tabellet Apartment Station Switch Settings

Mute Time Setting SW (1-4)
1 2 3 4 Mute Time
On On On On Disabled¹
Off On On On 2 minutes
On Off On On 5 minutes
Off Off On On 10 minutes
On On Off On 15 minutes
Off On Off On 20 minutes
On Off Off On 30 minutes
Off Off Off On 45 minutes
On On On Off 1 hour
Off On On Off 2 hours
On Off On Off 4 hours
Off Off On Off 5 hours
On On Off Off 6 hours
Off On Off Off 8 hours
On Off Off Off 10 hours
Off Off Off Off *Indefinite²
*Default setting¹Disabled means touching the mute symbol has no effect.
²Indefinite; the mute is cancelled by touching the symbol again.
Individual Functions DIP-SW (5-8)
SW-5 Master / Extension
*Off Master
On Extension / Slave
SW-6 Auto Display on Ring Apartment Station display behaviour
*Off Display during ring
On No display during ring
SW-7 Spare
*Off
On
SW-8 Spare
*Off
On
*Default setting
Video Terminator Jumper Setting
The jumper is situated next to the input connector. It is 3 pin and labelled On and Off.
The jumper should be on when there is only one apartment station on an individual BSC4
output. Otherwise only the last apartment station should have a jumper set to On the rest
being set to Off.
PD-307 Issue 2
tabellet Apartment Station 2-72 Way System
Which Apartment Station to set
Only or first apartment station per BSC4 output.
Second and subsequent apartment stations per BSC4
output.
Picture is on while ringing, stays on when answered.
Picture is off while ringing, comes on when answered.
Spare
Spare
Installation and Operating Manual
SW
OFF ↔ ON
SW
OFF ↔ ON
Page 26 of 48
