Mitsubishi Electric PEA-RP250WKA Operation Manuals

Original mr. slim series indoor unit
Hide thumbs

Advertisement

Quick Links

Кондиционеры
ВНУТРЕННИЙ БЛОК
Air-Conditioners
INDOOR UNIT
PEA-RP200,250WKA
OPERATION MANUAL
For safe and correct use, please read this operation manual thoroughly before operating the air-conditioner unit.
BEDIENUNGSHANDBUCH
Zum sicheren und einwandfreien Gebrauch der Klimaanlage dieses Bedienungshandbuch vor Inbetriebnahme
gründlich durchlesen.
MANUEL D'UTILISATION
Pour une utilisation correcte sans risques, veuillez lire le manuel d'utilisation en entier avant de vous servir du
climatiseur.
MANUAL DE INSTRUCCIONES
Lea este manual de instrucciones hasta el final antes de poner en marcha la unidad de aire acondicionado para
garantizar un uso seguro y correcto.
ISTRUZIONI DI FUNZIONAMENTO
Leggere attentamente questi istruzioni di funzionamento prima di avviare l'unità, per un uso corretto e sicuro
della stessa.
BEDIENINGSHANDLEIDING
Voor een veilig en juist gebruik moet u deze bedieningshandleiding grondig doorlezen voordat u de
airconditioner gebruikt.
DRIFTSMANUAL
Läs denna driftsmanual noga för säkert och korrekt bruk innan luftkonditioneringen används.
DRIFTSMANUAL
Læs venligst denne driftsmanual grundigt før airconditionanlægget betjenes af hensyn til sikker og korrekt brug.
MANUAL DE OPERAÇÃO
Para segurança e utilização correctas, leia atentamente o manual de operação antes de pôr a funcionar a
unidade de ar condicionado.
ΕΓΧΕΙΡΙ∆ΙΟ Ο∆ΗΓΙΩΝ ΧΡΗΣΕΩΣ
Για ασφάλεια και σωστή χρήση, παρακαλείστε διαβάσετε προσεχτικά αυτό το εγχειρίδιο χρήσεως πριν θέσετε σε
λειτουργία τη μονάδα κλιματισμού.
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
Для обеспечения правильного и безопасного использования следует ознакомиться с инструкциями, указанными в
данном руководстве по эксплуатации, тщательным образом до того, как приступать к использованию кондиционера.
İŞLETME ELKİTABI
Emniyetli ve doğru biçimde nasıl kullanılacağını öğrenmek için lütfen klima cihazını işletmeden önce bu elkitabını
dikkatle okuyunuz.
FOR USER
FÜR BENUTZER
POUR L'UTILISATEUR
PARA EL USUARIO
PER L'UTENTE
VOOR DE GEBRUIKER
FÖR ANVÄNDAREN
TIL BRUGER
PARA O UTILIZADOR
ΓΙΑ ΤΟΝ ΧΡΗΣΤΗ
ДЛЯ ПОЛЬЗОВАТЕЛЯ
KULLANICI İÇİN
<ORIGINAL>
English
Deutsch
Français
Español
Italiano
Nederlands
Svenska
Dansk
Português
Ελληνικά
Русский
Türkçe

Advertisement

loading

  Also See for Mitsubishi Electric PEA-RP250WKA

  Related Manuals for Mitsubishi Electric PEA-RP250WKA

  Summary of Contents for Mitsubishi Electric PEA-RP250WKA

  • Page 1 <ORIGINAL> Кондиционеры ВНУТРЕННИЙ БЛОК Air-Conditioners INDOOR UNIT PEA-RP200,250WKA OPERATION MANUAL FOR USER English For safe and correct use, please read this operation manual thoroughly before operating the air-conditioner unit. BEDIENUNGSHANDBUCH FÜR BENUTZER Deutsch Zum sicheren und einwandfreien Gebrauch der Klimaanlage dieses Bedienungshandbuch vor Inbetriebnahme gründlich durchlesen.
  • Page 2: Table Of Contents

