DeView MD4SP70 Instruction Manual

Ccd indoor dome camera

Advertisement

Quick Links

CCD Indoor Dome Camera
Instruction Manual
www.devieweurope.com
Color Camera
Emissions:
- CE:
--EN55022
--EN55011
- FCC:
--47 CFR Part15 Subpart B
--ANSI C63.4
--ICES-003
Immunity:
- CE:
--EN55024
--EN50130-4
FCC COMPLIANCE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation .
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from the receiver circuit.
• Consult the dealer or an experienced Radio/TV technician for help.
CISPR 22 WARNING:
This is a Class B product. In a domestic environment this product may cause radio interference in which case the user may be
required to take adequate measures.
POWER SUPPLY REQUIREMENTS:
For use with listed Audio/Video product and only connected to 15W or less power supply.
*Power supply should be a NEC Class 2 / LPS Supply.
EQUIPMENT MODIFICATION CAUTION:
Equipment changes or modifications not expressly approved by seller.
The party responsible for FCC compliance could void the user's authority to operate the equipment and could create a
hazardous condition.
This class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Product illustration only for installation or adjustment reference,
please take the product as standard.
Product specifications subject to change without notice. Certain product names
mentioned herein may be trade names and/or registered trademarks of other companies.
Torx key bit x 1
Wall plugs x 3
T3 1/4" screws x 3
T6 Screw x 1
½" cable entry grommet (3/4" Grommet fitted to enclosure) x 1
¾" threaded sealing plug (1/2" sealing plug fitted to enclosure) x 1
Camera Overview
A
B
D
C
OSD menu control bank
*Note:
Product illustration only for installation or adjustment reference,
please take the product as standard.
VER. 11/2015
OSD control board
E:RS485 Termination
Switch
ON
R.t.
E
Camera Specification
General Specifications
TV System
Image Sensor
Effective Picture
976(H) x 494(V)
Scanning Frequency
Resolution
Minimum Illumination
S/N Ratio
Video Output
A: Focus Adjuster
2nd Video Output
B: Field of View Adjuster
Power Source
C: External OSD Control Board
Power Consumption
Connector
Operating Temperature
D: 2nd video out
Storage Temperature
Dimensions
Functional Specifications
Sense Up
AES
NTSC: 1/60 ~ 1/100000
Shutter Speed
MES
ATR-EX
High-Light Compensation (HLC)
Menu / Enter
Backlight Compensation (BLC)
Down
AGC Gain Control
Up
Day/Night
White Balance Control
Left
Auto White Balance Range
Right
Mirror
Control Board
Defog
Connector
Sync System
2nd video out
Motion Detection
Privacy Zone
Digital Noise Reduction
Digital Zoom
DIS
Lens Specifications
Focal Length
2.6 ~ 6 mm
F-No.
F1.6
Iris Range
F1.6 ~ F360C
Minimum Object Distance
0.5 m
134.8° ~ 59.4°
Diagonal
106.0° ~ 47.6°
Field of View
Horizontal
78.2° ~ 35.8°
Vertical
Camera Adjustments and Programming
In addition to the levers for Focus and Field of View ,
all settings are made by keys on the OSD control board.
1. Press the ENTER button, and the OSD Menu will be displayed.
2. Use the Navigation Pad to select the desired menu option.
3. Pressing the ENTER button (on any item with the
or confirm the configuration.
Navigation Pad
ENTER button
4. Use the Navigation Pad to move the cursor to EXIT; then press the ENTER button to
write the new settings to memory and complete the configuration.
5.To move to next page of the OSD menu, select and press ENTER. Similarly, to move
