full charged EB1830HL battery)
85 mm (diameter) × 252 mm (length)
0.3 kg
2
110°
Head
Switch
Handle
Object of declaration : Hitachi Torchlight UB18D
EC DECLARATION OF CONFORMITY
31. 5. 2017
Naoto Yamashiro
European Standard Manager
U B 1 8 D
3
Attach
Front
cover
Remove
4
31. 5. 2017
M. Harada
Executive Offi cer
705
Code No. C99512015 A
Bulb