    This symbol mark is according to the directive 2012/19/EU Article 14 Information for users and Annex IX, and/or to the directive 2006/66/EC Article 20 Information for end-users and Annex II. Your MITSUBISHI ELECTRIC product is designed and manufactured with high quality materials and components which can be recycled and/or reused. This symbol means that electrical and electronic equipment, batteries and accumulators, at their end-of- life, should be disposed of separately from your household waste. If a chemical symbol is printed beneath the symbol (Fig. 1), this chemical symbol means that the battery or accumulator contains a heavy metal at a certain concentration.
  • Page 3: Parts Names

    2. Parts Names ■ Indoor Unit PEA-RP·WKA Fan steps 3 steps Vane – Louver – Filter Normal Filter cleaning indication – ■ Wired Remote Controller (option) Controller interface The functions of the function buttons change depending on the screen. Refer to the button function guide that appears at the bottom of the LCD for the functions they serve on a given screen. When the system is centrally controlled, the button function guide ⑤...
  • Page 4 2. Parts Names Display The main display can be displayed in two different modes: “Full” and “Basic”. The factory setting is “Full”. To switch to the “Basic” mode, change the setting on the Main display setting. (Refer to operation manual included with remote controller.) <Full mode>...
  • Page 5 2. Parts Names ■ Wireless Remote-Controller (option) SET TEMPERATURE button SET TEMPERATURE button ON/OFF button CHECK TEST RUN sets and any desired room MODEL SELECT Pushing button starts operation. temperature. Pushing again stops operation. NOT AVAILABLE FAN SPEED button AUTO STOP/AUTO START button TEMP ON/OFF This button is used to set fan Used for selecting timed starting speed to low, medium or high.
  • Page 6: Operation

    3. Operation ■ About the operation method, refer to the operation manual that comes with each remote controller. 3.1. Turning ON/OFF 3.1.1. For wired remote controller [ON] [OFF] Press the [ON/OFF] button. Press the [ON/OFF] button again. The ON/OFF lamp will light up in The ON/OFF lamp will come off, and green, and the operation will start. the operation will stop. ■...
  • Page 7 3. Operation Information for multi system air conditioner (Outdoor 3.3.2. For wireless remote controller unit: MXZ series) ► To decrease the room temperature: button ③ to set the desired temperature. ► M ulti system air conditioner (Outdoor unit: MXZ series) can Press The selected temperature is displayed 3. connect two or more indoor units with one outdoor unit. • Each time you press the button, the temperature value decreases by 1 °C. According to the capacity, two or more units can operate simultaneously.
  • Page 8 3. Operation 3.5. Ventillation (For wired remote controller) <Display of unsupported functions> 3.5.1. Navigating through the Main menu Title The message at left will appear <Accessing the Main menu> if the user selects a function not Not available Main Main menu Unsupported function supported by the corresponding Press the [MENU] button. Vane·Louver·Vent. (Lossnay) indoor unit model. The Main menu will appear.
  • Page 9: Timer

    4. Timer ■ Timer functions are different by each remote controller. ■ For details on how to operate the remote controller, refer to the appropriate operation manual included with each remote controller. 4.1. For wireless remote controller 1) Set the current time ① Press the CLOCK button using a thin stick and blink the time Ⓐ . ②...
  • Page 10: Trouble Shooting

    6. Trouble Shooting Having trouble? Here is the solution. (Unit is operating normally.) ■ Clean the filter. (Airflow is reduced when the filter is dirty or clogged.) Air conditioner does not heat or cool well. ■ Check the temperature adjustment and adjust the set temperature. ■...
  • Page 11: Specifications

    The wireless remote controller does not operate (the indoor unit beeps AUTO (dual set point) mode. For details, refer to the included Notice (A5 4 times). sheet) or the Installation Manual. 7. Specifications Item Model PEA-RP200WKA PEA-RP250WKA Power source 220-240V 50Hz Dimension Height / Width / Depth 470/1370/732 470/1370/732 Net weight...
  • Page 12 This product is designed and intended for use in the residential, commercial and light-industrial environment. The product at hand is • Low Voltage Directive 2014/35/EU based on the following • Electromagnetic Compatibility Directive EU regulations: 2014/30/EU • Machinery Directive 2006/42/EC Не...
