  • Page 1 User’s Manual Model GX10/GX20/GP10/GP20/GM10 Log Scale (/LG) User’s Manual IM 04L51B01-06EN 4th Edition...

  • Page 3: Introduction

    Describes how to use the Loop Control Function, Loop Control Function, Program Control Program Control Function (/PG Option). Function (/PG Option) User’s Manual Continued on the next page 4th Edition: May 2020 (YK) All Rights Reserved, Copyright © 2014, Yokogawa Electric Corporation IM 04L51B01-06EN...
  • Page 4 QR Code is a registered trademark of DENSO WAVE INCORPORATED. Trademarks • SMARTDAC+ is registered trademarks of Yokogawa Electric Corporation. • Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

  • Page 5: Recorder Versions Described In This Manual

    Recorder Versions Described in This Manual The contents of this manual correspond to the GX/GP with release number 4 (see the STYLE S number) and style number 3 (GX10/GX20/GP10), style number 4 (GP20) (see the STYLE H number) and the GM10 with release number 4 (see the STYLE S number) and style number 1 (see the STYLE H number).

  • Page 6: Conventions Used In This Manual

    Conventions Used in This Manual Unit Denotes 1024. Example: 768K (file size) Denotes 1000. Markings Improper handling or use can lead to injury to the user or damage to the instrument. This symbol appears on the instrument to indicate that the user must refer to the user’s manual for special instructions.

  • Page 7: Table Of Contents

    Contents Introduction ..............................i Recorder Versions Described in This Manual ..................iii Conventions Used in This Manual ......................iv Using the Log scale Function ......................1 Log Scale Display Function ........................1 Restrictions ............................... 2 Setting the Log scale ........................... 3 AI channel settings ...........................
  • Page 8 Blank...

  • Page 9: Using The Log Scale Function

    Using the Log scale Function Log Scale Display Function You can apply a logarithmic voltage that has been converted from a physical value to the recorder, and then use the log scale (logarithmic scale) to display and record the physical value.

  • Page 10: Restrictions

    Using the Log scale Function Restrictions Partial You cannot set the partial display on a channel that is set to log scale. Differential Computation between Channels If you set the reference channel of a differential computation between channels to a channel that is set to log scale, an error will be returned as the measured result of the differential computation between channels.

  • Page 11: Setting The Log Scale

    Setting the Log scale AI channel settings Log input computation cannot be specified on current (mA), 4-wire RTD/resistance modules. Range settings Path GX/GP: MENU key > Browse tab > Setting > Setting menu AI channel settings > Range Web application: Config. tab > AI channel settings > Channel range (display example: 0001-0010) >...
  • Page 12 Setting the Log scale Range Set the input type range. Range Details Type Range Selectable Range Default Value Volt 20mV –20.000 mV to 20.000 mV 60mV –60.00 mV to 60.00 mV 200mV –200.00 mV to 200.00 mV –1.0000 V to 1.0000 V –2.0000 V to 2.0000 V –6.000 V to 6.000 V –20.000 V to 20.000 V...
  • Page 13 Setting the Log scale • When Calculation is Log input Set the settings so that Scale Lower is less than Scale Upper. The mantissas of scale lower and scale upper can be set to different values. Mantissa of Scale Setting Range Lower 1.00 1.00E‒15 to 1.00E+15.
  • Page 14 Setting the Log scale • Pseudo-Log, Linear-Log You can set the settings so that Scale Lower is less than Scale Upper or so that Scale Lower is greater than Scale Upper. The mantissa that you set for Scale Lower is automatically set as the mantissa of Scale Upper.
  • Page 15 Setting the Log scale First-order lag filter (high-speed AI module only) Setup Item Selectable Range or Options Default Value On/Off Off, On Filter coefficient 3 to 300 1 Appears when On/Off is set to On. On/Off Set this to On to use the first-order lag filter. Filter coefficient Filter time constant = scan interval ×...
  • Page 16 Setting the Log scale Bias Setup Item Selectable Range or Options Default Value Value Numeric value (–999999 to 999999) Value Set the bias to add to input values or linear scaling values (input calculation). Channel on which bias is added Input value Measured value Bias (a constant value)
  • Page 17 Setting the Log scale Pseudo-Log input, Linear-Log input Example 3 Positive scale in which the mantissa of the scale lower limit and the mantissa of the scale upper limits are 1 This is the same as when the mantissa of the scale lower limit and the mantissa of the scale upper limit are both 1 in log input example 1.
  • Page 18 Setting the Log scale Alarm settings Path GX/GP: MENU key > Browse tab > Setting > Setting menu AI channel settings > Alarm Web application: Config. tab > AI channel settings > Channel range (display example: 0001-0010) > Alarm Hardware configurator: AI channel settings > Channel range (display example: 0001-0010) >...
  • Page 19 Setting the Log scale Logging Set this On to display an alarm (notify you) when an alarm occurs. If set to Off, when an alarm occurs, the recorder outputs signals to alarm output DO channels or internal switches but does not display the alarm. Alarms are also not recorded in the alarm summary. Output type Set the alarm output destination.
  • Page 20 Setting the Log scale Color scale band settings (Display settings) Path GX/GP: MENU key > Browse tab > Setting > Setting menu AI channel settings > Display settings Web application: Config. tab > AI channel settings > Channel range (display example: 0001-0010) >...

  • Page 21: Setup Examples

    Setting the Log scale Setup Examples pseudo-Log input and Log input (nonlinear log) setup examples are shown below. Setting the Pseudo-Log Range This setting is for logging the pseudo log output (see the table below) of a vacuum gauge. Pressure Reading [Pa] Output Voltage [V] Pressure Reading [Pa] Output Voltage [V] 1.30x10 0.13...
  • Page 22 Setting the Log scale Setting the Log input (Nonlinear Log) In this example, pressure is measured by applying calibration correction to linearly approximate the nonlinear output of a vacuum gauge. Calculating linearizer Input and linearizer output The following figure is an example of a nonlinear output of a vacuum gauge. The 10 red dots in the figure are the set points for the linearizer approximation.
  • Page 23 Setting the Log scale The combination of ‚ and „ is the set point. ——→ ƒ „ ‚ „ log() Linearly scale ƒ using ‚. point Linearizer Linearizer input [V] output [V] 0.200 0.200 -4.301029996 2.273611013 0.550 2.274 3.166666667 1.250 3.167 -3.698970004 4.05972232 2.700...
  • Page 24 Blank...
