CD Automation srl
14.6 Group EHT EHT (Functions setted also from input1 and input2)
EHT EHT
The functions
Auto/Manual
•
SP/SP1
•
Tune Insertion
•
Silencing the alarm
•
Control group selection
•
may be controlled from key panel, from serial or contact of input. To avoid conflicts, through this group, is
possible to select from which of these functions will be controlled.
FUNCTION COMMAND AUTO/MANUAL
(available only if is present a contact module or digital IO on Input1 or Input2 and if one of the two input
is configured by command Auto/Manual)
Upper display
Lower display
Range
Sutc Command from Input
Serh Command from key penel or serial
FUNCTION COMMAND SP/SP1
(available only if is present a contact module or digital IO on Input1 or Input2 and if one of the two input
is configured by command SP/SP1)
Upper display
Lower display
Range
Sutc Command from Input
Serh Command from key penel or serial
mnoP
Actual Value
SPoP
Actual Value
pag. 44 di 121
