7.
Hold polisher with left hand and pull
rear case straight back with the other
hand as shown in Figure 20.
NOTE: Do not twist case in a side to
side motion when pulling back.
8.
Pull back rear case until carbon brush
assembly is exposed as shown in
Figure 21.
NOTE: Do not pull rear case further back
from this point.
Figure-20
Figure-21
19
