DeView CCD Instruction Manual

CCD Bullet Camera
Instruction Manual
www.devieweurope.com
Parts and Descriptions
Bullet Camera
Accessories
Short Screws X 4
Power Lead X 1
Wall Plugs X 4
Rubber Sealing Plug X1
Template X1
Specifications
General Specifications
TV System
Image Sensor
Effective Picture
Scanning Frequency
Resolution
Minimum Illumination
Day Mode 0.3Lux(F1.2,50IRE, AGC ON,IR Off), Night Mode 0 Lux (IR ON)
S/N Ratio
Video Output
2nd Video Output
Power Source
Power Consumption
Operating Temperature
Storage Temperature
Dimensions
Functional Specifications
Shutter Control
Shutter Speed
Adaptive Tone Reproduction (ATR)
High-Light Compensation (HLC)
Backlight Compensation (BLC)
AGC Gain Control
Day/Night
White Balance Control
Auto White Balance Range
Mirror
Defog
Sync System
Motion Detection
Privacy Zone
Digital Noise Reduction
Digital Zoom
DIS
IR Optimizer
IR LED Count
IR Illumination Wavelength
IR Illumination Range
Color Camera
Sunhood
NEC Class 2 / Limited
Power Source Supply
Required
Alarm Common Black
Alarm Brown
GND Red
D/N Switch Orange
RS485- Yellow
RS485+ Green
Video Output Terminal
Power Input Terminal
NTSC PAL
Sony 1/3" Super HAD-II
976(H) x 494(V) 976(H) x 582(V)
60Hz 50Hz
700 TVL
50dB (100 IRE, F1.2)
1.0Vpp Composite Output
Yes (supports installation check)
12 VDC ±10% / 24 VAC ±20%
Normal:2.2W , IR On: 7W(Max)
-10°C ~ +50°C
-20°C ~ +60°C
Φ 84.5mm x 186.6mm (L) (camera unit + sunhood)
AUTO/MANUAL/FIX
NTSC: 1/60 ~ 1/100000 PAL: 1/50 ~ 1/100000
OFF / LOW / MID / HIGH
ON/OFF
Full Range
44.8 dB
TDN (AUTO ,COLOR ,NIGHT )
ATW / Manual / Push / Push Lock / USER1,2
Indoor：1800K~10500K / Outdoor：6500K~10500K
OFF/V-FLIP/H-FLIP/HV-FLIP
ON/OFF
INT /LL
4 Areas
Up to 15 Masks
3D DNR
255X Max
Yes
ON/OFF
30PCS
850 nm
50 m
Lens Specifications
Lens Specifications
Lens Type
Focal Length
F-No.
Iris Range
Minimum Object Distance
Field of View
Precautions
This product must be installed and maintained in accordance with good installation practices by qualified personnel only.
To prevent damage to your camera or injury to yourself or to others, read and comply with the safety precautions as follows:
Never attempt to disassemble or modify the camera.
Any modification could lead to damages that are not
covered by the guarantee.
Make sure the power source is switched off and
disconnected before installation. Refer servicing to
qualified personnel only.
To prevent fire or electrical shock, use only
regulated power supply and the wiring should
be used for the appropriate input terminal.
V531-BK002-S01
VER.11/2015
Camera Installation
1
Screws can be loosened and the desired position can be adjusted.
Loosen and tighten the screws by using a torx driver.
Tilt Appro.120°
Loosen the screw to adjust the
tilt of the camera
2
Slide the sunhood into the groove in the direction indicated by the arrow,
then tighten the screw.
Auto IRIS DC Lens
2.8 ~ 10 mm
F1.2
F1.2 ~ F360
0.15 m
Diagonal 125.0° ~ 36.0°
Horizontal 94.6° ~ 28.8°
Vertical 68.4° ~ 21.6°
Do not expose or operate the camera in wet areas.
Moisture may damage the camera and also increase
the danger of electrical shock.
Do not attempt to aim the camera at the sun or other
extremely bright objects. This may cause damage to
the CCD and the void of warranty.
Do not touch the lens or the CCD by hands while
installing or adjusting the camera.This may cause
damage to the camera.
360°
Loosen the screw to adjust the
pan of the camera
9 ~ 22 mm
F1.4
F1.4 ~ F360C
1 m
41.9° ~ 16.3°
32.1° ~ 13.1°
23.3° ~ 9.8°
.
