INSTALLATION GUIDE
A Replace existing cam lock with KitLock
Step 1 Remove existing cam lock.
Step 2 Place the 16mm ( 5 / ") template
8
hole over the hole left by the
cam lock and mark the upper
fixing hole.
1
Step 3 Drill the 6mm ( / ") fixing hole.
4
Step 4 Fit the KitLock to the door by
passing the spindle through
the 16mm ( 5 / ") hole.
8
Step 5 If required, from the inside of
the door, pass either of the
packing pieces over the
spindle to centralise the lock.
Step 6 Now secure the lock by threading
the large nut onto the spindle.
Step 7 Fit one of the upper fixing bolts
to suit your door thickness.
B New Installation
Step 1 Place template on door and
mark upper 6mm ( 1 / ") hole
4
and lower 16mm ( 5 / ") hole.
8
IMPORTANT NOTE: Before
drilling fixing holes, please
ensure the position of the
KitLock when fitted will allow
enough clearance for selected
cam to work.
Step 8 Tighten the lower fixing nut
and upper bolt.
Step 9 Select the cam which suits
your door and frame and
attach it to the square shaft at
the end of the spindle.
Step 10 Now check the operation of
the lock using the factory
User Code 22 44.
Step 11 If the lock is functioning
correctly, CHANGE THE
DEFAULT MASTER
CODE 11 33 55 77 and
DEFAULT USER CODE
22 44 and program the
lock using the programming
and operating instructions
enclosed.
Step 2 Drill both fixing holes.
Step 3 Continue installation from
step 4 to 11, above.
