Deep Sea Electronics Plc DSE701 MKII Installation Instructions And Instructions For Use

D S E 7 0 1 M K I I I N S T A L L A T I O N I N S T R U C T I O N
The Model DSE701 MKII Engine Control Module is designed to control the engine via a key switch and pushbuttons
on the front panel. The module is used to start and stop the engine and indicate fault conditions, automatically shutting
down the engine and indicating the cause of failure by LED, giving true, first up fault annunciation.
The auxiliary input on the controller can be configured using the DSE Configuration Suite Lite PC Software. This gives
the user the option to have a remote start module or for an auxillary fault input when used in a manual only application.
In the position the DC supply is removed from the module and the run output is de-energised.
The module is powered up when
MODULE OPERATION
MANUAL START MODULE
1. Turn the key to the RUN
2. The pre-heat will start automatically as soon as the
RUN mode is engaged and last for the duration of
the configured time.
3. Press START button to crank engine.
The starter disengages automatically in both operation modes when the engine fires, the safety on delay timer is then
initiated.
Operation of any of the following alarms (which are close on fault) will cause the fuel output to de-energise:
•
Low Oil Pressure
•
High Coolant Temperature
•
Auxiliary Shutdown
•
Overspeed - (Nominal frequency selector switch accessible through slots in base of module).
This will remove the fuel supply from the engine and bring it to rest.
Each alarm has its own LED indicator and once activated no further alarm conditions will be accepted. The alarm
output and relevant LED will remain active until the unit is reset by turning the switch to the
Deep Sea Electronics Plc.
Tel:+44 (0)1723 890099
Fax: +44 (0)1723 893303
Email: support@deepseaplc.com
Web: www.deepseaplc.com
D E E P S E A E L E C T R O N I C S
is selected.
AUTO START MODULE
position 1. Turn the key to the RUN
2. The pre-heat will operate automatically
prior to the starting of the engine.
3. Press START
remote start input to crank engine.
TOLL FREE (USA only) : Tel: 1 866 636 9703
position
button or apply the
position.
Deep Sea Electronics Inc.
Phone: +1 (815) 316-8706
Fax: +1 (815) 316-8708
Email: support@deepseausa.com
Web: www.deepseausa.com
053-132
ISSUE 2