to the previous page of the OSD menu (or to move one hierarchy level up), select or
RETURN and press ENTER.
6. To quit or give up the configuration, select EXIT and press ENTER to the sub menu to
select NOT SAVE.
7. To reset the camera to the factory setting, select CAMERA RESET and press ENTER (if
CAMERA RESET is not visible on the OSD menu, please select NEXT/BACK and press
ENTER until CAMERA RESET appears).
PAGE1
SCENE SELECT
FULL AUTO
INDOOR
NTSC
PAL
OUTDOOR
BACKLIGHT
Sony 1/3" Super HAD-II
ITS
CUSTOM
976(H) x 582(V)
60Hz
50Hz
700 TVL
0.3Lux(F1.2,50IRE, AGC ON)
50dB (100 IRE, F1.2)
1.0Vpp Composite Output
Yes (supports installation check)
12 VDC ±10% / 24 VAC ±20%
Normal:1.9W
-10°C ~ +50°C
-20°C ~ +60°C
Φ 136mm x 94.2mm (H)
ON / OFF
PAL: 1/50 ~ 1/100000
1/50 (1/60), 1/120 (1/100), 1/250, 1/500, 1/1K, 1/2K, 1/4K, 1/10K
OFF/ATR-EX
ON/OFF
Full Range
44.8 dB
SDN(AUTO ,COLOR ,NIGHT)
ATW / Manual / Push / Push Lock / USER1,2
Indoor:1800K~10500K Outdoor:6500K~10500K
OFF/V-FLIP/H-FLIP/HV-FLIP
ON/OFF
INT /LL
4 Areas
Up to 15 Masks
3D DNR
255X Max
ON/OFF
PICT ADJUST
2.8 ~ 10 mm
9 ~ 22 mm
DIS
F1.2
F1.4
EZOOM
F1.2 ~ F360
F1.4 ~ F360C
0.15 m
1 m
PRIVACY MASK
125.0° ~ 36.0°
41.9° ~ 16.3°
94.6° ~ 28.8°
32.1° ~ 13.1°
68.4° ~ 21.6°
23.3° ~ 9.8°
MOTION DET
SYS SETTING
symbol) will open the sub-menu
SETUP MENU
1/2
SENCE SELECT
CUSTOM
PICT ADJUST
EZOOM
OFF
EXIT
DIS
OFF
PRIVACY MASK
PAGE2
MOTION DET
OFF
LANGUAGE
ENGLISH/中文/ESPANOL/PORTUGUES/PYCCKNN/FRANCAIS/DEUTSCH/日本語
SYS SETTING
OFF
NEXT
VERSION
MAINTENANCE
EXIT
SAVE
NOT SAVE
CANCEL
BACK
SHUTTER /
AUTO
AE LEVEL
001 ~ 250
AGC
AGC MAX
6.0DB ~ 44.8DB
SENS UP
AUTO / OFF
MANUAL
SHUTTER
256FLD ~ 1/10000
AGC MAX
6.0DB ~ 44.8DB
FIX
SHUTTER
256FLD ~ 1/10000
AGC MAX
6.0DB ~ 44.8DB
SPEED
000 ~ 255
WHITE BAL
ATW(*1)
DELAY CNT
001∼255
ATW FRAME
001∼255
ENVIRONMENT
INDOOR / SUNNY / SHADE / AUTO
PUSH
USER1
RGAIN
000 ~ 255
000 ~ 255
BGAIN
USER2
RGAIN
000 ~ 255
BGAIN
000 ~ 255
MANUAL
LEVEL
00 ~ 63
PUSH LOCK
HLC/BLC
OFF
HLC
CLIP LEVEL
000 ~ 255
BLC(*2)
OFF
ATR-EX(*3)
CONTRAST
LOW / MID / HIGH(*4)
ATR-EX
CLEAR FACE
LOW / MID / HIGH / OFF
DNR
LEVEL
0 ~ 6
DAY/NIGHT
DAY
NIGHT
BURST
ON/OFF
AUTO
BURST
ON/OFF
CNTL SIGNAL
INT/EXT1/EXT2
DELAY CNT
DAY->NIGHT
NIGHT->DAY
IR OPTIMZER
OFF
ON
MODE
AUTO
CENTER
IR AREA
﹍﹍﹍﹍﹍﹍
TOP
0~ 6
BOTTOM
0~ 6
LEFT
0~ 8
RIGHT
0~ 8
WEIGHT
00~ 15
LEVEL
0-12
IR LED
OFF
FIX
LEVEL
000 ~ 255
DAY/NIGHT
LEVEL MIN
001 ~ 255
LEVEL MAX
001 ~ 255
COLOR NIGHT
OFF
ON
COLOR GAIN
LOW / MID / HIGH
IR SHADE COMP
OFF
ON
PATTERN
SET1 / SET2 / SET3
POSH
000 ~ 959
POSV
000~490
LEVEL
OFF / LOW / MID / HIGH
LENS SHD COMP
OFF
ON
PATTERN
SET1 / SET2 / SET3
POSH
000 ~ 959
POSV
000~490
DEFOG(*5)
OFF
ON
LEVEL
LOW / MID / HIGH
FLK LESS
OFF
AUTO
MODE
GAIN CNTL
SHUTTER FIX
ON
MODE
GAIN CNTL
SHUTTER FIX
ANTI CR
AUTO/OFF/ON
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
COLOR GAIN
ON/OFF
OFF
ON
MAG/PAN/TILT
AREA SEL
1~15
DISPLAY
OFF / ON
POSITION
WHITE / BLACK / RED /GREEN / BLUE /
COLOR
.
YELLOW / CYAN / MAGENTA
TRANSP
0.00 / 0.50 / 0.75 / 1.00
MOSAIC
OFF / ON
OFF
DETECT SENSE
ON
INTERVAL
BLOCK DISP
MASK AREA
MOTION AREA
AREA SEL
1~4
MODE
TOP
BOTTOM
LEFT
RIGHT
SYNC MODE
INT/LL(*6)
LENS
MANUAL
AUTO
TYPE
MODE
ADJUST
SPEED
FLIP
OFF/V/H/VH
LCD/CRT
COMMNUNICATION
PROTOCOL
ADDRESS
BAUDRATE
DATABIT
PARITY
STOPBIT
CAMERA ID
OFF
ON
POS
W.PIX MASK
MANUAL
REGISTRATION
REG.POINT
CAMERA RESET
CURSOR COLOR
BLINK
REG.NUMBER
AUTO
RUN
BACK
DATA CLEAR
This can not be changed except CUSTOM mode.
