Summary of Contents for Pfeiffer Vacuum TPS 110
- Page 1 AC in DC out TPS 110 - 400 / TPS 111 - 401 Mains pack Operating Instructions...
-
Page 2: Table Of Contents
Table of contents Table of contents About this manual..........3 Validity. -
Page 3: About This Manual
1 About this manual 1.1 Validity This operating manual is for customers of Pfeiffer Vacuum. It describes the func- tioning of the designated product and provides the most important information for safe use of the unit. The description follows applicable EU guidelines. All informa- tion provided in this operating manual refer to the current state of the product's de- velopment. -
Page 4: Safety
Safe operation after installation is the responsibility of the operator. Do not independently modify or change the pump and electrical equipment. Make sure that the system is integrated in an emergency off safety circuit. Consult Pfeiffer Vacuum for special requirements. WARNING Danger of electric shock In case of defect, the parts connected to the power supply are under voltage. -
Page 5: Proper Use
Take appropriate measures to ensure that hot surfaces (>70 °C) can not be touched. External separators shall be provided in case of not approachable installed devices. • Pfeiffer Vacuum mains packs only serve to the external voltage supply of Pfeiffer Vacuum turbopumps with integrated electronic drive unit. -
Page 6: Product Description
400 W W = Wall or standard rail mounting E = 19" partial plug-in unit 3HE with front panel To correctly identify the product when communicating with Pfeiffer Vacuum, al- ways have the information from the rating plate available. D-35614 Asslar... -
Page 7: Installation
The use of screws that are longer than than those stated below can cause a short circuit and is not permitted. To ensure the safe installation of Pfeiffer Vacuum products, use only the installation materials supplied. Standard rail installa-... -
Page 8: Connecting To The Mains Power Supply
Do not independently modify or change the pump and electrical equipment. Make sure that the system is integrated in an emergency off safety circuit. Consult Pfeiffer Vacuum for special requirements. Order the mains cable separately (see "accessories"). -
Page 9: Service
Service 6 Service Pfeiffer Vacuum offers first-class service! • Fast replacement with exchange products in mint condition • Advice on the most cost-efficient and quickest solution Detailed information, addresses and forms at: www.pfeiffer-vacuum.net (Service). Service orders All service orders are carried out exclusively according to our repair conditions for vacuum units and components. -
Page 10: Dimensions
Technical data 8.1 Dimensions Fig. 3: Power supply for wall or standard-rail mounting Dimensions TPS 110 TPS 180 TPS 310 TPS 400 169 mm 190 mm 190 mm 190 mm 120 mm 120 mm 120 mm 120 mm 142 mm... -
Page 11: Declaration Of Conformity
DIN EN 61000-3-2 : 2008 DIN EN 61000-3-3 : 2006 DIN EN 61010-1 : 2002 DIN EN 61326-1 : 2006 DIN EN 62061 : 2005 Signatures: Pfeiffer Vacuum GmbH Berliner Straße 43 35614 Asslar Germany (M.Bender) (Dr. M. Wiemer) CE/2009...
