WLS-TC User's Guide
Microcontroller
Parameter
Type
Wireless communications
Parameter
Communication standard
Range
Transmit power output
Receiver sensitivity
RF channels
Addressing
Encryption
Contains FCC ID: OUR-XBEEPRO. The enclosed device complies with Part 15 of the FCC Rules.
Note 8:
Operation is subject to the following two conditions: (i.) this device may not cause harmful
interference and (ii.) this device must accept any interference received, including interference that may
cause undesired operation.
Note 9:
Canada: Contains Model XBee Radio, IC: 4214A-XBEEPRO
Caution! To satisfy FCC RF exposure requirements for mobile transmitting devices, a separation distance
of 20 cm or more should be maintained between the antenna of this device and persons during
device operation. To ensure compliance, operations at closer than this distance is not
recommended. The antenna used for this transmitter must not be co-located in conjunction with
any other antenna or transmitter.
USB +5V voltage
Parameter
USB +5V (VBUS) input voltage range
Table 8. Microcontroller specifications
Specification
Three high performance 8-bit RISC microcontrollers
Table 9. Wireless communications specifications
Specification
IEEE 802.15.4, ISM 2.4GHz frequency band, non-beacon, point-to-point
Indoor/urban: Up to 150 ft (50 m)
Outdoor RF line-of-sight: Up to ½ mile (750 m)
10 mW (10 dBm)
–100 dBm (1% packet error rate)
12 direct sequence channels available, channels 12 – 23 (2.410 – 2.465 GHz)
(software selectable)
16-bit PAN (personal area network) IDs per channel (software selectable)
64-bit device address
128-bit AES (software selectable)
Table 10. USB +5V voltage specifications
Condition
21
Specifications
Specification
4.75 V min to 5.25 V max
