YOKOGAWA GX60 User Manual

Paperless recorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

User's
Manual
Contents
Introduction ................................................................................. 1
Handling Precautions of the GX/GP ............................................ 5
SD Memory Card Handling Precautions ...................................... 5
Checking the Package Contents ................................................. 5
Standard Accessories ................................................................. 8
Conventions Used in This Manual ............................................... 9
Protection of Environment ..........................................................10
Functional Overview ...................................................... 11
Overview ...................................................................................11
A Variety of Source Signals ........................................................11
Expandable Module Construction ...............................................11
mode) ....................................................................................12
Data Storage .............................................................................12
A Variety of Display Functions ....................................................12
Touch Screen ............................................................................13
Freehand Messages ..................................................................13
Versatile Network Functions and Software .................................13
Other Functions ........................................................................ 14
System Configuration ................................................................15
Component Names ........................................................16
GX20/GX10 ...............................................................................16
GP20/GP10 ...............................................................................17
GX60/GX90EX ..........................................................................17
..............................................................................................18
Operating Procedure ......................................................20
Installation and Wiring ....................................................22
Installation Location ................................................................... 22
Installation Procedure ................................................................ 23
Connect an GX60 ..................................................................... 25
Installing and Removing I/O Modules ......................................... 26
Wiring ....................................................................................... 28
Power Specialties, Inc. | www.powerspecialties.com | (816) 353-6550
Model
GX10/GX20/GP10/GP20
Paperless Recorder
First Step Guide
Basic Operation ..............................................................37
Turning the Power On and Off ................................................... 37
Setting and Removing SD Memory Cards ................................. 38
Viewing the Operation Screen (Trend) ....................................... 38
Displaying the Menu Screen ...................................................... 39
Setting the Date and Time* ........................................................ 39
Configuring the Inputs ............................................................... 40
Starting Measurement and Recording ....................................... 40
Switching between Operation Screens ...................................... 40
Saving Data to USB Memory .................................................... 41
Switching the Quick Settings (GP only) ...................................... 41
Setting Alarms .......................................................................... 42
Alarm DO output ....................................................................... 43
Registering and Deleting Favorite Screens ................................ 44
Setting the Measurement Mode .....................................45
Setting the Measurement Mode ................................................ 45
Limitations................................................................................. 45
Reconfiguring the GX/GP .......................................................... 46
(Initializing all settings) ........................................................... 46
Saving and Loading Setting Parameters .......................47
Saving Setting Parameters........................................................ 47
Loading Setup Parameters ....................................................... 47
Web Application .............................................................48
Starting the Web Application ..................................................... 48
Closing the Web Application ...................................................... 48
Application Software ......................................................49
PC System Requirements ......................................................... 49
Installation ................................................................................. 49
Starting and Closing Universal Viewer ....................................... 50
Starting and Closing Hardware Configurator .............................. 50
Setup Menu Map .............................................................51
IM 04L51B01-02EN
